Flaggkabelskor
FLB (rullad)
Material: Mässing
Ytbehandling: > 4µ Sn
Temperaturområde: -10 - 110°C
Technical properties
- Model:
- Bushing
- Max. current (Imax):
- 10 A, 15 A
- Insulation:
- Not isolated
- Colour insulation:
- Other
- With cam clamp:
- No
- With tap spreader:
- No
- Material insulation:
- Other
- Operating temperature:
- -10-110 °C
- Material:
- Bronze, Brass
- Neck type:
- Open barrel crimp
- Packaging:
- Loose piece
Show more
Item List
- Total: 6
- Total: 6
Accessories
Related products
Spare Parts
Product video
Documents
Manuals, Datasheets, Sketches & Drawings
CE Declaration of Conformity - Cable lugs
Conflict Minerals Reporting Template Version 6.31_Approved
Dimensions
- Total: 6
| Product Description | MOQ | Unit | Nominal cross section | Plug dimensions | Availability | ||
|---|---|---|---|---|---|---|---|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 0.5-1.5mm2, 6.3x0.8mm, BRONZE | 100 . | pcs | 0.5-1.5 mm² | Flat 6.3x0.8 mm |
Yes
|
|
|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 0.5-0.75mm2, 4.8x0.5mm | 100 . | pcs | 0.5-0.75 mm² | Flat 4.8x0.5 mm |
Yes
|
|
|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 0.5-0.75mm2, 4.8x0.8mm | 100 . | pcs | 0.5-0.75 mm² | Flat 4.8x0.8 mm |
Yes
|
|
|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 0.5-1.5mm2, 6.3x0.8mm | 100 . | pcs | 0.5-1.5 mm² | Flat 6.3x0.8 mm |
Yes
|
|
|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 1.5-2.5mm2, 4.8x0.5mm | 100 . | pcs | 1.5-2.5 mm² | Flat 4.8x0.5 mm |
Yes
|
|
|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 1.5-2.5mm2, 4.8x0.8mm | 100 . | pcs | 1.5-2.5 mm² | Flat 4.8x0.8 mm |
Yes
|
|
|
- Total: 6
Similar Options
Approvals
- Total: 6
| Product Description | Approved according to UR | Approved according to CE | With approval according to UL | Availability | ||
|---|---|---|---|---|---|---|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 0.5-1.5mm2, 6.3x0.8mm, BRONZE |
|
Yes
|
|
|
||
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 0.5-0.75mm2, 4.8x0.5mm |
|
|
Yes
|
|
|
|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 0.5-0.75mm2, 4.8x0.8mm |
|
|
Yes
|
|
|
|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 0.5-1.5mm2, 6.3x0.8mm |
|
Yes
|
|
|
||
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 1.5-2.5mm2, 4.8x0.5mm |
|
Yes
|
|
|
||
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 1.5-2.5mm2, 4.8x0.8mm |
|
Yes
|
|
|
- Total: 6
Technical Properties
- Total: 6
| Product Description | Model | Max. current (Imax) | Insulation | Colour insulation | With cam clamp | With tap spreader | Material insulation | Operating temperature | Material | Neck type | Packaging | Availability | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 0.5-1.5mm2, 6.3x0.8mm, BRONZE | Bushing | 10 A | Not isolated | Other | No | No | Other | Bronze | Open barrel crimp | Loose piece |
Yes
|
|
|
|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 0.5-0.75mm2, 4.8x0.5mm | Bushing | 10 A | Not isolated | Other | No | No | Other | -10-110 °C | Brass | Open barrel crimp | Loose piece |
Yes
|
|
|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 0.5-0.75mm2, 4.8x0.8mm | Bushing | 10 A | Not isolated | Other | No | No | Other | -10-110 °C | Brass | Open barrel crimp | Loose piece |
Yes
|
|
|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 0.5-1.5mm2, 6.3x0.8mm | Bushing | 10 A | Not isolated | Other | No | No | Other | -10-110 °C | Brass | Open barrel crimp | Loose piece |
Yes
|
|
|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 1.5-2.5mm2, 4.8x0.5mm | Bushing | 15 A | Not isolated | Other | No | No | Other | -10-110 °C | Brass | Open barrel crimp | Loose piece |
Yes
|
|
|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 1.5-2.5mm2, 4.8x0.8mm | Bushing | 15 A | Not isolated | Other | No | No | Other | -10-110 °C | Brass | Open barrel crimp | Loose piece |
Yes
|
|
|
- Total: 6
Other information
- Total: 6
| Product Description | ETIM-Class | ETIM-Release | Trademark | Product Group | Alternative SKU | Availability | ||
|---|---|---|---|---|---|---|---|---|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 0.5-1.5mm2, 6.3x0.8mm, BRONZE | EC000516 - Round or flat plug/receptacle | 9.0 |
|
Uninsulated Flag female disconnectors - Loose Pieces | B1507FLB-8BR |
Yes
|
|
|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 0.5-0.75mm2, 4.8x0.5mm | EC000516 - Round or flat plug/receptacle | 9.0 |
|
Uninsulated Flag female disconnectors - Loose Pieces | B1504FLB-5 |
Yes
|
|
|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 0.5-0.75mm2, 4.8x0.8mm | EC000516 - Round or flat plug/receptacle | 9.0 |
|
Uninsulated Flag female disconnectors - Loose Pieces | B1504FLB-8 |
Yes
|
|
|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 0.5-1.5mm2, 6.3x0.8mm | EC000516 - Round or flat plug/receptacle | 9.0 |
|
Uninsulated Flag female disconnectors - Loose Pieces | B1507FLB-8 |
Yes
|
|
|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 1.5-2.5mm2, 4.8x0.5mm | EC000516 - Round or flat plug/receptacle | 9.0 |
|
Uninsulated Flag female disconnectors - Loose Pieces | B2504FLB-5 |
Yes
|
|
|
| UNINSULATED FLAG FEMALE DISCONNECTORS ROLLED, 1.5-2.5mm2, 4.8x0.8mm | EC000516 - Round or flat plug/receptacle | 9.0 |
|
Uninsulated Flag female disconnectors - Loose Pieces | B2504FLB-8 |
Yes
|
|
|
- Total: 6
