Stripping tool - SUPER HS
Precise wire stripper for wires insulated with problematic material, Body made out of fibreglass reinforced polyamide (PA).
Stripping device for wires 0.5-0.75-1.5-2.5-4.0 mm² Adjustable length stop from 5-15 mm.
Length: 140 mm
Technical properties
- Depth of notch adjustable:
- No
- Longitudinal section:
- No
- Round edge:
- Yes
- Spiral cut:
- No
- Strip length adjustable:
- Yes
- With wire cutter:
- No
- Grip design:
- 1-component
- ESD tested:
- No
- With impact protection:
- No
- Insulated:
- No
- Stripping tool type:
- Självjusterande
- Isolation protection 1000 V:
- No
Show more
Item List
Accessories
Related products
Spare Parts
Product video
Documents
Manuals, Datasheets, Sketches & Drawings
Jokari Complete Range
Dimensions
- Total: 1
| Product Description | Strip range cross-section | Strip range AWG | Jaw length | Head width | Head height | MOQ | Unit | Length | Availability | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| SKALVERKTYG, 0.5-4.0, SVÅR ISOLERIN | 0.5-4 mm² | 20-12 . | 8.5 mm | 25.2 mm | 34.3 mm | 1 . | pcs | 140 mm |
Yes
|
|
|
- Total: 1
Similar Options
Approvals
- Total: 1
| Product Description | VDE tested | Isolation protection 1000 V | Availability | ||
|---|---|---|---|---|---|
| SKALVERKTYG, 0.5-4.0, SVÅR ISOLERIN | No | No |
Yes
|
|
|
- Total: 1
Technical Properties
- Total: 1
| Product Description | Depth of notch adjustable | Longitudinal section | Round edge | Spiral cut | Strip length adjustable | With wire cutter | Grip design | ESD tested | With impact protection | Insulated | Stripping tool type | Isolation protection 1000 V | Availability | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SKALVERKTYG, 0.5-4.0, SVÅR ISOLERIN | No | No | Yes | No | Yes | No | 1-component | No | No | No | Självjusterande | No |
Yes
|
|
|
- Total: 1
Other information
- Total: 1
| Product Description | ETIM-Class | ETIM-Release | Trademark | Product Group | Alternative SKU | Availability | ||
|---|---|---|---|---|---|---|---|---|
| SKALVERKTYG, 0.5-4.0, SVÅR ISOLERIN | EC002109 - Wire stripper pliers | 9.0 |
|
Wire Stripper Pliers (self adjusting) | SUPERHS |
Yes
|
|
|
