LSP-3 3CCTW80R-MW
3-PACK LED DOWNLIGHTS 80mm, 3.3W, WHITE, ROUND 60gr, IP54 PRISM REFLECTOR, 3CCT, WINGS
LSP-3 3CCTW80R-MW
- Availability:
-
Yes
- Total: 1
Related items
LSP Downlights 3CCT Runda 3-Pack
These downlights can be tilted, only use high quality components and has a premium feeling.Works for both indoor and outdoor use.
Available with diameter 60 mm, 80 mm and 90 mm.
60 mm frames have springs and can be mounted in ceiling.Hole size: 52-54 mm.
80mm frames have metal wings and can be mounted in ceiling as well as in 70mm junction boxes. Hole size: 52-62 mm.
90 mm frames have metal wings and can be mounted in ceiling as well as in 80mm junction boxes.Hole size: 52-72mm.3-pack. Can be supplemented with drivers, cables and connectors.
Technical data:
Power: 3.3W
Lumen: See below.
Dimmable: Yes
Light beam spread: 60°
Color temp: See below.
IP rating: IP54
Temp. Range: -20°C to +50°C
Life-span: 70% after 50.000h
Voltage: 1-10V
Amperage: 350mA
Amount of LED’s: 3pcs
Type of LED: COB, CREE CXA1304-2 STEP
CRI: RA90
Optics: Reflector with a prism in front of the LED.
Glass: Clear
Energy rating: A++
Cable: 100 mm AWG22 with connector.
Size: Depth = 50 mm, Height = 60 mm
Downlight depth in box: Max 25 mm
Available in white, black or aluminum color.
- Total: 1
Product Properties
| Dimmable | Yes |
|---|---|
| Dimming 0-10 V | No |
| Dimming 1-10 V | No |
| Dimming DALI | No |
| Dimming DSI | No |
| Dimming DMX | No |
| Dimming potentiometer (integrated) | No |
| Dimming GPRS | No |
| Dimming LineSwitch | No |
| Dimming manufacturer's proprietary system | No |
| Dimming mains voltage modulation | No |
| Dimming phase cut-off (trailing edge) | No |
| Dimming phase cut-on (leading edge) | No |
| Dimming programmable | No |
| Dimming RF | No |
| Dimming Sine Wave Reduction | No |
| Dimming Touch and Dim | No |
| Dimming Zigbee | No |
| Dimming with push-button | No |
| Protection class according to IEC 61140 | III |
| Housing material | Aluminium |
| Suitable for surface mounting | No |
| Suitable for built-in mounting | Yes |
| Suitable for wall mounting | No |
| Suitable for suspended mounting | No |
| Suitable for ceiling mounting | Yes |
| Suitable for traverse mounting | No |
| Suitable for pedestal/floor mounting | No |
| Suitable for light-track mounting | No |
| Suitable for clamp-mounting | No |
| Suitable for low voltage cable system | No |
| Adjustability | Rotatable |
| With movement sensor | No |
| With light sensor | No |
| Lamp type | LED not exchangeable |
| With light source | Yes |
| Suitable for number of light sources | 1 . |
| Lamp holder | None |
| Housing colour | White |
| Material cover | None |
| Surface brushed | No |
| Voltage type | AC |
| Nominal voltage | 220-240 V |
| Type of control gear | LED operating device current-controlled |
| With control gear | No |
| Dimming depending on control gear | Yes |
| Reflector | High-gloss |
| Light distributor | Reflector |
| Light distribution | Symmetric |
| Beam angle | 41-80° - Wide beam |
| Light outlet | Direct |
| Energy efficiency class of the built-in lamp | F |
| Degree of protection (NEMA) | Other |
| Suitable for lamp power | 0 N/A |
| Max. system power | 4 W |
| Colour of light | White |
| Colour temperature | 2400-3000 K |
| Colour rendering index CRI | 80-89 |
| Luminous flux | 325 lm |
| Lamp efficacy | 82 lm/W |
| Luminous intensity | 364 cd |
| Number of poles | 2 . |
| Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24 | No |
| Suitable for workplace according to EN 12464-1 | No |
| Covering of the luminaire with thermally insulating material possible | Yes |
| Connection type | Crimping |
| Frame shape | Round |
| Degree of protection (IP) | IP54 |
| Surface protection | Powder coating |
| Rated luminous flux according to IEC 62722-2-1 | 325 lm |
Dimensions
| Width | 0 mm |
|---|---|
| Built-in width | 0 N/A |
| Built-in length | 0 N/A |
| Built-in diameter | 52-62 mm |
| Conductor cross section | 0.34 mm² |
| MOQ | 1 . |
| Connectable conductor cross section | 0.34 mm² |
| Height/depth | 3 mm |
| Unit | pck |
| Length | 0 N/A |
| Outer diameter | 80 mm |
Logistics
| Barcode | 733117641219 |
|---|---|
| Country of origin | TW |
| Item status | Stock item, normally in stock with reservation for in between sales. |
| MOQ | 1 . |
| Stock code | LSP-3 3CCTW80R-MW |
| Taric code | 85395100 |
| Unit | pck |
Approvals
| Rated luminous flux according to IEC 62722-2-1 | 325 lm |
|---|---|
| Protection class according to IEC 61140 | III |
| Voltage type | AC |
| Degree of protection (NEMA) | Other |
| Degree of protection (IP) | IP54 |
Other info
| ETIM-Class | EC001744 - Downlight/spot/floodlight |
|---|---|
| ETIM-Release | 9.0 |
| Trademark | NESIGN |
| Product Group | 415026 |
| Alternative SKU | LSP-33CCTW80R-MW |
