360 view
Product Properties
| With locking device (for mechanical tools) | No |
|---|---|
| Inserts exchangeable | No |
| Number of included inserts | 1 . |
| With automatic return | No |
| Cycle time | 2 s |
| Suitable for | Cable lugs and connectors |
| Construction/operation | Mechanical |
| For component | Non-insulated Cu tube and sheet terminals |
| Compression shape | Hexagon |
Dimensions
| Cross section | 6-50 mm² |
|---|---|
| MOQ | 1 . |
| Unit | pcs |
| Length | 380 mm |
Logistics
| Barcode | 733117632064 |
|---|---|
| Country of origin | TW |
| Item status | Stock item, normally in stock with reservation for in between sales. |
| MOQ | 1 . |
| Stock code | HDD 0650 |
| Taric code | 82032000 |
| Unit | pcs |
Approvals
Other info
| ETIM-Class | EC000168 - Crimp tool cable lugs, cable end sleeves, screen connection |
|---|---|
| ETIM-Release | 9.0 |
| Trademark | NEMIQ |
| Product Group | Two Hand (mechanical) |
| Alternative SKU | HDD0650 |
Compliance
| Conflict Minerals | N/A, Contains no conflict minerals |
|---|---|
| Extended Minerals | N/A, contains no extended minerals |
| Iron and Steel Sanction | Compliance |
| PFAS | No PFAS |
| REACH | No SVHC (Latest. 27 June 2024) |
| RoHS | RoHS 3 (2015/863) |
| SCIP | Not Applicable |
