Reläsockel - Minireläer
86663
Sockeln används i följade kombinationer med flatstiftshylsor med nabb: - 4 eller 5 st 6.3 x 0.8 mm - 4 st 2.8 x 0.8 mm. Kan skruvas fast i chassi samt monteras på rad.
Monteringshål (B x H): 7.5 x 5.3 mm.
Påbyggningsbar med MRS 500006, MRS 500007 och säkringshållaren SH 500016.
NELCOFLEX-Y
75201
Flexible oil resistant cable is resistant to the effects of chemicals and acids.
The finely stranded structure in combination with PVC sheath provides a very flexible cable with a small bending radius. It is used as command and control cable, and in industrial machinery, in cooling and ventilation as well as in computer and signal systems. Can be used in dry and wet areas.
Structure
Conductor: Blank stranded copper
Conductor insulation: PVC
Conductor identification: Black with white numbers mark. Green-yellow protective conductors
Outer Sheath: PVC
Sheath Colour: Grey
Technical data:
Rating voltage: 300/500 V
Test voltage: 3000 V
Minimum bending radius: 6 x cable diameter
Temperature range: Fixed min/max: -40ºC to +70ºC (-40ºF to +158ºF)Moving min/max: -5ºC to +70ºC (+23ºF to +158ºF)
Radiation
Best: 8 x 107 [/ sup] cJ / kg
Minimum bending radius: 6 x cable diameter
Oil resistance: Good
Flame resistance: IEC 332-1
Approvals: Meets Swedish and European standards asSS EN 60204
- Number of cores:
- 2-50 .
- Material core insulation:
- Polyvinyl chloride (PVC)
- Specification core insulation:
- Other
- Core identification:
- Colour, Numbers
- Protective conductor:
- Yes, No
- Material outer sheath:
- Polyvinyl chloride (PVC)
- Specification material outer sheath:
- Other
- Colour outer sheath:
- Other
- Flame retardant:
- According to IEC/EN 60332-1-2
- Permitted cable outer temperature after assembling without vibration:
- -30-70 °C
- Conductor material:
- Copper
- Twisted cores:
- No
- Max. conductor temperature:
- 70 °C
- Screen:
- No
- Protective barrier:
- N/A
- Armouring/reinforcement:
- None
- Insulation integrity:
- N/A
- Drain wire:
- No
- Nominal voltage:
- 500-1000 V
- Halogen free:
- No
- Conductor category:
- Class 5 = flexible
- Colour:
- Grey
- Material insulation:
- Polyvinyl chloride (PVC)
- Operating temperature:
- -40-70 °C
- Core colour:
- Several
- Conductor surface:
- Bare
- Halogen free:
- No
- Min. permitted bending radius, stationary application/permanent installation:
- 19.6-164.8 mm
- Reaction-to-fire according to EN 13501-6: Class:
- Eca
- Reaction-to-fire according to EN 13501-6: Smoke production:
- N/A
- Reaction-to-fire according to EN 13501-6: Flaming droplets/particles:
- N/A
- Reaction-to-fire according to EN 13501-6: Acidity:
- N/A
- Low smoke (according to EN 61034-2):
- No
- Low temperature resistant (according to EN 60811-504+505+506):
- No
- Oil resistant according to EN IEC 60811-404:
- No
- Availability:
-
No
- Number of cores:
- 1 .
- Material core insulation:
- Polyvinyl chloride (PVC)
- Specification core insulation:
- Other
- Core identification:
- None
- Protective conductor:
- No
- Material outer sheath:
- None
- Specification material outer sheath:
- Other
- Colour outer sheath:
- Other
- Flame retardant:
- According to IEC/EN 60332-1-2
- Permitted cable outer temperature after assembling without vibration:
- -30-70 °C
- Conductor material:
- Copper
- Twisted cores:
- No
- Max. conductor temperature:
- 70 °C
- Screen:
- No
- Protective barrier:
- N/A
- Armouring/reinforcement:
- None
- Insulation integrity:
- N/A
- Drain wire:
- No
- Nominal voltage:
- 600 V
- Halogen free:
- No
- Conductor category:
- Class 5 = flexible
- Colour:
- Green/yellow
- Material insulation:
- Polyvinyl chloride (PVC)
- Designations:
- H07V-K (RK 1.5 - 400mm2)
- Operating temperature:
- -5-70 °C
- Core colour:
- Green/yellow
- Conductor surface:
- Bare
- Halogen free:
- No
- Packaging:
- Ring
- Min. permitted bending radius, stationary application/permanent installation:
- 60.8 mm
- Reaction-to-fire according to EN 13501-6: Class:
- N/A
- Reaction-to-fire according to EN 13501-6: Smoke production:
- N/A
- Reaction-to-fire according to EN 13501-6: Flaming droplets/particles:
- N/A
- Reaction-to-fire according to EN 13501-6: Acidity:
- N/A
- Low smoke (according to EN 61034-2):
- No
- Low temperature resistant (according to EN 60811-504+505+506):
- No
- Oil resistant according to EN IEC 60811-404:
- No
EAP 240
EAP 240_VP
EAP 240 is a thorn-crimping tool for 25-240 mm² end-sleeves.
Length: 625 mm
Crimp dies are not included!
- With locking device (for mechanical tools):
- No
- Inserts exchangeable:
- Yes
- Number of included inserts:
- 0 .
- With automatic return:
- No
- Cycle time:
- 2 s
- Suitable for:
- Cable end sleeves
- Construction/operation:
- Mechanical
- For component:
- End sleeves
- Compression shape:
- Arbour clamping
Pressverktyg mekaniskt för NH-BACK
Pressverktyg mekaniskt_NH-BACK_vp
RHX 185
RHX 185 är ett mekaniskt 6-kants pressverktyg för 10-120 mm² KRF, 10-150 mm² KRT, 10-150 mm² KRD samt 10-50 mm² Cu-förgreningar.
NH-backar används.
Längd: 470 mm
OBS! Pressbackar ingår ej.
- With locking device (for mechanical tools):
- Yes
- Inserts exchangeable:
- Yes
- Number of included inserts:
- 0 .
- With automatic return:
- No
- Cycle time:
- 10 s
- Suitable for:
- Cable lugs and connectors
- Construction/operation:
- Mechanical
- For component:
- Non-insulated Cu tube and sheet terminals
- Compression shape:
- Hexagon
AA-35C
AA-35C_VP
AA-35C is a symmetrical crimping tool for 10.0-35.0 mm² insulated terminals.
Also crimps uninsulated terminals from 10.0-35.0 mm².
There is 4 die nests:
1: 10.0 mm²
2: 16.0 mm²
3: 25.0 mm²
4: 35.0 mm²
Length: 490 mm
- With locking device (for mechanical tools):
- No
- Inserts exchangeable:
- No
- Number of included inserts:
- 1 .
- With automatic return:
- No
- Cycle time:
- 2 s
- Suitable for:
- Cable lugs and connectors
- Construction/operation:
- Mechanical
- For component:
- Insulated terminals
- Compression shape:
- Oval pressing
NELCOFLEX-CY (EMC) - Korta längder
80034
Flexible oil resistant cable is resistant to the effects of chemicals and acids. The finely stranded structure in combination with PVC sheath provides a very flexible cable with a small bending radius. The cable is fitted with a screen of tinned braided copper wire, which protects against mechanical loads and in particular all shields electrical freqvencly as well inside and outside the cable (EMC Directive).
It is used as command and control cable, and in industrial machinery, in cooling and ventilation as well as in computer and signal systems.
Can be used in dry and wet areas.
Structure
Conductor: Blank stranded copper
Conductor insulation: PVC
Conductor identification: Black with white numbers mark. Green-yellow protective conductors
Inner Sheath: PVC
Screen: Tinned copper braid
Outer Sheath: PVC
Sheath Colour: Transparent
Technical data:
Rating voltage: 300/500 V
Test voltage: 3000 V
Minimum bending radius: 6 x cable diameter
Temperature range: Fixed min/max: -40ºC to +70ºC (-40ºF to +158ºF)
Moving min/max: -5ºC to +70ºC (+23ºF to +158ºF)
Radiation Best: 8 x 10 7 [/ sup] cJ / kg
Minimum bending radius: 6 x cable diameter
Oil resistance: Good
Flame resistance: IEC 332-1
Approvals: Meets Swedish and European standards asSS EN 60204
- Number of cores:
- 2-50 .
- Material core insulation:
- Polyvinyl chloride (PVC)
- Specification core insulation:
- Other
- Core identification:
- Numbers
- Protective conductor:
- Yes, No
- Material outer sheath:
- Polyvinyl chloride (PVC)
- Specification material outer sheath:
- Other
- Colour outer sheath:
- Other
- Flame retardant:
- According to IEC/EN 60332-1-2
- Permitted cable outer temperature after assembling without vibration:
- -30-70 °C
- Conductor material:
- Copper
- Twisted cores:
- No
- Max. conductor temperature:
- 70 °C
- Screen:
- Yes
- Protective barrier:
- N/A
- Armouring/reinforcement:
- Braiding
- Insulation integrity:
- N/A
- Drain wire:
- No
- Nominal voltage:
- 500 V
- Halogen free:
- No
- Conductor category:
- Class 5 = flexible
- Colour:
- Transparent
- Material insulation:
- Polyvinyl chloride (PVC)
- Operating temperature:
- -40-70 °C
- Core colour:
- Several
- Conductor surface:
- Bare
- Halogen free:
- No
- Min. permitted bending radius, stationary application/permanent installation:
- 31.6-105.6 mm
- Reaction-to-fire according to EN 13501-6: Class:
- N/A
- Reaction-to-fire according to EN 13501-6: Smoke production:
- N/A
- Reaction-to-fire according to EN 13501-6: Flaming droplets/particles:
- N/A
- Reaction-to-fire according to EN 13501-6: Acidity:
- N/A
- Low smoke (according to EN 61034-2):
- No
- Low temperature resistant (according to EN 60811-504+505+506):
- No
- Oil resistant according to EN IEC 60811-404:
- No
Bultsaxar
133801
TS-serien
7 kraftiga bultsaxar med justerbara skär.
Skänklar av stålrör med greppvänliga gummihandtag.
TS 1200: Längd 320 mm, kapacitet 5 mm
TS 1400: Längd 360 mm, kapacitet 7 mm
TS 1800: Längd 460 mm, kapacitet 8 mm
TS 2400: Längd 600 mm, kapacitet 10 mm
TS 3000: Längd 750 mm, kapacitet 12 mm
TS 3600: Längd 900 mm, kapacitet 15 mm
TS 4200: Längd 1050 mm, kapacitet 18 mm
- With adjustable jaws:
- Yes
- Cutting blade exchangeable:
- No
- Blade shape:
- Other, Straight
- Angled:
- No
- Construction/operation:
- Mechanic two hands
- Isolation protection 1000 V:
- No
NELCOFLEX - PUR
80047
Den fintrådiga uppbyggnaden i kombination med PUR-manteln ger en mycket elastisk kabel med liten böjradie. Ytterhöljet av polyuretan möjliggör en mycket liten kabelytterdiameter, höga mekaniska påfrestningar kan motstås. Kabeln är nötningssäker, mikrobeständig och flamsäker. Lämplig för användning i kabelkedjor och kontinuerligt rörliga maskiner samt
portalrobotar.
Uppbyggnad:
Ledare: Blank flertrådig koppar klass 6.
Ledarisolation: PP
Yttermantel: PUR, PURWIL
Mantelfärg: Grå, Orange
Ledarfärg - PUR: Svart med vit eller svart nummermärkning.
Ledarfärg - PURWIL: Färgade ledare enl. HD 308
Gröngul skyddsledare.
Teknisk data:
Driftspänning: 300/500 V
Provspänning: 3000 V
Kabelarea: 0.5mm² -70mm²
Temp. område: Fast förläggning min/max: -40ºC till +90ºC
Rörlig förläggning min/max: -40ºC till +90ºC
Minsta böjradie: 5 x kabelns diameter
Oljebeständighet: God
Flambeständighet: IEC 332-1
Godkännanden: DIN EN 60811-404
VDE 0482 del 332-2-2 resp. IEC 60332-2-2
Tillämpade standarder: liknande VDE 0250
- Number of cores:
- 2-25 .
- Material core insulation:
- Rubber, Polyurethane (PUR)
- Specification core insulation:
- Other
- Core identification:
- Colour, Numbers
- Protective conductor:
- Yes, No
- Material outer sheath:
- Polyurethane (PUR)
- Specification material outer sheath:
- Other
- Colour outer sheath:
- Grey, Orange
- Flame retardant:
- According to IEC/EN 60332-1-2
- Permitted cable outer temperature after assembling without vibration:
- -40-90 °C
- Conductor material:
- Copper
- Twisted cores:
- No
- Max. conductor temperature:
- 60-90 °C
- Screen:
- No
- Armouring/reinforcement:
- Braiding, None
- Drain wire:
- No
- Nominal voltage:
- 500 V
- Halogen free:
- No
- Conductor category:
- Class 5 = flexible
- Colour:
- Grey, Orange
- Material insulation:
- Polyurethane (PUR)
- Operating temperature:
- -40-70 °C
- Core colour:
- Several
- Conductor surface:
- Bare
- Halogen free:
- Yes
- Min. permitted bending radius, stationary application/permanent installation:
- 27.5-97 mm
- Reaction-to-fire according to EN 13501-6: Class:
- N/A
- Reaction-to-fire according to EN 13501-6: Smoke production:
- N/A
- Reaction-to-fire according to EN 13501-6: Flaming droplets/particles:
- N/A
- Reaction-to-fire according to EN 13501-6: Acidity:
- N/A
- Low smoke (according to EN 61034-2):
- No
- Low temperature resistant (according to EN 60811-504+505+506):
- No
- Oil resistant according to EN IEC 60811-404:
- No
Quick Power Marine
97774
Batterikabelsko för Amerikanska batterier, med snabbkoppling och polskydd.
Finns i förtent mässing.
Area på kabel: 25 - 35 mm²
Polstorlek: (+) 19 mm, (-) 17 mm
Levereras parvis i blisterpack.
- Type of accessory/spare part:
- Battery terminal
- Insulated:
- Yes
- Surface protection:
- Tinned
- Cable connection type:
- Klämning
- Connection around pole:
- Snabbkoppling
- Packaging:
- Bag
- Accessory:
- Yes
- Spare part:
- No
Quick Power & Quick Power ft
97773
Batterikabelsko, med snabbkoppling och polskydd.
Finns i förtent och oförtent mässing.
Area på kabel: 25 - 35 mm²
Polstorlek: (+) 19 mm, (-) 17 mm
Levereras parvis i blisterpack.
- Type of accessory/spare part:
- Battery terminal
- Insulated:
- Yes
- Surface protection:
- Untreated
- Cable connection type:
- Klämning
- Connection around pole:
- Snabbkoppling
- Packaging:
- Bag
- Accessory:
- Yes
- Spare part:
- No
- Explosion-proof:
- No
- Release characteristic:
- Medium time-lag
- Optical defect indication:
- Yes
- Type of current:
- DC
- Colour code:
- Other
- Nominal voltage DC:
- 58 V
- Max. continuous voltage DC:
- 58 V
- Max. current (Imax):
- 50-300 A
- Nominal current:
- 50-300 A
- Fuse type:
- Battery
- Packaging:
- Loose piece
Battery pole protection
Batteripolskydd BPC 2550
Battery pole protection for Battery terminals BTSQ 2550 series.
- Type of accessory/spare part:
- Insulation cover
- Insulated:
- Yes
- Accessory:
- Yes
- Spare part:
- No
ISO 98 S
ISO 98 S_VP
ISO 98 S
Isolationsmuff för förmontage.
Material: Nylon
Färg: Natur
Passar till: Flatstifthylsor 9.5 mm
- Type of accessory/spare part:
- Insulating sleeve
- Colour:
- Natural colour
- Material:
- Polyamide (PA)
- Halogen free:
- Yes
- Isolation sleeve for:
- Flatstiftshylsa 9.5mm
- Mounting method:
- Pre-assembly (before crimping)
- Accessory:
- Yes
- Spare part:
- No
554
554_VP
554
Handmanövrerat bockningsverktyg för kretskortskomponenter, såsom motstånd, dioder m.m. Bockar i exakt 90º vinkel.
Pitchen justeras enkelt med ett tummanövrerat hjul.
Verktyget är dessutom utrustad med en klippfunktion.
Ledardiameter: 0.25-1.0 mm
Min/max böjlängd: 9.5-32 mm
Min/max klipplängd: 19-64 mm
Mindistans för böjning från komponent: 1.0 mm
Max komponentdiameter: 13 mm
Vikt: 280 g
553
553_VP
553
Handmanövrerat bockningsverktyg för kretskortskomponenter, såsom motstånd, dioder m.m. Bockar i exakt 90º vinkel.
Pitchen justeras enkelt med ett tummanövrerat hjul.
Ledardiameter: 0.25-1.0 mm
Min/max böjlängd: 9.5-32 mm
Mindistans för böjning från komponent: 1.0 mm
Max komponentdiameter: 13 mm
Vikt: 226 g
Kapverktyg för DIN-Skenor
W05000X_VP
Kapverktyg för DIN-skenor med lång hävarm för lättare användning. Kapar skenan utan grader.
Se nedan vilka skentyper respektive verktyg kan kapa.
Dragavlastning till GSTF
Dragavlastning till GSTF_vp
Dragavlastning till GSTF, Svart
För 3 x 1.5 mm²
Bladsäkringar - BSO-Series
BSO-bladsäkring_vp
Bolt-on fuse according to VAG.
Stud size: M6
CC dimensions: 30 mm
Material: Zinc
- Explosion-proof:
- No
- Release characteristic:
- Medium time-lag
- Optical defect indication:
- Yes
- Type of current:
- DC
- Colour code:
- Other
- Nominal voltage DC:
- 32 V
- Max. continuous voltage DC:
- 32 V
- Nominal current:
- 30-175 A
Kabelkontakt AC 166 serien, 3-pol, Vit
Kabelkontakt AC 166 serien_3-pol Vit_vp
Kabelkontakt AC 166 serien, 3-pol, Vit
Poltal: 3
Spänning: 250 V
Ström: 20A
Skruvanslutning: 2.5 mm²
Temperatur: +70° C
Material: PA 6.6
- First Page
- [121]-[130]
- 131
- 132
- 133
- 134
- 135
- 136
- 137
- 138
- 139
- 140
- [141]-[150]
- Last Page
- Total: 3662
