Pressverktyg i flera utförande bestyckad med 1 backpar från NCXD/DHD/DRG-serien. Pressverktyget är en ratchettång som säkerställer att pressningen fullföljs. Returspärren har en release-hake ifall man vill avsluta pressningen.

Pressverktyget är en ratchettång med inbyggd returspärr som garanterar att kontaktpressningen fullföljs.

Copper tube lugs for the Nordic market. For stranded wires. Material: 99.9% pure copper Surface: > 4µ Sn Inscriptions on the lugs palm can for ie be: n35-12D n = nemiq // 35 = 35 mm² wire // 12 = M12 stud size // F = KRF Inscriptions on the lugs neck can for ie be: 6 6 = Outside diameter of the neck (F). When crimping with hexagon dies neck inscription and die markings must conform

Copper tube lugs for the Nordic market. For stranded wires (class 5 and Class 6). Material: 99.9% pure copper Surface: > 4µ Sn Inscriptions on the lugs palm can for ie be: F35-12 F = KRF // 35 = 35 mm² wire // 12 = M12 stud size. Inscriptions on the lugs neck can for ie be: 13 13 = Outside diameter of the neck (F). When crimping with hexagon dies neck inscription and die markings must conform.

Copper tube lugs for the Nordic market. For stranded wires (class 5 and Class 6). Material: 99.9% pure copper Surface: > 4µ Sn Inscriptions on the lugs palm can for ie be: F35-12 F = KRF // 35 = 35 mm² wire // 12 = M12 stud size. Inscriptions on the lugs neck can for ie be: 13 13 = Outside diameter of the neck (F). When crimping with hexagon dies neck inscription and die markings must conform.

Copper tube lugs for the Nordic market. Copper tube lugs for stranded (class 5) and solid wires (class 2). Material: 99.9% pure copper Surface: > 4µ Sn Inscriptions on the lugs palm can for ie be: n35-12T n = nemiq // 35 = 35 mm² wire // 12 = M12 stud size // T = KRT Inscriptions on the lugs neck can for ie be: 12 12 = Outside diameter of the neck (OD). When crimping with hexagon dies neck inscription and die markings must conform.

Meets the measure requirements according to DIN 46235. Copper tube lugs for stranded (class 5 and class 6) and solid wires (class 2). Material: 99.9% pure copper Surface: > 4µ Sn Inscriptions on the lugs neck can for ie be: 12 12 = Outside diameter of the neck (F). When crimping with hexagon dies neck inscription and die markings must conform.

Cable lugs according to DIN 46235. Suitable for multi-stranded conductors (class 2 and class 5). Material: 99.9% pure Cu Surface: > 4µ Sn Marking on the flat of the tube cable lug can be, for example: n35-12DIN n = Nemiq // 35 = 35 mm² cable // 12 = M12 hole // DIN = DIN46235 Marking is found on the neck of the cable lug as an indication of how they should be crimped.

Copper tube lugs for stranded cable. (Class 2) Material: 99.9% pure copper Surface: > 4µ Sn Inscriptions on the lugs palm can for ie be: n35-12D n = nemiq // 35 = 35 mm² wire // 12 = M12 stud size // D = KRD Inscriptions on the lugs neck can for ie be: 11 11 = Outside diameter of the neck (OD). When crimping with hexagon dies neck inscription and die markings must conform.

Copper tube lugs for the Nordic market. For stranded wires. Material: 99.9% pure copper Surface: > 5µ Ni Inscriptions on the lugs palm can for ie be: n35-12F n = Nemiq // 35 = 35 mm² wire // 12 = M12 stud size // F = KRF Inscriptions on the lugs neck can for ie be: 13 13 = Outside diameter of the neck (F). When crimping with hexagon dies neck inscription and die markings must conform.

Isolationsmuff för förmontage. Material: Polyeten Färg: Natur eller svart, röd på förfrågan Längd: 24 mm UL standard: UL310 Flamskyddsbeständighet: klass V2 Passar till: Flatstifthylsor 6.3 mm, kabelhål 3.3 mm diameter

Content: 1000 pcs 0.25 mm² 1000 pcs 0.34 mm² 1000 pcs 0.5 mm² 500 pcs 0.75 mm² 500 pcs 1.0 mm² ST 23 B has tin plating and ST 23 BS has silver plating.

ISO 263 Isolationsmuff för eftermontage. Material: Polyeten Färg: Natur Passar till: Flaggkabelskor typ FLB, FLBF, FLV 6.3 mm

ISO 26 Isolationsmuff för förmontage. Material: Polyeten Färg: Natur Passar till: Flatstifthylsor 6.3 mm, kabelhål 5.4 x 3.5 mm Längd: 22 mm

ISO 041 Isolationsmuff för eftermontage. Material: Nylon Färg: Natur Passar till: Flatstifthylsor med nabb 4.8 mm

ISO 04 Isolationsmuff för förmontage. Material: Polyeten Färg: Natur Passar till: Flatstifthylsor 4.8 mm

ISO 03 Isolationsmuff för förmontage. Material: Polyeten Färg: Natur Passar till: Flatstifthylsor 2.8 mm

The end-sleeves has silver plating. Content: 200 st 4.0 mm² 100 st 6.0 mm² 70 st 10.0 mm² 70 st 16.0 mm²

PVC-tape Dimensions 15 x 10 mm Thickness: 0.2 mm

Electrical tape made of soft PVC. Impact strength 10.000 V. Lowest installation temperature -10° C Used at electrical installations, jointing cables, tubes etc. Dimension: 19 mm x 20 m

Electrical tape made of soft PVC. Excellent resistance against UV-lightning, acids and moist. Self-extinguising. Impact strength 6.000 V Lowest installation temperature: -10° C Used at electrical installtions for insulation, jointing of cables, tubes etc. Dimension: 19 mm x 20 m

Holder for shrink hose boxes.Can be mounted directly on the wall. Ideal for workshops and service cars. Following boxes fits: NAB, KSB, HSB, PKGB mm. Width: According to below table.Height: 200mmDebth: 175mmMaterial thickness: 1.2mm

All-Weather Tape in soft PVC. Used in electrical installations for insulation, jointing, and wrapping of cables, etc. Effective in low temperatures (-18°C to 105°C). Dimensions: 19 mm x 20 m Thickness: 0.175 mm Elongation: 100% Adhesion: 0.45 kg/25 mm Dielectric Strength: 7 kV Approved according to: UL, CSA, IEC-60454-3-1-7, VDE Type 7 certified.

Nemiq Silver Tape is a strong and durable tape that is easy to tear in both directions. The tape is waterproof and has excellent adhesion on tough surfaces. Technical data: Carrier: Polyethylene-coated fabric Adhesive: Natural rubber-based (may leave adhesive residue) Total thickness: 0.30 mm Max temperature (30 min): 60°C Mesh: 80 per square inch Adhesion to steel: 13 N/25 mm Tensile strength: 183 N/25 mm
