NYCP 240T
NYCP 240T_VP
NYCP 240 är ett handhydrauliskt pressverktyg för rörkabelskor och C-hylsor.
Verktygets huvud är roterbart 180°.
Levereras i en slitstark plastväska.
Verktyget kan pressa:
KRF 10-120 mm²
KRT 10-240 mm²
KRD 10-240 mm²
C4-C9
Verktyget passar med NH-backar.
Presskraft: 52 kN/5,3 ton
Vikt: 2.4 kg
Längd: 377 mm
OBS! Pressbackar ingår ej.
- With locking device (for mechanical tools):
- No
- Inserts exchangeable:
- Yes
- Number of included inserts:
- 0 .
- With automatic return:
- No
- Cycle time:
- 10 s
- Suitable for:
- Cable lugs and connectors
- Construction/operation:
- Hand hydraulic
- For component:
- Non-insulated Cu tube and sheet terminals
- Compression shape:
- Round compression
Kombinationstång med returfjäder
CP 200 S_VP
CP 200 S
Kombinationstång med returfjäder och halkskyddade handtag.
Med sidavbitare och tvärräfflade gripytor.
Tillverkad i blankpolerad, svart CrV.
Längd: 210 mm
- Gripping surface:
- Toothed
- With diagonal cutting nipper:
- Yes
- Grip design:
- 1-component
- ESD tested:
- No
- Low spark model:
- No
- Protruding cutting edge:
- No
- Insulated:
- Yes
- Shape:
- Straight
- Material:
- Steel
- Isolation protection 1000 V:
- No
- VDE tested:
- No
Kombinationstång/Linjetång, softgrip
PP-225P_VP
Combination Pliers with slip proof soft grip handles. The plier side cutter, burner hole and facets. Crimp socket for 2.5-6.0 mm² uninsulated terminals.Forged steel with polished / hardened jaws. Slip-proof soft-grip handle.
Length: 225 mm
- Gripping surface:
- Toothed
- With diagonal cutting nipper:
- Yes
- Grip design:
- 1-component
- ESD tested:
- No
- Low spark model:
- No
- Protruding cutting edge:
- No
- Insulated:
- Yes
- Shape:
- Straight
- Material:
- Steel
- Isolation protection 1000 V:
- No
Elskåpsnyckel
CS 5_vp
Apparatskåpnyckel som passar de flesta apparat- och elskåp.
Levereras med bits för spår- och stjärnskruv.
Blisterförpackad för butiksexponering.
Längd: 90 mm
Invändiga Fyrkanter: 5, 6, 7-8 mm
Trekant: 7-8 mm
Cirkel - Spår: ca 2.2 mm, IØ: 5.5 mm, YØ: 9mm
Spårbits: 1 x 7 mm
Philipsbits: PH2
Crimp tools for End-sleeves
84702
KH 55WF / KH 95WF / KH 150WF
3 different crimping tools for end-sleeves.
Type of crimping: Trapezoid crimp
Capacity:
KH 55WF: 10-50 mm²
KH 95WF: 50-95 mm²
KH 150WF: 120-150 mm²
Length: 330 mm / 330 mm / 385 mm
- With locking device (for mechanical tools):
- Yes
- Inserts exchangeable:
- No
- Number of included inserts:
- 1 .
- With automatic return:
- Yes
- Cycle time:
- 2 s
- Suitable for:
- Cable end sleeves
- Construction/operation:
- Mechanical
- For component:
- End sleeves
- Compression shape:
- Trapezoid compression
KRF - 500-1000mm²
KRF_500-1000mm_vp
Copper tube lugs for the Nordic market. For stranded wires (class 5 and Class 6).
Material: 99.9% pure copper
Surface: > 4µ Sn
Inscriptions on the lugs palm can for ie be: F35-12
F = KRF // 35 = 35 mm² wire // 12 = M12 stud size.
Inscriptions on the lugs neck can for ie be: 13
13 = Outside diameter of the neck (F).
When crimping with hexagon dies neck inscription and die markings must conform.
- Suitable for Class 5 conductor:
- Yes
- Suitable for Class 6 conductor:
- Yes
- Insulated:
- No
- Max. current (Imax):
- 842-950 A
- Number of mounting holes:
- 1 .
- Flange shape:
- Ring shape
- Colour insulation:
- Other
- Slender flange model:
- No
- With sight-hole:
- Yes
- Conductor category:
- Several
- Max Temp:
- 150 °C
- Surface protection:
- Tinned
- Material:
- Copper
- Connecting angle:
- 180° (horizontal)
- Series:
- KRF/KSF (500-1000mm2)
R2G4 - 100 m spool 2-colors
R2G4 på 100 m bobin_vp
GeneralThin-walled car cable with PVC insulation and fine wire copper conductors for maximum 100ºC conductor temperature.
Packaging (OD x Hub x Width):
Spool B3: 160mm x 56mm x 50mm
Structure:
Conductor: Blank stranded copper
Conductor insulation: PVC
Conductor identification: Multiple color combinations
Technical data:
Rating voltage: 100V
Temperature range: -40ºC to +100ºC (-40ºF to +212ºF)
Approvals: According to Volvo 7613 R2, 111 / 3
- Number of cores:
- 1 .
- Material core insulation:
- Polyvinyl chloride (PVC)
- Specification core insulation:
- Other
- Core identification:
- None
- Protective conductor:
- No
- Material outer sheath:
- None
- Specification material outer sheath:
- Other
- Colour outer sheath:
- Other
- Flame retardant:
- According to IEC/EN 60332-1-2
- Permitted cable outer temperature after assembling without vibration:
- -40-100 °C
- Conductor material:
- Copper
- Twisted cores:
- No
- Max. conductor temperature:
- 100 °C
- Screen:
- No
- Protective barrier:
- N/A
- Armouring/reinforcement:
- None
- Insulation integrity:
- N/A
- Drain wire:
- No
- Halogen free:
- No
- Conductor category:
- Class 5 = flexible
- Single insulated/Double insulated:
- Single insulated
- Core colour:
- Several
- Conductor surface:
- Bare
- Min. permitted bending radius, stationary application/permanent installation:
- 8-18 mm
- Reaction-to-fire according to EN 13501-6: Class:
- N/A
- Reaction-to-fire according to EN 13501-6: Smoke production:
- N/A
- Reaction-to-fire according to EN 13501-6: Flaming droplets/particles:
- N/A
- Reaction-to-fire according to EN 13501-6: Acidity:
- N/A
- Low smoke (according to EN 61034-2):
- No
- Low temperature resistant (according to EN 60811-504+505+506):
- No
- Oil resistant according to EN IEC 60811-404:
- No
R2G4 - 400 m spool 2-colors
73501
Thin-walled car cable with PVC insulation and fine wire copper conductors for maximum 100ºC conductor temperature.
Packaging (OD x Hub x Width):
Spool B6: 250mm x 56mm x 95mm
Structure
Conductor: Blank stranded copper
Conductor insulation: PVC
Conductor identification: Multiple color combinations
Technical data:
Rating voltage: 100V
Temperature range: -40ºC to +100ºC (-40ºF to +212ºF)
Approvals: According to Volvo 7613 R2, 111 / 3
- Number of cores:
- 1 .
- Material core insulation:
- Polyvinyl chloride (PVC)
- Specification core insulation:
- Other
- Core identification:
- None
- Protective conductor:
- No
- Material outer sheath:
- None
- Specification material outer sheath:
- Other
- Colour outer sheath:
- Other
- Flame retardant:
- According to IEC/EN 60332-1-2
- Permitted cable outer temperature after assembling without vibration:
- -40-100 °C
- Conductor material:
- Copper
- Twisted cores:
- No
- Max. conductor temperature:
- 100 °C
- Screen:
- No
- Protective barrier:
- N/A
- Armouring/reinforcement:
- None
- Insulation integrity:
- N/A
- Drain wire:
- No
- Nominal voltage:
- 100 V
- Halogen free:
- No
- Conductor category:
- Class 5 = flexible
- Single insulated/Double insulated:
- Single insulated
- Colour:
- Green/yellow, Other, Black/white, Yellow/black, Red/black, Red/Blue, Blue/Brown, Blue/Yellow, Blue/Pink, Blue/Red, Blue/Black, Blue/White, Brown/Orange, Brown/Pink, Brown/Black, Brown/White, Grey/Blue, Grey/Green, Grey/Red, Grey/Black, Grey/White, Green/Red, Green/Black, Green/White, Yellow/Purple, Yellow/Red, Yellow/Violet, Yellow/White, Orange/Black, Orange/White, Pink/Brown, Pink/White, Red/Green, Red/White, Violet/Yellow, White/Violet
- Operating temperature:
- -40-100 °C
- Core colour:
- Green/yellow, Several
- Conductor surface:
- Bare
- Packaging:
- Reel B3, Reel B5, Reel B6
- Min. permitted bending radius, stationary application/permanent installation:
- 8-14 mm
- Reaction-to-fire according to EN 13501-6: Class:
- N/A
- Reaction-to-fire according to EN 13501-6: Smoke production:
- N/A
- Reaction-to-fire according to EN 13501-6: Flaming droplets/particles:
- N/A
- Reaction-to-fire according to EN 13501-6: Acidity:
- N/A
- Low smoke (according to EN 61034-2):
- No
- Low temperature resistant (according to EN 60811-504+505+506):
- No
- Oil resistant according to EN IEC 60811-404:
- No
K 35
K 35_VP
Crimps end-sleeves:
Single end-sleeve: 10.5-35.0 mm²
Type of crimping: Thorn crimp
Length: 230 mm
- With locking device (for mechanical tools):
- No
- Inserts exchangeable:
- No
- Number of included inserts:
- 1 .
- With automatic return:
- No
- Cycle time:
- 2 s
- Suitable for:
- Cable end sleeves
- Construction/operation:
- Mechanical
- For component:
- End sleeves
- Compression shape:
- Arbour clamping
CT 38
CT 38_VP
CT 38 is a simpler thorn-crimping tool for 10.0-35.0 mm² copper lugs type KRF/KRT/KRD and metal sheet terminals (DIN).
There are 4 die nests:
Nest 8: Metal sheet 10, KRT 10
Nest 14: Metal sheet 16, KRF 10 & 16, KRT 16, KRD 16 & 25
Nest 22: Metal sheet 25, KRF 25, KRT 25, KRD 35
Nest 38: Metal sheet 35, KRF 35, KRT 35
Length: 550 mm
- With locking device (for mechanical tools):
- No
- Inserts exchangeable:
- No
- Number of included inserts:
- 1 .
- With automatic return:
- No
- Cycle time:
- 2 s
- Suitable for:
- Cable lugs and connectors
- Construction/operation:
- Mechanical
- For component:
- Non-insulated Cu tube and sheet terminals
- Compression shape:
- Arbour clamping
Kapsaxar för slang och VP-rör
6907
TC 38 / TC 42
Kapsaxar för PVC-rör, PVC-slang, kabelkanal, gummislang mm.
Steglös frammatning med returknapp för skäret.
Klippkapacitet (diameter):
TC 38: 6-35 mm
TC 42: 6-42 mm
Längd: 195 mm / 220 mm
- Suitable for stainless steel:
- No
- Suitable for aluminium:
- No
- Suitable for copper:
- No
- Suitable for steel:
- No
- Suitable for cast iron pipe:
- No
- Suitable for plastic:
- Yes
- Suitable for multi-layer composite pipes:
- Yes
- With inner tube deburrer:
- No
- With quick adjustment:
- Yes
- Telescopic:
- No
- Number of cutting wheels:
- 0 .
- Isolation protection 1000 V:
- No
Elskåpsnyckel
CS 4_VP
Device cabinet key that fits most device and electrical cabinets. Comes with bit for Slotted and Phillips screw. Blister packaged for store display. Length: 90 mm Inner Squares: 5, 6, 7-8 mm Triangle: 11mm Outside Squares: 6, 7, 8 and 9 mm Slotted bit: 1x7 mm Philips bits: PH2
K 6
K 6_VP
With return feather for quicker handling.
Crimps end-sleeves:
Single end-sleeve: 1.5-6.0 mm²
Type of crimping: Thorn crimp
Length: 150 mm
- With locking device (for mechanical tools):
- No
- Inserts exchangeable:
- No
- Number of included inserts:
- 1 .
- With automatic return:
- Yes
- Cycle time:
- 2 s
- Suitable for:
- Cable end sleeves
- Construction/operation:
- Mechanical
- For component:
- End sleeves
- Compression shape:
- Arbour clamping
K 48
K 48_VP
With return spring for quicker handling.
Crimps end-sleeves:
Single end-sleeve: 0.25-2.5 mm²
Type of crimping: Trapezoid crimp
Length: 150 mm
- With locking device (for mechanical tools):
- No
- Inserts exchangeable:
- No
- Number of included inserts:
- 1 .
- With automatic return:
- Yes
- Cycle time:
- 2 s
- Suitable for:
- Cable end sleeves
- Construction/operation:
- Mechanical
- For component:
- End sleeves
- Compression shape:
- Trapezoid compression
K 4
K 4_VP
With return feather for quicker handling.
Crimps end-sleeves:
Single end-sleeve: 0.5-2.5 mm²
Type of crimping: Thorn crimp
Length: 150 mm
- With locking device (for mechanical tools):
- No
- Inserts exchangeable:
- No
- Number of included inserts:
- 1 .
- With automatic return:
- Yes
- Cycle time:
- 2 s
- Suitable for:
- Cable end sleeves
- Construction/operation:
- Mechanical
- For component:
- End sleeves
- Compression shape:
- Arbour clamping
K 16
K 16_VP
Crimps end-sleeves:
Single end-sleeve: 0.75-16.0 mm²
Type of crimping: Thorn crimp
Length: 230 mm
- With locking device (for mechanical tools):
- No
- Inserts exchangeable:
- No
- Number of included inserts:
- 1 .
- With automatic return:
- No
- Cycle time:
- 2 s
- Suitable for:
- Cable end sleeves
- Construction/operation:
- Mechanical
- For component:
- End sleeves
- Compression shape:
- Arbour clamping
ES 3
ES 3_VP
Crimps end-sleeves:
Single end-sleeve: 0.25-2.5 mm²
Type of crimping: Trapezoid crimp
Length: 165 mm
- With locking device (for mechanical tools):
- No
- Inserts exchangeable:
- No
- Number of included inserts:
- 1 .
- With automatic return:
- No
- Cycle time:
- 2 s
- Suitable for:
- Cable end sleeves
- Construction/operation:
- Mechanical
- For component:
- End sleeves
- Compression shape:
- Trapezoid compression
ES 16
ES 16_VP
Crimps end-sleeves:
Single end-sleeve: 0.5-16.0 mm²
Type of crimping: Trapezoid crimp
Length: 190 mm
- With locking device (for mechanical tools):
- No
- Inserts exchangeable:
- No
- Number of included inserts:
- 1 .
- With automatic return:
- No
- Cycle time:
- 2 s
- Suitable for:
- Cable end sleeves
- Construction/operation:
- Mechanical
- For component:
- End sleeves
- Compression shape:
- Trapezoid compression
- Handle cover:
- Plastic
- Surface protection:
- Lacquered
- Construction/operation:
- Ratchet model mechanical
- Isolation protection 1000 V:
- No
- With spring:
- No
AC 8
AC 8_VP
Cable cutter for steel wire with V-shaped blades for easier cutting.
Cutting capacity (diameter): 0.6-4.0 mm
Length: 180 mm
- Handle cover:
- Plastic
- Surface protection:
- Lacquered
- Construction/operation:
- Mechanic one hand
- Isolation protection 1000 V:
- No
- With spring:
- No
Tool for steel cable ties - TG 600S
TG 600S_VP
Tool for steel cable ties with adjustable tension and automatic cutting function.
Used for the following cable ties: Type ST2, LS, AE 6xx, AE 7xx
Length: 180 mm
- Tensioning strength:
- Manual
- Material tool:
- Metal
- Property:
- Manual clipping
- Construction type:
- Ställbart dragtryck, Automatisk klipp
- Construction/operation:
- Mechanic one hand
- Material cable tie:
- Stainless steel
- MIL specified:
- No
Hand tools for steel ties - CT3
CT 3_VP
Steel cable tie tool with very good functionality and precision.
The cable tie is cut off using a hand-operated lever.
Used for the following cable ties: Type ST2, LS, AE 6xx, AE 7xx
Length: 220 mm
- Tensioning strength:
- Manual
- Material tool:
- Metal
- Property:
- Manual clipping
- Construction/operation:
- Mechanic one hand
- Material cable tie:
- Stainless steel
- MIL specified:
- No
Pressverktyg för modularkontakter- RJ
65010
Pressverktyg för modularkontakter, utrustad med en färdiginställd skal- och klippfunktion.
- With locking device (for mechanical tools):
- Yes
- Inserts exchangeable:
- No
- Number of included inserts:
- 1 .
- With automatic return:
- Yes
- Cycle time:
- 2 s
- Suitable for:
- Cable lugs and connectors
- Construction/operation:
- Mechanical
- For component:
- Modularplugg
- Compression shape:
- Notching
