- Total: 10
NGBTO CC85
NGBTO CC85_VP
A Battery Cable cutter with cutting up to 85 mm Cu and Al cable.The blade is connected to a power of 78,4kN. The head is angular for to facilitate work from different angles.
NGBTO CC85 is delivered in a plastic case with battery (18.0VDC.2.0Ah), battery charger and shoulder strap.
- Grip design:
- 2-components
- With impact protection:
- No
- Suitable for steel wire braiding:
- No
- Replaceable cutting head:
- Yes
- Cutting jaws exchangeable:
- Yes
- With strip function:
- No
- Insulated:
- Yes
- Suitable for solid cores:
- Yes
- Suitable for stranded conductors:
- Yes
- Suitable for fine strand conductors:
- Yes
- Construction/operation:
- Accumulator-hydraulic
- Isolation protection 1000 V:
- No
- With spring:
- N/A
- VDE tested:
- No
NGBT CC85
NGBT CC85_VP
A Battery Cable cutter with cutting up to 85 mm Cu and Al cable.The blade is connected to a power of 56kN.
The head is angular for to facilitate work from different angles.
The machine is delivered in a plastic case with battery, battery charger and shoulder strap.
- Grip design:
- 2-components
- With impact protection:
- No
- Suitable for steel wire braiding:
- No
- Replaceable cutting head:
- Yes
- Cutting jaws exchangeable:
- Yes
- With strip function:
- No
- Insulated:
- Yes
- Suitable for solid cores:
- Yes
- Suitable for stranded conductors:
- Yes
- Suitable for fine strand conductors:
- Yes
- Construction/operation:
- Accumulator-hydraulic
- Isolation protection 1000 V:
- No
- With spring:
- N/A
- VDE tested:
- No
NBCC 54SW
NBCC 54SW_VP
Battery Cable Cutter for copper, aluminum and ACSR-cable.Chargable battery and charger is includedDelivered in high quality bagbattery type: Se below
Cutting capacity:Max. cable diameter (YD), incl insulation: 54 mmSingle core: 325 mm2 (31 mm YD).Multi corel: 3 x 150 mm2 (47 mm YD).ACSR: 120 mm2 (18.6 mm YD), ACSR Steel core smaller than 2 mm in diameter.hard aluminium: 400 mm2 (31.9 mm YD).Soft copper cable: 500 mm2 (35 mm YD).hard copper cable: 150 mm2 (21 mm YD).
Length: 326 mmWeight: 3 kg
- Grip design:
- 2-components
- With impact protection:
- No
- Suitable for steel wire braiding:
- Yes
- Replaceable cutting head:
- Yes
- Cutting jaws exchangeable:
- Yes
- With strip function:
- No
- Insulated:
- Yes
- Suitable for solid cores:
- Yes
- Suitable for stranded conductors:
- Yes
- Suitable for fine strand conductors:
- Yes
- Construction/operation:
- Accumulator-hydraulic
- Isolation protection 1000 V:
- No
- With spring:
- N/A
- VDE tested:
- No
Batteridrivet multiverktyg
NMBT MAT_VP
Battery tool for multiple applications with interchangeable heads. The battery tool is sold as one article no. The accessories are sold as separate items so there is no need to invest in applications not needed for the end user.
Tool can be used for following applications- Hole punch head for 19.1mm rod. MAT PH- DIN-Rail cutter. MAT DRC- Cutter for threaded bolt. MAT TR- Head for crimp dies. MAT NH- Cable cutter for Aluminum, Copper & ACSR-cable. MAT CC
MAT ADAPTER is needed to fit MAT TR and MAT CC.
The Tool comes in a plastic case together with a Li-Ion battery and a charger from Bosch.
Pressure: 700barForce: 6.7 tonLength: 410mmWeight: 3.9kg
- Grip design:
- Other
- With impact protection:
- No
- With locking device (for mechanical tools):
- No
- Inserts exchangeable:
- Yes
- Number of included inserts:
- 0 .
- With automatic return:
- No
- Cycle time:
- 5 s
- Compression force:
- 67 kN
- Suitable for:
- Various applications
- Suitable for steel wire braiding:
- Yes, No
- Replaceable cutting head:
- Yes
- Cutting jaws exchangeable:
- Yes
- With strip function:
- No
- Insulated:
- No
- Suitable for solid cores:
- Yes
- Suitable for stranded conductors:
- Yes
- Suitable for fine strand conductors:
- Yes
- Construction/operation:
- Accumulator-hydraulic
- For component:
- Non-insulated Cu tube and sheet terminals
- Isolation protection 1000 V:
- No
- With spring:
- N/A
- Compression shape:
- Universal (exchangeable inserts)
- VDE tested:
- No
NBCC 65
NBCC 65_VP
Battery Cable Cutter for copper and aluminium cable.Chargable battery and charger is included.Delivered in high quality bag.Battery type: Se below
Cutting capacity:Max. cable diameter (YD), incl insulation: 65 mmSingle core: 500 mm2 (45 mm YD).Multi corel: 3 x 150 mm2 (47 mm YD).Soft copper cable: 500 mm2 (35 mm YD)Hard copper cable: 150 mm2 (21 mm YD)
Length: 340 mmWeight: 3 kg
- Grip design:
- 2-components
- With impact protection:
- No
- Suitable for steel wire braiding:
- No
- Replaceable cutting head:
- Yes
- Cutting jaws exchangeable:
- Yes
- With strip function:
- No
- Insulated:
- Yes
- Suitable for solid cores:
- Yes
- Suitable for stranded conductors:
- Yes
- Suitable for fine strand conductors:
- Yes
- Construction/operation:
- Accumulator-hydraulic
- Isolation protection 1000 V:
- No
- With spring:
- N/A
- VDE tested:
- No
NBCC 50
NBCC 50_VP
Battery Cable Cutter for copper and aluminium cable.Chargable battery and charger is includedDelivered in high quality bagbattery type: Se belowCutting capacity:
Max. cable diameter (YD), incl insulation: 50 mmSingle core: 325 mm2 (31 mm YD).Multi core: 3 x 150 mm2 (47 mm YD).Soft copper cable: 500 mm2 (35 mm YD)Hard copper cable: 150 mm2 (21 mm YD)Length: 313 mmWeight: 2.4 kg
- Grip design:
- 2-components
- With impact protection:
- No
- Suitable for steel wire braiding:
- No
- Replaceable cutting head:
- Yes
- Cutting jaws exchangeable:
- Yes
- With strip function:
- No
- Insulated:
- Yes
- Suitable for solid cores:
- Yes
- Suitable for stranded conductors:
- Yes
- Suitable for fine strand conductors:
- Yes
- Construction/operation:
- Accumulator-hydraulic
- Isolation protection 1000 V:
- No
- With spring:
- N/A
- VDE tested:
- No
Multifunctional Battery Operated Tool: NGB2
NGB2_vp
Tool for efficiency and flexibility in a wide range of tasks. Our battery-powered tool is designed to be adaptable with various heads, allowing you to handle multiple work areas with a single device. Switch between different heads to perform tasks ranging from hexagonal crimping of cable lugs from 16-400 mm² Cu & 16-300 mm² Al with the HX400, to a powerful cable cutter that cuts up to 45 mm Cu and 40 mm ACSR with the CC40. For convenience, we sell both the machine and the heads separately as well as complete machines, enabling you to purchase according to your needs.
NGB2 Usage Areas:
HX400 - Seamless hexagonal crimping for cable lugs and splice connectors from 16-400 mm² Cu & 16-300 mm² Al.
CC40 - Cable cutter that cuts up to 45 mm Cu and 40 mm ACSR.
- Grip design:
- 2-components, Other
- With impact protection:
- No
- With locking device (for mechanical tools):
- No
- Inserts exchangeable:
- No
- Number of included inserts:
- 1 .
- With automatic return:
- No
- Cycle time:
- 5 s
- Compression force:
- 124.6-125 kN
- Suitable for:
- Cable lugs and connectors
- Replaceable cutting head:
- Yes
- Cutting jaws exchangeable:
- Yes
- With strip function:
- No
- Insulated:
- Yes, No
- Suitable for solid cores:
- Yes
- Suitable for stranded conductors:
- Yes
- Suitable for fine strand conductors:
- No
- Construction/operation:
- Accumulator-hydraulic, Hydraulic cutter head
- Isolation protection 1000 V:
- No
- Compression shape:
- Hexagon
- VDE tested:
- No
HPC Batteridrivna Kabelsaxar
HPC 85R_VP
Robust cable cutter that cuts 65/85mm (see item.no) Cu and Al cables.The cable cutter is battery powered and works with 700 bars of pressure. The head is angular to facilitate work from different directions.
The cutter is delivered in a box with battery (EY 9200 B) and shoulder strap.
Battery charger, EY 0110 B, is not included in the item number but is sold on a separate part number.
- Grip design:
- 2-components
- With impact protection:
- No
- Suitable for steel wire braiding:
- No
- Replaceable cutting head:
- Yes
- Cutting jaws exchangeable:
- Yes
- With strip function:
- No
- Insulated:
- Yes
- Suitable for solid cores:
- Yes
- Suitable for stranded conductors:
- Yes
- Suitable for fine strand conductors:
- Yes
- Construction/operation:
- Accumulator-hydraulic
- Isolation protection 1000 V:
- No
- With spring:
- N/A
- VDE tested:
- No
HPC Batteridrivna Kabelsaxar
HPC 65BRL_VP
Robusta Cable cutter that cuts 65/85mm (see item.no) Cu and Al cables.The cable cutter are battery powered and work with 700 bars of pressure. The head is angular to facilitate work from different directions.
The cutter is delivered in a box with battery and shoulder strap.
Battery charger, EYOL82B is not included in the item number but is sold on a separate part number.
- Grip design:
- 2-components
- With impact protection:
- No
- Suitable for steel wire braiding:
- No
- Replaceable cutting head:
- Yes
- Cutting jaws exchangeable:
- Yes
- With strip function:
- No
- Insulated:
- Yes
- Suitable for solid cores:
- Yes
- Suitable for stranded conductors:
- Yes
- Suitable for fine strand conductors:
- Yes
- Construction/operation:
- Accumulator-hydraulic
- Isolation protection 1000 V:
- No
- With spring:
- N/A
- VDE tested:
- No
35-078
35-078_VP
Cable cutter for copper and aluminium that can be mounted on almost every Drill Driver on the market. Delivered in a solid bag.
Cutting capacity (diameter): 45 mm
- Grip design:
- Other
- With impact protection:
- No
- Suitable for steel wire braiding:
- No
- Replaceable cutting head:
- No
- Cutting jaws exchangeable:
- Yes
- With strip function:
- No
- Insulated:
- No
- Suitable for solid cores:
- Yes
- Suitable for stranded conductors:
- Yes
- Suitable for fine strand conductors:
- Yes
- Construction/operation:
- Accumulator-hydraulic
- Isolation protection 1000 V:
- No
- With spring:
- No
- VDE tested:
- No
- Total: 10
