BNC hylsa till BNC hylsa, enhåls chassimontage Rak adapter.

Halogen-free control cable for protected fixed installation in train applications. The cable has a very small outer diameter and is used in tight spaces, smaller, lighter and more flexible than previous cables for railway application. Areas of use are control and control cabinets, control panels, signal circuits and internal control cable in other train equipment. Guidelines for selection and installation are described in the standards EN 50355 and EN 50343. Resistant to high mechanical loads, oil and fuel. Structure Conductor: Tinned multi-wire copper according to IEC 60228 class 5 Conductor insulation inner jacket: RADOX EI 303 (polyolefin copolymer) Conductor color: White, numbered and g = green / yellow. Transparent plastic foil Conductor insulation outer sheath: RADOX EM 104 (polyolefin copolymer) Sheath color: Black with yellow text Technical data: Operating voltage: 600/1000 V AC, 750/1500 V DC Test voltage: 3500 V (50 Hz, 5 min) Temp. range: -40ºC to + 120ºC Minimum bending radius: 3 x cable diameter (see data sheet) Approvals: EN 50355 and EN 50343, flame resistance BS 6853 DIN 5510 NF F16-101 BS 4066-3 BS 6583 BS 6853 cat. D BS 6853 cat. B DIN EN 50265-2-1 DIN EN 50266-2-4 DIN EN 50266-2-5 DIN EN 50268-2 NF C32-070 TEST 2 NF X10-702-2 NF X70-100 IEC 60332-1 EN 50265 -2-1 IEC 60332-3-24 EN 50266-2-4 IEC 60754-1 EN 50267-2-1 IEC 60754-2 EN 50267-2-3 IEC 61034-2 EN 50268-2

Halogen-free cable suitable both for fixed installation or as a connection cable in dry, damp and wet areas both indoors and outdoors. Due to the good mechanical properties and the high chemical resistance, RADOX 125 is especially suitable in industry in demanding environments, eg for machines and industrial equipment.

Halogenfri kabel lämpligt både för fast förläggning eller som anslutningskabel i torra, fuktiga och våta utrymmen både inom- och utomhus. Med hänsyn av de goda mekaniska egenskaper samt den höga kemikaliebeständigheten, är RADOX 125 speciellt lämplig inom industrin i krävande miljöer, t.ex för maskiner och industriutrustningar. Kabeln har flätad kopparskärm med hög täckningsgrad, därför är den mycket lämplig i miljöer med hög störningsnivå (enligt EMC-direktivet).

Halogen-free cable suitable both for fixed installation or as a connection cable in dry, damp and wet areas both indoors and outdoors. Due to the good mechanical properties and the high chemical resistance, RADOX 125 is especially suitable in industry in demanding environments, eg for machines and industrial equipment.

Flexible connector cable for the internal wiring in lamps, heaters, electrical equipment, command and control cabinets, and in the construction industry. Ideal for the installation inside the tubes as well as for external installation. Very good electrical and mechanical properties. Wide temperature range and high resistance to oils, ozone, hydrolysis and mechanical stress. Connection wire is flame retardant, at fire it develops minimum of smoke and no corrosive gases are released.
