Lamphållare 844 för GZ10 Lamphållare i keramik för halogenlampor. För sockel: GZ10, passar även Gu10 sockel Spänning: 250 V Ström: 2.0 A Temp: 350° C Ledning: Teflon PTFE 0.75 mm², längd 145 mm (135 mm nyttjbar längd) Artikelnr: 1766-25848 isolerkåpa M10 x 1 mm

Lamphållare 257 B15d/Ba15d Lamphållare i förnicklad mässing för halogenlampor. Sockel: B15d/Ba15d Spänning: 250 V Ström: 10 A Temperatur: 250° C, ej över gränstemperatur för anslutningsledningen. Ledningsanslutning: Skruv Fastsättning: Fläns

Lamphållare 990 för G4, Gy4, Gz4 Lamphållare i keramik för halogenlampor. För sockel G4, Gy4, Gz4 Spänning: 50 V Ström: 10 A Temperatur: 350° C Ledning: Silikon N2GFAF0.75 mm², längd 145 mm

Lamphållare 952 för R7S Lamphållare i metall/keramik för halogenlampor. För sockel: R7S Spänning: 250 V Ström: 10.0 A Temperatur: 250° C Ledning: Silikon N2GFAF 0.75 mm², längd 400 mm

Krimpfläns I=Innermått mm Y=Yttermått mm

Krimphylsa I=Innermått mm Y=Yttermått mm

Quick lock kåpa 2-delad

Plocktång/ monteringstång för produktion och service inom telefon- och elektronikindustri, finmekanik etc. Lätta handtag med fjädrande band av polyamid. Diagonalt räfflade käftar av härdat stål. Spetsbredd: 1.5 mm Käftlängd: 18 mm Längd: 155 mm P 20 B: Handtag av plast

Plocktång/ monteringstång för produktion och service inom telefon- och elektronikindustri, finmekanik etc. Lätta handtag med fjädrande band av polyamid. Diagonalt räfflade käftar av härdat stål. Spetsbredd: 2.0 mm Käftlängd: 22 mm Längd: 155 mm Handtag av plast.

Plocktång/ monteringstång för produktion och service inom telefon- och elektronikindustri, finmekanik etc. Lätta handtag med fjädrande band av polyamid. Diagonalt räfflade käftar av härdat stål. Spetsbredd: 2.5 mm Käftlängd: 21 mm Längd: 155 mm Handtag av plast.

Sax med skär av rostfritt stål, för både höger- och vänsterhänta. Lätt plasthandtag med fjädrande band av polyamid. Levereras med kombinerat eggskydd/ upphängare. Skärlängd: 60 mm Längd: 190 mm

Sax med skär av rostfritt stål, för både höger- och vänsterhänta. Lätt och starkt plasthandtag med fjädrande band av polyamid. Skärlängd: 38 mm Längd: 165 mm

Plocktång/ monteringstång för produktion och service inom telefon- och elektronikindustri, finmekanik etc. Lätt och starkt plasthandtag med fjädrande band av polyamid. Utrustad med ett längre handtag med låsanordning. Spetsbredd: 2.5 mm Käftlängd: 21 mm Längd: 165 mm

Grommets which both seals and locks. Locking by inserting the cable through the sleeve and then pull backcable a few millimeters, where the rubber rolls back and locksthe cable. The thickness of the hole where the seal must be affixed can be 1.0-4.0 mm for PG-grommets and 1.3-5.0 mm for metric grommets. Chloroprene (CR) has very good resistanceto oils and is self-extinguishing. Chloroprene is age- and weather-resistant.

LMC 35 Multigate is suitable for leading through both low and medium power current cables as well as various types of tubing. It fits directly to a C-standard cut-out (or FL 21). LMC 35 Multigate is metal reinforced cable gland plate made of various types of polymers. It meets the respective IP enclosure classes as it does not need separate gaskets or glands which makes it very easy to use, providing innumerable advantages in a single assembly unit. LMC 35 Multigate is suitable for both outdoor and indoor use. LMC 35 Multigate gives protection against water splashed from all directions. LMC 35 Multigate is inspected and sertified by SGS FIMKO: the Finnish authority in charge of electrical equipment safety standards. All article numbers ending with “F” include fastening rivets. LMC 35 IP44 Multigate will lead through and seal cables as follows: 15 - 32 mm 1 pc12 - 18 mm 2 pcs10 - 14 mm 16 pcs7 - 12 mm 14 pcs6 - 10 mm 2 pcsTotal of 35 cables

MC 16 Reversible Multigate is suitable for leading through both low and medium power current cables as well as various types of tubing. It fits directly to a C-standard cut-out (or FL 21) MC 16 Reversible Multigate is plastic reinforced cable gland plate made of various types of polymers. It meets the respective IP enclosure classes as it does not need separate gaskets or glands which makes it very easy to use, providing innumerable advantages in a single assembly unit. MC 16 Reversible Multigate can be used by two different ways. When the Multigate is used “facade” up, it works as a regular IP54 enclosure cable gland plate. The product contains a gasket against the cabinet and it comes with self-locking pins. This means that no special tools are needed at any point of the installation. When the Multigate is used reversed it functions as a piping grommet in dry space swichboards. Pipes lock securely to the seal in the gland plate by the friction of the elastic material.Membranes on the plate seal the pipes and effectively prevent condensate formation in pipes that run, for instance, through attic space. The self-locking pins supplied with the Multigate are also suitable for reverse mounting. MC 16 Reversible Multigate is suitable for both outdoor and indoor use. MC 16 Reversible Multigate gives protection for limited ingress of dust and against water splashed from all directions. MC 16 Reversible Multigate is inspected and certified by SGS FIMKO: the Finnish authority in charge of electrical equipment safety standards. All article numbers ending with “F” include fastening rivets. MC 16 Multigate will lead through and seal cables as follows: 10 - 20 mm 15 pcs10 - 30 mm 1 pcTotal of 16 cables

Grommets which both seals and locks. Locking by inserting the cable through the sleeve and then pull back the cable a few millimeters, where the rubber rolls back and locks the cable. The thickness of the hole where the seal must be affixed can be 1.3-5.0 mm. Protection: IP 67 within the specifies cable diameter(for both materials). Material: Thermoplastic Elastomer (TPE). Self-extinguishing. Weather-resistant. Temperature range: -40° C to +100° C

LMC 14 Multigate is suitable for leading through both low and medium power current cables as well as various types of tubing. It fits directly to a C-standard cut-out (or FL 21). LMC 14 Multigate is metal reinforced cable gland plate made of various types of polymers. It meets the respective IP enclosure classes as it does not need separate gaskets or glands which makes it very easy to use, providing innumerable advantages in a single assembly unit. LMC 14 Multigate is suitable for both outdoor and indoor use. LMC 14 Multigate gives protection against water splashed from all directions. LMC 14 Multigate is inspected and certified by SGS FIMKO: the Finnish authority in charge of electrical equipment safety standards. All article numbers ending with “F” include fastening rivets. LMC 14 IP54 Multigate will lead through and seal cables as follows: 24 - 54 mm 2 pcs14 - 22 mm 3 pcs14 - 18 mm 4 pcs10 - 14 mm 5 pcsTotal of 14 cables

LMC 25 Multigate is suitable for leading through both low and medium power current cables as well as various types of tubing. It fits directly to a C-standard cut-out (or FL 21). LMC 25 Multigate is metal reinforced cable gland plate made of various types of polymers. It meets the respective IP enclosure classes as it does not need separate gaskets or glands which makes it very easy to use, providing innumerable advantages in a single assembly unit. LMC 25 Multigate is suitable for both outdoor and indoor use. LMC 25 Multigate gives protection against water splashed from all directions. LMC 25 Multigate is inspected and certified by SGS FIMKO: the Finnish authority in charge of electrical equipment safety standards. All article numbers ending with “F” include fastening rivets. LMC 25 IP54 Multigate will lead through and seal cables as follows: 14 - 35 mm 1 pc14 - 22 mm 5 pcs14 - 18 mm 12 pcs10 - 14 mm 5 pcs3.5 - 11 mm 2 pcsTotal of 25 cables

LMC 51 Multigate is suitable for leading through both low and medium power current cables as well as various types of tubing. It fits directly to a C-standard cut-out (or FL 21). LMC 51 Multigate is metal reinforced cable gland plate made of various types of polymers. It meets the respective IP enclosure classes as it does not need separate gaskets or glands which makes it very easy to use, providing innumerable advantages in a single assembly unit. LMC 51 Multigate is suitable for both outdoor and indoor use. LMC 51 Multigate gives protection against water splashed from all directions. LMC 51 Multigate is inspected and certified by SGS FIMKO: the Finnish authority in charge of electrical equipment safety standards. All article numbers ending with “F” include fastening rivets. LMC 51 IP54 Multigate will lead through and seal cables as follows: 15 - 25 mm 1 pc7 - 13 mm 50 pcsTotal of 51 cables

MB 4 Multigate is suitable for leading through both low and medium power current cables as well as various types of tubing. It fits directly to a B-standard cut-out (or FL 13) MB 4 Multigate is metal reinforced cable gland plate made of various types of polymers. It meets the respective IP enclosure classes as it does not need separate gaskets or glands which makes it very easy to use, providing innumerable advantages in a single assembly unit. MB 4 Multigate is suitable for both outdoor and indoor use. MB 4 Multigate gives protection for limited ingress of dust and against water splashed from all directions. MB 4 Multigate is inspected and sertified by SGS FIMKO: the Finnish authority in charge of electrical equipment safety standards All article numbers ending with “F” include fastening rivets. MB 4 Multigate will lead through and seal cables as follows: 10 - 25 mm 4 pcsTotal of 4 cables

MB 5/11 Multigate is suitable for leading through both low and medium power current cables as well as various types of tubing. It fits directly to a B-standard cut-out (or FL 13). MB 5/11 Multigate is metal reinforced new type of cable gland plate made of various types of polymers. It meets the respective IP enclosure classes as it does not need separate gaskets or glands which makes it very easy to use, providing innumerable advantages in a single assembly unit. MB 5/11 Multigate is suitable for both out door and indoor use. MB 5/11 Multigate gives absolute protection against dust and both strong jets of water from all direction and against the effects of immersion between 15 cm and 1,0 m. MB 5/11 Multigate can be used instead of MB 5 Multigate. The configuration has the same openings than MB 5 and 6 extra. MB 5/11 Multigate is inspected and certified by SGS FIMKO: the Finnish authority in charge of electrical equipment safety standards. All article numbers ending with “F” include fastening rivets.
