Heat-Shrink Y-Branch Connector FS-series
FS-serien
Krympkabelsko med lim. För säker kabelskarvning från en till två ledare med samma kabelarea i dammiga och fuktiga miljöer.
Temperaturområde: -55° C till 110° C
Krymptemperatur: 121° C
Genomslagstålighet: 500 V
Technical properties
- Suitable for Class 2 conductor:
- Yes
- Suitable for Class 5 conductor:
- Yes
- Colour:
- White/Red, Red/Blue, Blue/Yellow, Yellow/Red
- Operating temperature:
- -55-110 °C
- Voltage max:
- 600V
- Packaging:
- Loose piece
Show more
Item List
- Total: 4
- Total: 4
Accessories
Related products
Spare Parts
Product video
Documents
Dimensions
- Total: 4
| Product Description | MOQ | Unit | Nominal cross section | Availability | ||
|---|---|---|---|---|---|---|
| SHRINK Y-BRANCH CONNECTOR WHITE/RED, 0.35-0.5mm2 | 25 . | pcs | 0.35-0.5 mm² |
Yes
|
|
|
| SHRINK Y-BRANCH CONNECTOR RED/BLUE, 0.75-1.0mm2 | 25 . | pcs | 0.75-1 mm² |
Yes
|
|
|
| SHRINK Y-BRANCH CONNECTOR BLUE/YELLOW, 1.5-2.5mm2 | 25 . | pcs | 1.5-2.5 mm² |
Yes
|
|
|
| SHRINK Y-BRANCH CONNECTOR YELLOW/RED, 4.0mm2 | 25 . | pcs | 4-6 mm² |
Yes
|
|
|
- Total: 4
Similar Options
Approvals
- Total: 4
| Product Description | Availability | ||
|---|---|---|---|
| SHRINK Y-BRANCH CONNECTOR WHITE/RED, 0.35-0.5mm2 |
Yes
|
|
|
| SHRINK Y-BRANCH CONNECTOR RED/BLUE, 0.75-1.0mm2 |
Yes
|
|
|
| SHRINK Y-BRANCH CONNECTOR BLUE/YELLOW, 1.5-2.5mm2 |
Yes
|
|
|
| SHRINK Y-BRANCH CONNECTOR YELLOW/RED, 4.0mm2 |
Yes
|
|
|
- Total: 4
Technical Properties
- Total: 4
| Product Description | Suitable for Class 2 conductor | Suitable for Class 5 conductor | Colour | Operating temperature | Voltage max | Packaging | Availability | ||
|---|---|---|---|---|---|---|---|---|---|
| SHRINK Y-BRANCH CONNECTOR WHITE/RED, 0.35-0.5mm2 | Yes | Yes | White/Red | -55-110 °C | 600V | Loose piece |
Yes
|
|
|
| SHRINK Y-BRANCH CONNECTOR RED/BLUE, 0.75-1.0mm2 | Yes | Yes | Red/Blue | -55-110 °C | 600V | Loose piece |
Yes
|
|
|
| SHRINK Y-BRANCH CONNECTOR BLUE/YELLOW, 1.5-2.5mm2 | Yes | Yes | Blue/Yellow | -55-110 °C | 600V | Loose piece |
Yes
|
|
|
| SHRINK Y-BRANCH CONNECTOR YELLOW/RED, 4.0mm2 | Yes | Yes | Yellow/Red | -55-110 °C | 600V | Loose piece |
Yes
|
|
|
- Total: 4
Other information
- Total: 4
| Product Description | ETIM-Class | ETIM-Release | Trademark | Product Group | Search Description | Alternative SKU | Availability | ||
|---|---|---|---|---|---|---|---|---|---|
| SHRINK Y-BRANCH CONNECTOR WHITE/RED, 0.35-0.5mm2 | EC001059 - Crimp splices for copper conductor | 9.0 |
|
Heat-Shrink Y-Branch Connector | FÖRGRENINGSSKARV, LIM, SKH2024EJ | FS0824SK |
Yes
|
|
|
| SHRINK Y-BRANCH CONNECTOR RED/BLUE, 0.75-1.0mm2 | EC001059 - Crimp splices for copper conductor | 9.0 |
|
Heat-Shrink Y-Branch Connector | FÖRGRENINGSSKARV, LIM, SKH2024EJ | FS1525SK |
Yes
|
|
|
| SHRINK Y-BRANCH CONNECTOR BLUE/YELLOW, 1.5-2.5mm2 | EC001059 - Crimp splices for copper conductor | 9.0 |
|
Heat-Shrink Y-Branch Connector | FÖRGRENINGSSKARV, LIM, SKH2024EJ | FS2527SK |
Yes
|
|
|
| SHRINK Y-BRANCH CONNECTOR YELLOW/RED, 4.0mm2 | EC001059 - Crimp splices for copper conductor | 9.0 |
|
Heat-Shrink Y-Branch Connector | FÖRGRENINGSSKARV, LIM, SKH2024EJ | FS4652SK |
Yes
|
|
|
- Total: 4
