Extension work light
Förlängning_kedjebelysning_vp
For extended work light needs, they can be extended up to 100m.
Does not come with a starting connector.
Double-row diodes:
NWLD6000K09W-10
NWLD6000K09W-25
Single-row diodes:
NWLS6000K09W-10
NWLS6000K09W-25
Applications: construction sites, stairwells, elevator shafts, scaffolding, and corridors.
Note that it should not be connected while still in the box or rolled up.
Temperature Range: -25º to +50º
CE and RoHS certification
Standard: EN 60595-1
LVD: 2014/35/EU
EMC: 2014/30/EU
- Protection class according to IEC 61140:
- II
- Lamp type:
- LED not exchangeable
- Voltage type:
- AC
- Energy efficiency class of the built-in lamp:
- Other
- Max. system power:
- 50-250 W
- Colour of light:
- White
- Colour temperature:
- 6000 K
- Colour rendering index CRI:
- 80-89
- Power factor:
- 0.9 .
- Number of poles:
- 2 .
- Connection type:
- Other
- Self-adhesive:
- No
- Mounting method:
- Surface mounting
- With protective cover:
- Yes
- Degree of protection (IP):
- IP65
- Model:
- Hose
- Exchangeable control gear:
- Yes
- Colour of light adjustable:
- No
- Beam angle adjustable:
- No
- Luminous flux adjustable:
- No
- Number of nodes per meter:
- 120-240 .
- Number of nodes per foot:
- 37-73 .
- Lamp power per meter:
- 8-10 W
- Lamp power per foot:
- 2.4384-3.048 W
- Luminous flux per meter:
- 880-1200 lm
- Lamp voltage:
- 220-240 V
- Beam angle:
- 120 °
- Suitable for dimmer:
- No
- With end piece:
- Yes
- With connection set:
- No
Adapter till NWL för koppling med andra fabrikat
Adapter_NWL_vp
En adapter för att kunna koppla ihop NWL kedjebelysning med andra fabrikat på marknaden.
