2-gang Frame - INTEGRO FLOW
2-Facks Ramar - Flow
For vertical and horizontal mounting.
Size: 59.5 mm x 119 mm
- Anti-bacterial treatment:
- No
- Surface finishing:
- Glossy, Matt
- Mounting direction:
- Horizontal and vertical
- Label space/information surface:
- No
- With mounting grid:
- No
- Flush-mounted installation:
- Yes
- Suitable for floor box:
- No
- Suitable for built-in installation:
- Yes
- With hinged lid:
- No
- Transparent:
- No
- Type of fastening:
- Engage (snap)
- RAL-number (similar):
- 7021-9010 .
- Colour:
- Black, Grey, Brown, Anthracite, Chrome, Polar white
- Surface protection:
- Untreated, Lacquered
- Material:
- Plastic
- Type of product:
- Ram
- Variant:
- N/A
2-gang Frame - INTEGRO Classic
2-Facks Ramar -INTEGRO Classic_vp
For vertical and horizontal mounting.
Size: 59.5 mm x 119 mm
- Anti-bacterial treatment:
- No
- Surface finishing:
- Matt
- Mounting direction:
- Horizontal and vertical
- Label space/information surface:
- No
- With mounting grid:
- No
- Flush-mounted installation:
- Yes
- Suitable for floor box:
- No
- Suitable for built-in installation:
- Yes
- With hinged lid:
- No
- Transparent:
- No
- Type of fastening:
- Engage (snap)
- RAL-number (similar):
- 9006 .
- Colour:
- Chrome
- Surface protection:
- Lacquered
- Material:
- Plastic
Twin push-button switch for blinds - INTEGRO Berker
99010
Blind series push-button with imprinted symbol arrow
-e.g.for electrical blinds and awnings. Imprinted arrow symbol.
With electrical interlocking to prevent mutual activation.
10A, 250V
Size: 55.5 mm x 55.5 mm
Screw terminals
- For venetian blinds:
- Yes
- Number of buttons:
- 2 .
- With electrical locking:
- Yes
- Nominal voltage:
- 250 V
- Connection type:
- Screwed terminal
- Rated current:
- 10 A
- Mounting method:
- Built-in installation
- Anti-bacterial treatment:
- No
- Surface finishing:
- Glossy, Matt
- Compatible with Apple HomeKit:
- No
- Compatible with Google Assistant:
- No
- Compatible with Amazon Alexa:
- No
- IFTTT support available:
- No
- Assembly arrangement:
- Basic element with central cover plate
- Wiring system:
- Other
- Method of operation:
- Rocker/button, Rocker
- With mounting plate:
- No
- Illumination:
- No
- Feedback-signal contact:
- No
- Heating switch:
- No
- Washing machine switch:
- No
- Label space/information surface:
- No
- Model:
- 2-pole push button
- Type of fastening:
- Screw mounting
- RAL-number (similar):
- 7021-9023 .
- Min. depth of built-in installation box:
- 16 mm
- Colour:
- Brown, White, Anthracite, Chrome
- Surface protection:
- Untreated
- Material:
- Plastic
- Type of product:
- Strömbrytare
- Variant:
- 250V
- Built-in depth:
- 15.5 mm
Outlets USB-A and USB-C for 8-34VDC
Uttag USB-A och USB-C_vp
Input voltage: 8 – 34 VDC
Out voltage: 5V DC (+- 5%).
Max Current: 3.6A
Power in stand-by: <100mW
Measures: 55.5 mm x 55.5 mm
Installation depth: 32 mm
Pre-wired with 15cm red/black cable.
- Connection type:
- Other
- Mounting method:
- Built-in installation
- Anti-bacterial treatment:
- No
- Model:
- Bus
- Colour:
- Black, White
Wallboxes and Accessories - INTEGRO Berker
185107
Apparatdosa utanpåliggande 16 mm för FLOW och PURE
Högblank plast i utförande med och utan dragavlastning.
Bredd: 59.5 mm
Höjd: 59.5 mm
Djup: 16 mm
- Surface finishing:
- Glossy
- Assembly arrangement:
- Surface mounted box
- Suitable for modular domestic switching devices:
- No
- With cover frame:
- No
- With screw gland entry:
- No
- Colour:
- Black, White
- Surface protection:
- Untreated
- Type of product:
- Dosa
- Variant:
- N/A
Outlet 250 VAC - INTEGRO Berker
184502
Socket outlet grounded Schuko with child protection 16A, 250 VAC IP21
Screwterminals fits wall boxes Ø45 mm and Ø49 mm
Standard IEC 60884-1
- Impact strength:
- IK05
- Nominal voltage:
- 250 V
- Connection type:
- Screwed terminal
- Mounting method:
- Flush-mounted
- Over voltage protection:
- No
- With built-in USB power supply:
- No
- With on/off switch:
- No
- Surface finishing:
- Matt
- Rotated central insert:
- No
- Compatible with Apple HomeKit:
- No
- Compatible with Google Assistant:
- No
- Compatible with Amazon Alexa:
- No
- IFTTT support available:
- No
- Imprint/indication:
- None
- With signal lamp:
- No
- Label space/information surface:
- No
- With hinged lid:
- No
- Special power supply:
- No special power supply
- Protective contact:
- Yes
- With enhanced contact protection:
- No
- Metallic colour:
- No
- Lockable:
- No
- Eject-mechanism:
- No
- Insulated mounting:
- No
- With function lighting:
- No
- With orientation lighting:
- No
- Fault current protection:
- No
- With miniature fuse:
- No
- With loop through function:
- No
- Model:
- Protective contact (SCHUKO)
- Nominal current:
- 16 A
- Transparent:
- No
- Type of fastening:
- Mounting with screw
- Min. depth of built-in installation box:
- 32 mm
- Colour:
- Black, Grey, Brown, White
- Surface protection:
- Untreated
- Material:
- Plastic
- Type of product:
- Uttag
- Variant:
- Schuko
- Number of phases:
- 1 .
Antennuttag TV med F-kontakt - INTEGRO Berker
Berker antennuttag TV F kontakt_vp
Aerial connection box for TV, F connection
With IEC jack (male)
Connection in F system on the rear.
Standard: DIN 45325
Size: 55.5 mm x 55.5 mm
- Mounting method:
- Built-in installation
- Surface finishing:
- Matt
- Model:
- Loop-through socket
- Colour:
- Black, Brown
- Surface protection:
- Untreated
- Type of product:
- Uttag
- Variant:
- TV/DATA
