Plintar (flatstift)
420 DS-serien
Kopplingsplintar med 6.3 x 0.8 mm flatstiftsanslutning.
Varje pol har 2 flatstiftsanslutningar samt en anslutning med M3 skruv.
Material: Polyamid UL94 V2
Färg: Grå
422-20 DS: 2-pol
423-30 DS: 3-pol
424-40 DS: 4-pol
426-60 DS: 6-pol
Technical properties
- Number of poles:
- 2 ., 3 ., 4 ., 6 .
- Type of electrical connection 1:
- Flat plug-in connection
- Type of electrical connection 2:
- Flat plug-in connection
- Material insulation body:
- Other
- Closing plate required:
- No
- Transparent:
- No
- Colour:
- Grey
Show more
Item List
Accessories
Related products
Spare Parts
Product video
Documents
Dimensions
- Total: 4
| Product Description | MOQ | Unit | Width/grid dimension | Height at lowest possible mounting height | Length | Availability | ||
|---|---|---|---|---|---|---|---|---|
| TERMINAL STRIP 2-POL | 200 . | pcs |
Yes
|
|
|
|||
| TERMINAL STRIP 3-POL | 150 . | pcs |
Yes
|
|
|
|||
| TERMINAL STRIP 4-POL | 1 . | pcs |
No
|
|
|
|||
| TERMINAL STRIP 6-POL | 1 . | pcs | 75 mm | 20 mm | 20 mm |
Yes
|
|
|
- Total: 4
Similar Options
Approvals
- Total: 4
| Product Description | Availability | ||
|---|---|---|---|
| TERMINAL STRIP 2-POL |
Yes
|
|
|
| TERMINAL STRIP 3-POL |
Yes
|
|
|
| TERMINAL STRIP 4-POL |
No
|
|
|
| TERMINAL STRIP 6-POL |
Yes
|
|
|
- Total: 4
Technical Properties
- Total: 4
| Product Description | Number of poles | Type of electrical connection 1 | Type of electrical connection 2 | Material insulation body | Closing plate required | Transparent | Colour | Availability | ||
|---|---|---|---|---|---|---|---|---|---|---|
| TERMINAL STRIP 2-POL | 2 . | Flat plug-in connection | Flat plug-in connection | No | Grey |
Yes
|
|
|
||
| TERMINAL STRIP 3-POL | 3 . | Flat plug-in connection | Flat plug-in connection | No | Grey |
Yes
|
|
|
||
| TERMINAL STRIP 4-POL | 4 . | Flat plug-in connection | Flat plug-in connection | No | Grey |
No
|
|
|
||
| TERMINAL STRIP 6-POL | 6 . | Flat plug-in connection | Flat plug-in connection | Other | No | No | Grey |
Yes
|
|
|
- Total: 4
Other information
- Total: 4
| Product Description | ETIM-Class | ETIM-Release | Trademark | Product Group | Alternative SKU | Availability | ||
|---|---|---|---|---|---|---|---|---|
| TERMINAL STRIP 2-POL | EC001284 - Single- and multi-pole terminal strip | 9.0 |
|
Terminal Strip - TAB | 422-20DS |
Yes
|
|
|
| TERMINAL STRIP 3-POL | EC001284 - Single- and multi-pole terminal strip | 9.0 |
|
Terminal Strip - TAB | 423-30DS |
Yes
|
|
|
| TERMINAL STRIP 4-POL | EC001284 - Single- and multi-pole terminal strip | 9.0 |
|
Terminal Strip - TAB | 424-40DS |
No
|
|
|
| TERMINAL STRIP 6-POL | EC001284 - Single- and multi-pole terminal strip | 9.0 |
|
Terminal Strip - TAB | 426-60DS |
Yes
|
|
|
- Total: 4
