NTCS 70

NTCS 70 is an electrically powered wire cutting and stripping machine designed for both solid and multi-stranded cables. It is engineered to process cables with cross-sections ranging from 1.5 to 70 mm², with an productivity of up to 2500 pieces per hour. Technical data: Stripping capability: 3-layer stripping for shield cable Wire material: Wide range of industrial wires Conductor cross-section: 1.5-70 mm² Cutting length 1-100,000 mm Cutting length tolerance: < 0.002*L Stripping length (side 1): 0-400 mm Stripping length (side II): 0-180 mm Slitting function: Optional Maximum guide tube diamete: 20 mm Display mode: 7-inch touch screen Memory capacity: 100 programs Blade material: High speed steel Productivity: 1500-2500 pcs./h Power supply: 220-240V AC / 50Hz Power: 800 W Weight: 80 kg Dimension: 700 x 640 x 480 mm
