LSP Downlights 3CCT Runda
Vinklingsbara downlights med mycket hög kvalitetskänsla.
Fungerar för både inomhus och utomhus montage. Downlights med 3CCT (2400K, 2700K och 3000K) som enkelt väljs på kabeln.
Finns i diamter 60 mm, 80 mm & 90 mm.
60 mm ramar har fjädrar och kan monteras i undertak. Hålstorlek 52-54 mm
80 mm ramar har metallvingar och kan monteras i undertak samt i 70 mm dosor. Hålstorlek 52-62 mm 90 mm ramar har metallvingar och kan monteras i undertak samt i 80 mm dosor. Hålstorlek 52-72 mm
1-Pack. Kan kompletteras med drivdon, kablar och kopplingsplintar.
Teknisk data:
Effekt: 4 W
Ljusstyrka: Se nedan tabell
Dimmningsbara: Ja
Ljusvinkel: 60°
Ljustemperatur: Se nedan tabell
IP-klass: IP54
Temperaturområde: -20 till +50C
Livslängd: 70% efter 50.000 h
Spänning: 1-9 V
Ström: 350 mA
Antal LED;ar: 1st
LED: COB, CREE CXA1304-2 STEP
Color Rendering Index(CRI): 90
Optik: Reflektor med prisma framför LED
Glas: Klart
Energiklass: F
Kabel: 100mm AWG22 med brytare samt kontaktdon.
Downlight djup i dosa: Max 25 mm
Finns i vitt, svart eller aluminium utförande.
- Dimmable:
- Yes
- Dimming 0-10 V:
- No
- Dimming 1-10 V:
- No
- Dimming DALI:
- No
- Dimming DSI:
- No
- Dimming DMX:
- No
- Dimming potentiometer (integrated):
- No
- Dimming GPRS:
- No
- Dimming LineSwitch:
- No
- Dimming manufacturer's proprietary system:
- No
- Dimming mains voltage modulation:
- No
- Dimming phase cut-off (trailing edge):
- No
- Dimming phase cut-on (leading edge):
- No
- Dimming programmable:
- No
- Dimming RF:
- No
- Dimming Sine Wave Reduction:
- No
- Dimming Touch and Dim:
- No
- Dimming Zigbee:
- No
- Protection class according to IEC 61140:
- III
- Housing material:
- Aluminium
- Suitable for surface mounting:
- No
- Suitable for built-in mounting:
- Yes
- Suitable for wall mounting:
- No
- Suitable for suspended mounting:
- No
- Suitable for ceiling mounting:
- Yes
- Suitable for traverse mounting:
- No
- Suitable for pedestal/floor mounting:
- No
- Suitable for light-track mounting:
- No
- Suitable for clamp-mounting:
- No
- Suitable for low voltage cable system:
- No
- Adjustability:
- Rotatable, Not adjustable
- With movement sensor:
- No
- With light sensor:
- No
- Lamp type:
- LED not exchangeable
- With light source:
- Yes
- Suitable for number of light sources:
- 1 .
- Lamp holder:
- None
- Housing colour:
- Aluminium, Black, White
- Material cover:
- None
- Surface brushed:
- Yes, No
- Voltage type:
- AC
- Nominal voltage:
- 220-240 V
- Type of control gear:
- LED operating device current-controlled
- With control gear:
- No
- Dimming depending on control gear:
- Yes
- Reflector:
- High-gloss
- Light distributor:
- Reflector
- Light distribution:
- Symmetric
- Beam angle:
- 41-80° - Wide beam
- Light outlet:
- Direct
- Energy efficiency class of the built-in lamp:
- F
- Degree of protection (NEMA):
- Other
- Suitable for lamp power:
- 0 N/A
- Max. system power:
- 4 W
- Colour of light:
- White
- Colour temperature:
- 2400-3000 K
- Colour rendering index CRI:
- 80-89
- Luminous flux:
- 325 lm
- Lamp efficacy:
- 82 lm/W
- Luminous intensity:
- 364 cd
- Number of poles:
- 2 .
- Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24:
- No
- Suitable for workplace according to EN 12464-1:
- No
- Covering of the luminaire with thermally insulating material possible:
- Yes
- Connection type:
- Crimping
- Frame shape:
- Round
- Degree of protection (IP):
- IP54
- Surface protection:
- Other, Powder coating
- Rated luminous flux according to IEC 62722-2-1:
- 325 lm
LSP Downlights 3CCT Kvadratiska
Vinklingsbara downlights med mycket hög kvalitetskänsla.
Fungerar för både inomhus och utomhus montage. Downlights med 3CCT (2400K, 2700K och 3000K) som enkelt väljs på kabeln.
Finns i storlek 60 x 60 mm eller 80 x 80 mm.
60 x 60 mm ramar har fjädrar och kan monteras i undertak. Hålstorlek 52-54 mm
80 x 80 mm ramar har metallvingar och kan monteras i undertak samt i 70 mm dosor. Hålstorlek 52-62 mm
1-Pack. Kan kompletteras med drivdon, kablar och kopplingsplintar.
Teknisk data:
Effekt: 4 W
Ljusstyrka: Se nedan tabell
Dimmningsbara: Ja
Ljusvinkel: 60°
Ljustemperatur: Se nedan tabell
IP-klass: IP54
Temperaturområde: -20 till +50° C
Livslängd: 70% efter 50.000 h
Spänning: 1-9 V
Ström: 350 mA
Antal LED;ar: 1 st
LED: COB, CREE CXA1304-2 STEP
Color Rendering Index(CRI): 90
Optik: Reflektor med prisma framför LED
Glas: Klart
Energiklass: F
Kabel: 100 mm AWG22 med brytare samt kontaktdon.
Downlight djup i dosa: Max 25 mm
Finns i vitt, svart eller aluminium utförande.
- Dimmable:
- Yes
- Dimming 0-10 V:
- No
- Dimming 1-10 V:
- No
- Dimming DALI:
- No
- Dimming DSI:
- No
- Dimming DMX:
- No
- Dimming potentiometer (integrated):
- No
- Dimming GPRS:
- No
- Dimming LineSwitch:
- No
- Dimming manufacturer's proprietary system:
- No
- Dimming mains voltage modulation:
- No
- Dimming phase cut-off (trailing edge):
- No
- Dimming phase cut-on (leading edge):
- No
- Dimming programmable:
- No
- Dimming RF:
- No
- Dimming Sine Wave Reduction:
- No
- Dimming Touch and Dim:
- No
- Dimming Zigbee:
- No
- Protection class according to IEC 61140:
- III
- Housing material:
- Aluminium
- Suitable for surface mounting:
- No
- Suitable for built-in mounting:
- Yes
- Suitable for wall mounting:
- No
- Suitable for suspended mounting:
- No
- Suitable for ceiling mounting:
- Yes
- Suitable for traverse mounting:
- No
- Suitable for pedestal/floor mounting:
- No
- Suitable for light-track mounting:
- No
- Suitable for clamp-mounting:
- No
- Suitable for low voltage cable system:
- No
- Adjustability:
- Rotatable
- With movement sensor:
- No
- With light sensor:
- No
- Lamp type:
- LED not exchangeable
- With light source:
- Yes
- Suitable for number of light sources:
- 1 .
- Lamp holder:
- None
- Housing colour:
- Aluminium, Black, White
- Material cover:
- None
- Surface brushed:
- Yes, No
- Voltage type:
- AC
- Nominal voltage:
- 220-240 V
- Type of control gear:
- LED operating device current-controlled
- With control gear:
- No
- Dimming depending on control gear:
- Yes
- Reflector:
- High-gloss
- Light distributor:
- Reflector
- Light distribution:
- Symmetric
- Beam angle:
- 41-80° - Wide beam
- Light outlet:
- Direct
- Energy efficiency class of the built-in lamp:
- F
- Degree of protection (NEMA):
- Other
- Suitable for lamp power:
- 0 N/A
- Max. system power:
- 4 W
- Colour of light:
- White
- Colour temperature:
- 2400-3000 K
- Colour rendering index CRI:
- 80-89
- Luminous flux:
- 325 lm
- Lamp efficacy:
- 82 lm/W
- Luminous intensity:
- 364 cd
- Number of poles:
- 2 .
- Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24:
- No
- Suitable for workplace according to EN 12464-1:
- No
- Covering of the luminaire with thermally insulating material possible:
- Yes
- Connection type:
- Crimping
- Degree of protection (IP):
- IP54
- Surface protection:
- Other, Powder coating
- Rated luminous flux according to IEC 62722-2-1:
- 325 lm
LSP Downlights 3CCT Runda 3-Pack
These downlights can be tilted, only use high quality components and has a premium feeling.Works for both indoor and outdoor use.
Available with diameter 60 mm, 80 mm and 90 mm.
60 mm frames have springs and can be mounted in ceiling.Hole size: 52-54 mm.
80mm frames have metal wings and can be mounted in ceiling as well as in 70mm junction boxes. Hole size: 52-62 mm.
90 mm frames have metal wings and can be mounted in ceiling as well as in 80mm junction boxes.Hole size: 52-72mm.3-pack. Can be supplemented with drivers, cables and connectors.
Technical data:
Power: 3.3W
Lumen: See below.
Dimmable: Yes
Light beam spread: 60°
Color temp: See below.
IP rating: IP54
Temp. Range: -20°C to +50°C
Life-span: 70% after 50.000h
Voltage: 1-10V
Amperage: 350mA
Amount of LED’s: 3pcs
Type of LED: COB, CREE CXA1304-2 STEP
CRI: RA90
Optics: Reflector with a prism in front of the LED.
Glass: Clear
Energy rating: A++
Cable: 100 mm AWG22 with connector.
Size: Depth = 50 mm, Height = 60 mm
Downlight depth in box: Max 25 mm
Available in white, black or aluminum color.
- Dimmable:
- Yes
- Dimming 0-10 V:
- No
- Dimming 1-10 V:
- No
- Dimming DALI:
- No
- Dimming DSI:
- No
- Dimming DMX:
- No
- Dimming potentiometer (integrated):
- No
- Dimming GPRS:
- No
- Dimming LineSwitch:
- No
- Dimming manufacturer's proprietary system:
- No
- Dimming mains voltage modulation:
- No
- Dimming phase cut-off (trailing edge):
- No
- Dimming phase cut-on (leading edge):
- No
- Dimming programmable:
- No
- Dimming RF:
- No
- Dimming Sine Wave Reduction:
- No
- Dimming Touch and Dim:
- No
- Dimming Zigbee:
- No
- Protection class according to IEC 61140:
- III
- Housing material:
- Aluminium
- Suitable for surface mounting:
- No
- Suitable for built-in mounting:
- Yes
- Suitable for wall mounting:
- No
- Suitable for suspended mounting:
- No
- Suitable for ceiling mounting:
- Yes
- Suitable for traverse mounting:
- No
- Suitable for pedestal/floor mounting:
- No
- Suitable for light-track mounting:
- No
- Suitable for clamp-mounting:
- No
- Suitable for low voltage cable system:
- No
- Adjustability:
- Rotatable
- With movement sensor:
- No
- With light sensor:
- No
- Lamp type:
- LED not exchangeable
- With light source:
- Yes
- Suitable for number of light sources:
- 1 .
- Lamp holder:
- None
- Housing colour:
- Aluminium, Black, White
- Material cover:
- None
- Surface brushed:
- Yes, No
- Voltage type:
- AC
- Nominal voltage:
- 220-240 V
- Type of control gear:
- LED operating device current-controlled
- With control gear:
- No
- Dimming depending on control gear:
- Yes
- Reflector:
- High-gloss
- Light distributor:
- Reflector
- Light distribution:
- Symmetric
- Beam angle:
- 41-80° - Wide beam
- Light outlet:
- Direct
- Energy efficiency class of the built-in lamp:
- F
- Degree of protection (NEMA):
- Other
- Suitable for lamp power:
- 0 N/A
- Max. system power:
- 4 W
- Colour of light:
- White
- Colour temperature:
- 2400-3000 K
- Colour rendering index CRI:
- 80-89
- Luminous flux:
- 325 lm
- Lamp efficacy:
- 82 lm/W
- Luminous intensity:
- 364 cd
- Number of poles:
- 2 .
- Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24:
- No
- Suitable for workplace according to EN 12464-1:
- No
- Covering of the luminaire with thermally insulating material possible:
- Yes
- Connection type:
- Crimping
- Frame shape:
- Round
- Degree of protection (IP):
- IP54
- Surface protection:
- Other, Powder coating
- Rated luminous flux according to IEC 62722-2-1:
- 325 lm
MSP Downlight 3CCT
A very powerful LED in frame which can tilt. The optic angle can be changed by switching between included reflectors. Honey comb is included to reduce blinding.
Delivered in a complete kit including spotlight, frame, driver, three different reflectors, 15°, 25° and 35° and honey comb.
Available in white, black or aluminum color.
Technical data:
Power: 9W
Lumen: See below.
Dimmable: Yes
Light beam spread: See below.
Color temp: See below.
IP rating: IP20
Temp. Range: -10°C to +50°C
Life-span: 70% after 50.000 h
Amperage: 350 mA (constant)
Amount of LED’s: 1 pcs
Type of LED: COB, CREECRI: 90
Optics: Reflector with a prism in front of the LED.
Energy rating: A++
Cable: 400mm AWG20
Size: Diameter = 93 mm, Depth = 65 mm
Installation: In holes sized 78-88 mm.
Springs with rubber protection. Parallel connector can be used if 9W is too powerful. Can be driven at 50% or 33% of full performance if 1 or 2 extra downlights are installed with parallel connector using the same driver.
Recommended drivers: LDD185 = 1 spotlight. Included in the kit.
- Dimmable:
- Yes
- Dimming 0-10 V:
- No
- Dimming 1-10 V:
- No
- Dimming DALI:
- No
- Dimming DSI:
- No
- Dimming DMX:
- No
- Dimming potentiometer (integrated):
- No
- Dimming GPRS:
- No
- Dimming LineSwitch:
- No
- Dimming manufacturer's proprietary system:
- No
- Dimming mains voltage modulation:
- No
- Dimming phase cut-off (trailing edge):
- Yes
- Dimming phase cut-on (leading edge):
- Yes
- Dimming programmable:
- No
- Dimming RF:
- No
- Dimming Sine Wave Reduction:
- No
- Dimming Touch and Dim:
- No
- Dimming Zigbee:
- No
- Protection class according to IEC 61140:
- III
- Housing material:
- Aluminium
- Suitable for surface mounting:
- No
- Suitable for built-in mounting:
- Yes
- Suitable for wall mounting:
- No
- Suitable for suspended mounting:
- No
- Suitable for ceiling mounting:
- Yes
- Suitable for traverse mounting:
- No
- Suitable for pedestal/floor mounting:
- No
- Suitable for light-track mounting:
- No
- Suitable for clamp-mounting:
- No
- Suitable for low voltage cable system:
- No
- Adjustability:
- Rotatable
- With movement sensor:
- No
- With light sensor:
- No
- Lamp type:
- LED not exchangeable
- With light source:
- Yes
- Suitable for number of light sources:
- 1 .
- Lamp holder:
- None
- Housing colour:
- Aluminium, Black, White
- Material cover:
- None
- Surface brushed:
- Yes, No
- Voltage type:
- AC
- Nominal voltage:
- 220-240 V
- Type of control gear:
- LED operating device current-controlled
- With control gear:
- Yes
- Dimming depending on control gear:
- Yes
- Reflector:
- High-gloss
- Light distributor:
- Reflector
- Light distribution:
- Symmetric
- Beam angle:
- Variable beam angle
- Light outlet:
- Direct
- Energy efficiency class of the built-in lamp:
- F
- Degree of protection (NEMA):
- Other
- Suitable for lamp power:
- 0 N/A
- Max. system power:
- 9 W
- Colour of light:
- White
- Colour temperature:
- 2400-3000 K
- Colour rendering index CRI:
- 90-100
- Luminous flux:
- 863 lm
- Lamp efficacy:
- 90 lm/W
- Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24:
- No
- Suitable for workplace according to EN 12464-1:
- No
- Covering of the luminaire with thermally insulating material possible:
- Yes
- Connection type:
- Crimping
- Frame shape:
- Round
- Degree of protection (IP):
- IP20
- Surface protection:
- Other, Powder coating
- Rated luminous flux according to IEC 62722-2-1:
- 863 lm
LED Spotlight LSP-Serien i butiksförpackning
Small downlights which can be put in different sized frames. There are frames for different applications, they can be round, square or rectangular. These downlights can be tilted, only use high quality components and has a premium feeling.Works for both indoor and outdoor use.Technical data:Power: 3.3WLumen: See below.Dimmable: YesLight beam spread: 60°Color temp: See below.IP rating: IP54Temp. Range: -20°C to +50°CLife-span: 70% after 50.000hVoltage: 1-10VCurrent: Constant 350mAAmount of LED’s: 1pcsType of LED: COB, CREE CXA1304-2 STEPCRI: RA90Optics: Reflector with a prism in front of the LED.Glass: ClearEnergy rating: A++Cable: 100mm AWG22 with connector.Size: Depth=50mm, Height=60mmAvailable in white, black or aluminum color.
- Dimmable:
- Yes
- Dimming 0-10 V:
- No
- Dimming 1-10 V:
- No
- Dimming DALI:
- No
- Dimming DSI:
- No
- Dimming DMX:
- No
- Dimming potentiometer (integrated):
- No
- Dimming GPRS:
- No
- Dimming LineSwitch:
- No
- Dimming manufacturer's proprietary system:
- No
- Dimming mains voltage modulation:
- No
- Dimming phase cut-off (trailing edge):
- No
- Dimming phase cut-on (leading edge):
- No
- Dimming programmable:
- No
- Dimming RF:
- No
- Dimming Sine Wave Reduction:
- No
- Dimming Touch and Dim:
- No
- Dimming Zigbee:
- No
- Protection class according to IEC 61140:
- III
- Housing material:
- Aluminium
- Suitable for surface mounting:
- No
- Suitable for built-in mounting:
- Yes
- Suitable for wall mounting:
- No
- Suitable for suspended mounting:
- No
- Suitable for ceiling mounting:
- Yes
- Suitable for traverse mounting:
- No
- Suitable for pedestal/floor mounting:
- No
- Suitable for light-track mounting:
- No
- Suitable for clamp-mounting:
- No
- Suitable for low voltage cable system:
- No
- Adjustability:
- Rotatable
- With movement sensor:
- No
- With light sensor:
- No
- Lamp type:
- LED not exchangeable
- With light source:
- Yes
- Suitable for number of light sources:
- 1 .
- Lamp holder:
- None
- Housing colour:
- Aluminium, Black, White
- Material cover:
- None
- Surface brushed:
- Yes, No
- Voltage type:
- AC
- Nominal voltage:
- 220-240 V
- Type of control gear:
- LED operating device current-controlled
- With control gear:
- No
- Dimming depending on control gear:
- Yes
- Reflector:
- High-gloss
- Light distributor:
- Reflector
- Light distribution:
- Symmetric
- Beam angle:
- 41-80° - Wide beam
- Light outlet:
- Direct
- Energy efficiency class of the built-in lamp:
- A++, A+, A (LED)
- Degree of protection (NEMA):
- Other
- Suitable for lamp power:
- 0 N/A
- Max. system power:
- 3.3 W
- Colour of light:
- White
- Colour temperature:
- 2700 K
- Colour rendering index CRI:
- 90-100
- Luminous flux:
- 310 lm
- Lamp efficacy:
- 94 lm/W
- Luminous intensity:
- 368 cd
- Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24:
- No
- Suitable for workplace according to EN 12464-1:
- No
- Covering of the luminaire with thermally insulating material possible:
- Yes
- Connection type:
- Crimping
- Frame shape:
- Round
- Degree of protection (IP):
- IP54
- Surface protection:
- Other, Powder coating
- Rated luminous flux according to IEC 62722-2-1:
- 310 lm
LSC Förlängningskablar
Extension cables in different lengths.Used for when connectors or drivers can’t be placed adjacent to LED.
High Bay Ufo - OnOff
Armaturer för lager, industrier, garage, idrottshallar mm. Armaturen är helt nyutvecklad och i mycket kompakt storlek, perfekt för moderna byggnader där mycket installationer som sprinkler, värmeelement, elstegar mm skall få plats.
Dioder: Seoul
Prestanda: 160 lm / W
Effekt: 60-200 W
Dimbar: Nej
CRI: RA80
IP-klass: IP65
Ljusvinkel: 120° standard. 60° / 90° vid förfrågan.
Drivdon: Av / På
Ljustemperatur: 3500-4500 K (Standard), övriga på förfrågan.
Garanti: 5 år
High Bay Sport
High Bay Sports är armaturerna som klarar de högt ställda belysningskraven för racketsporter som Padel och Tennis, där bra och jämnt ljus är viktigt för utövningen. Beroende på setup klarar High Bay Sports både standarden från Svenska Idrottsförbundet eller Europeisk standard för nationellt och internationellt tävlingsspel*.
Installation underlättas av ljusvinkelmarkörer/gradskalor på armaturens väggfäste.
Armaturens gedigna konstruktion och kraftiga belysning gör den även lämplig för andra offentliga utrymmen såsom parkeringsgarage/platser, byggnader, bensinstationer osv.
Dioder: Nichia
Prestanda: 140lm/W
Effekt: 100W/150W
Dimbar: Ja
CRI: RA80
IP-klass: IP65
Ljusvinkel: 60x9°
Drivdon: 1-10V
Ljustemperatur: 4000K
Garanti: 5 år
High Bay Linear - OnOff
Luminaires for industrial use, garages, warehouses, gymnasiums etc. The oblong design makes this product very appropriate for being mounted between shelves and in aisles for forklifts.
Technical data:
Diodes: Nichia
Performance: 140 lm / W
Power: 50-240 W. Can be mounted in double rows for 240-480 W.
Dimmable: Yes
CRI: RA80
IP rating: IP65
Light beam spread: 80 x 40° or 130 x 55°. See below.
Driver: On/Off, 0-10 V or Dali. See below.
Color temp: 3500-4500 K (Standard), other color temperatures per customer request.
Warranty: 5 years.
Options: Can be mounted with different types of holders, chains, motion detectors, light sensors etc.
KOPPLINGSPLINTAR LED - S 3050 - Konsumentförpackning
Seriekoppling för LED.
IDC 3 x 2 polig, 0.34-0.5 mm² (IN, LED, OUT)
Kontakt: Tennplätterad brons
Material: Polyamid (Nylon, PA 6.6)
Montering: M3.5 eller limning
Spänning: 150V, EN60598-1
Ström: 6A (0.5 mm²) resp. 5A (0.34 mm²) vid temp 60° C
Temperatur: 100° C (kontinuerlig arbetstemp) 160° C (korttidstemp)
Färg: Ljusgrå
Brandklass: UL94 V-2
Skyddsklass: IP20
- Number of poles:
- 2 .
- Type of electrical connection 1:
- Insulation displacement connection
- Type of electrical connection 2:
- Insulation displacement connection
LED List COB 24VDC, IP20
Enkel installation med dubbelhäftande 3M tejp på baksidan.
Teknisk data:
Effekt: 8 W/m
Längd: 5 m
Bredd: 4 mm
Klippintervall: 62,5mm
Ljustemperatur: 2700KIP20
Lumen: 744 LM/m, 93 LM/W
Spänning: 24V DC
Ström: 333mA/m
Color Rendering Index(CRI): 90+
Energiklass: A++
Minimum bockningsradie: ≥50 mm
TUV-CE, UL, RoHs
- Max. system power:
- 40 W
- Colour temperature:
- 2700 K
- Number of poles:
- 2 .
- Lamp power per meter:
- 8 W
- Lamp power per foot:
- 2.439 W
- Luminous flux per meter:
- 93 lm
- Lamp voltage:
- 24 V
LED Strip SMD 24DC IP65 1100LM
Enkel installation med dubbelhäftande 3M tejp på baksidan.
Teknisk data:
Effekt: 14,4 W/m
Längd: 5 m
Bredd: 8 mm
Klippintervall: 33mm
Ljustemperatur: 3000K
IP65
Lumen: 1100 LM/m, 76 LM/W
Spänning: 24V DC
LED/m: 180
Color Rendering Index(CRI): 90+
Energiklass: A++
CE, UL, RoHs
- Max. system power:
- 72 W
- Colour temperature:
- 2700 K
- Number of poles:
- 2 .
- Lamp power per meter:
- 14.4 W
- Lamp power per foot:
- 4.39 W
- Luminous flux per meter:
- 76 lm
- Lamp voltage:
- 24 V
Rektangulära ramar LSP-Serien i butiksförpackning
Frames for 2 or 3 LED downlights.Installation:4 springs.2 downlights 60 x 115 mm frame. Hole size: 52x99 mm.3 downlights 60 x 170 mm frame. Hole size: 52x146 mm.Available in white, black or aluminum color.
- Housing material:
- Aluminium
- Suitable for suspended mounting:
- No
- Suitable for ceiling mounting:
- Yes
- Suitable for traverse mounting:
- No
- Suitable for pedestal/floor mounting:
- No
- Suitable for light-track mounting:
- No
- Suitable for clamp-mounting:
- No
- Suitable for number of light sources:
- 2-3 .
- Housing colour:
- Aluminium, Black, White
- Surface brushed:
- Yes, No
- Type of accessory/spare part:
- Cover
- Frame shape:
- Rectangular
- Transparent:
- No
- Colour:
- Black, White, Aluminium
- Surface protection:
- Other, Powder coating
- Material:
- Aluminium
- Accessory:
- Yes
- Spare part:
- No
Runda ramar för LSP-Serien i butiksförpackning
Frames with an outer diameter of 60mm, 80mm or 90mm.Installation:60x60mm frames have springs and can be mounted in recessed ceiling.Hole size: 52-54mm80mm frames have metal wings and can be mounted in ceiling as well as in 70mm junction boxes.Hole size: 52-62mm.90mm frames have metal wings and can be mounted in ceiling as well as in 80mm junction boxes.Hole size: 52-72mm.Available in white, black or aluminum color.
- Housing material:
- Aluminium
- Suitable for suspended mounting:
- No
- Suitable for ceiling mounting:
- Yes
- Suitable for traverse mounting:
- No
- Suitable for pedestal/floor mounting:
- No
- Suitable for light-track mounting:
- No
- Suitable for clamp-mounting:
- No
- Suitable for number of light sources:
- 1 .
- Housing colour:
- Aluminium, Black, White
- Surface brushed:
- Yes, No
- Type of accessory/spare part:
- Cover
- Frame shape:
- Round
- Transparent:
- No
- Colour:
- Black, White, Aluminium
- Surface protection:
- Other, Powder coating
- Material:
- Aluminium
- Accessory:
- Yes
- Spare part:
- No
Runda ramar för MSP-Serien
Tiltable frames with an outer diameter of 93mm.Installation:Springs.Hole size: 78-88mmAvailable in white, black or aluminum color.
- Housing material:
- Aluminium
- Suitable for suspended mounting:
- No
- Suitable for ceiling mounting:
- Yes
- Suitable for traverse mounting:
- No
- Suitable for pedestal/floor mounting:
- No
- Suitable for light-track mounting:
- No
- Suitable for clamp-mounting:
- No
- Housing colour:
- Aluminium, Black, White
- Surface brushed:
- Yes, No
- Type of accessory/spare part:
- Cover
- Transparent:
- No
- Colour:
- Black, White, Aluminium
- Surface protection:
- Other, Powder coating
- Material:
- Aluminium
- Accessory:
- Yes
- Spare part:
- No
Kvadratiska ramar för LSP-Serien i butiksförpackning
Frames in sizes 60x60mm or 80x80mm.Installation:60x60mm frames have springs and can be mounted in recessed ceiling.Hole size: 52-54mm80mm frames have metal wings and can be mounted in ceiling as well as in 70mm junction boxes.Hole size: 52-62mm.Available in white, black or aluminum color.
- Housing material:
- Aluminium
- Suitable for suspended mounting:
- No
- Suitable for ceiling mounting:
- Yes
- Suitable for traverse mounting:
- No
- Suitable for pedestal/floor mounting:
- No
- Suitable for light-track mounting:
- No
- Suitable for clamp-mounting:
- No
- Suitable for number of light sources:
- 1 .
- Housing colour:
- Aluminium, Black, White
- Surface brushed:
- Yes, No
- Type of accessory/spare part:
- Cover
- Frame shape:
- Square
- Transparent:
- No
- Colour:
- Black, White, Aluminium
- Surface protection:
- Other, Powder coating
- Material:
- Aluminium
- Accessory:
- Yes
- Spare part:
- No
LED ARMATUR 60x60mm
LED Luminaires for pendant installation or surface mount to the ceiling.
Technical data:
Length: See below.
Height: 60 mm
Width: 60 mm
Color temp: See below.
Efficacy: Approx. 100lm/W, See below.
Life-span: 50.000h
Light beam spread: 110°
Voltage: 110-250VAC
Type of LED: SMD 2835 LED
Power: See below.
Dimmable: Yes
CRI: RA80
Lens: PMMA
Energy rating: A++
On/Off delay: <1s
IP rating: IP20
Driver: On/Off, 0-10V or Dali. See below.
Warranty: 3 years.
- Dimming 0-10 V:
- Yes
- Dimming DALI:
- Yes
- Suitable for suspended mounting:
- Yes
- Suitable for ceiling mounting:
- Yes
- Lamp type:
- LED not exchangeable
- With light source:
- Yes
- Housing colour:
- Grey
- Voltage type:
- AC
- Nominal voltage:
- 110-250 V
- With control gear:
- Yes
- Light distribution:
- Symmetric
- Rated life time L70/B50 at 25 °C:
- 50000 h
- Max. system power:
- 28-50 W
- Colour temperature:
- 3000 K
- Colour rendering index CRI:
- 80-89
- Luminaire efficacy:
- 100 lm/W
- Degree of protection (IP):
- IP20
- Rated luminous flux according to IEC 62722-2-1:
- 2900-4900 lm
Dimbart drivdon konstant spänning
Drivers for LED StripsTechnical data:Voltage: 220-240 VACFrequency: 50-60 HzSize (LxWxH): 135x45x32mmTemp. Range: -20°C to +50°CIP rating: IP65Dimming: Leading Edge & TRIACIP rating: IP65
Installation:Cables for both input and output are 150mm, 1.5mm2.Suitable to be installed on top of suspended ceilings, inside lockers etc.See accessories below for appropriate connector.
- Suitable for outdoor use:
- Yes
- Dimming phase cut-off (trailing edge):
- Yes
- Dimming phase cut-on (leading edge):
- Yes
- Housing:
- Plastic housing
- Suitable for constant current:
- No
- Suitable for constant voltage:
- Yes
- Output voltage:
- 24 V
- Output current:
- 0-3200 mA
- Output power:
- 0-75 W
- Protection class according to IEC 61140:
- III
- Degree of protection (IP):
- IP65
- Model:
- Dynamic
Utomhusbelysning för väggmontage
WOT är armaturerna för utomhusbelysning med högt ställda belysningskrav. Armaturens gedigna konstruktion och kraftiga belysning gör den lämplig för offentliga utrymmen såsom parkeringsplatser/garage, byggnader, bensinstationer marinor, uppställningsplatser m.m.
Installation underlättas av ljusvinkelmarkörer/gradskalor på armaturens väggfäste.
Dioder: Nichia
Prestanda: 140 lm / W
Effekt: 100 W / 150 W
Dimbar: Ja
CRI: RA75
IP-klass: IP65
Ljusvinkel: 60° x 90°
Drivdon: 1-10 V
Ljustemperatur: 4000 K
Garanti: 5 år
- Dimming 1-10 V:
- Yes
- Suitable for wall mounting:
- Yes
- Lamp type:
- LED not exchangeable
- With light source:
- Yes
- Housing colour:
- Grey
- Voltage type:
- AC
- With control gear:
- Yes
- Max. system power:
- 100-150 W
- Colour temperature:
- 3500-4500 K
- Colour rendering index CRI:
- 70-79
- Luminaire efficacy:
- 140 lm/W
- Degree of protection (IP):
- IP65
