Mini fuses with indicator diode
Mini fuse, BL-seriesThe built-in miniature lamp (Bulb or LED) lights-up after the fusing element has interrupted (show-blow).
Saves a lot of time troubleshooting.Maximum voltage: 32 V DCCurrent rating: 2-30 ASize excl. lamp (W x D x H): 11.3 x 4.1 x 16.7 mmLamp height: 3.5 mm
This part is also available in retail packaging (pin-pac) with barcode, then with the suffix -PP added to the end of the part number.
Technical properties
- Release characteristic:
- Medium time-lag
- Type of current:
- DC
- Colour code:
- Red, Blue, Grey, Yellow, Other, Purple, Green, Pink, Brown
- Nominal voltage DC:
- 32 V
- Max. current (Imax):
- 10 A, 15 A, 2 A, 20 A, 25 A, 3 A, 30 A, 4 A, 5 A, 7.5 A
- Nominal current:
- 10 A, 15 A, 2 A, 20 A, 25 A, 3 A, 30 A, 4 A, 5 A, 7.5 A
- Fuse type:
- Mini
- Packaging:
- Loose piece
Show more
Item List
- Total: 10
- Total: 10
Accessories
Related products
Spare Parts
Product video
Documents
Manuals, Datasheets, Sketches & Drawings
Conflict Minerals Reporting Template Version 6.31_Approved
Dimensions
- Total: 10
| Product Description | Width | MOQ | Unit | Length | Availability | ||
|---|---|---|---|---|---|---|---|
| BLADE FUSE, MINI, 2A GREY | 11.3 mm | 25 . | pcs | 18.7 mm |
Yes
|
|
|
| BLADE FUSE, MINI, 3A PURPLE | 11.3 mm | 25 . | pcs | 18.7 mm |
Yes
|
|
|
| BLADE FUSE, MINI, 4A PINK | 11.3 mm | 25 . | pcs | 18.7 mm |
Yes
|
|
|
| BLADE FUSE, MINI, 5A ORANGE | 11.3 mm | 25 . | pcs | 18.7 mm |
Yes
|
|
|
| BLADE FUSE, MINI, 7.5A BROWN | 11.3 mm | 25 . | pcs | 18.7 mm |
Yes
|
|
|
| BLADE FUSE, MINI, 10A RED | 11.3 mm | 25 . | pcs | 18.7 mm |
Yes
|
|
|
| BLADE FUSE, MINI, 15A BLUE | 11.3 mm | 25 . | pcs | 18.7 mm |
Yes
|
|
|
| BLADE FUSE, MINI, 20A YELLOW | 11.3 mm | 25 . | pcs | 18.7 mm |
Yes
|
|
|
| BLADE FUSE, MINI, 25A WHITE | 11.3 mm | 25 . | pcs | 18.7 mm |
Yes
|
|
|
| BLADE FUSE, MINI, 30A GREEN | 11.3 mm | 25 . | pcs | 18.7 mm |
Yes
|
|
|
- Total: 10
Similar Options
Approvals
- Total: 10
| Product Description | Availability | ||
|---|---|---|---|
| BLADE FUSE, MINI, 2A GREY |
Yes
|
|
|
| BLADE FUSE, MINI, 3A PURPLE |
Yes
|
|
|
| BLADE FUSE, MINI, 4A PINK |
Yes
|
|
|
| BLADE FUSE, MINI, 5A ORANGE |
Yes
|
|
|
| BLADE FUSE, MINI, 7.5A BROWN |
Yes
|
|
|
| BLADE FUSE, MINI, 10A RED |
Yes
|
|
|
| BLADE FUSE, MINI, 15A BLUE |
Yes
|
|
|
| BLADE FUSE, MINI, 20A YELLOW |
Yes
|
|
|
| BLADE FUSE, MINI, 25A WHITE |
Yes
|
|
|
| BLADE FUSE, MINI, 30A GREEN |
Yes
|
|
|
- Total: 10
Technical Properties
- Total: 10
| Product Description | Release characteristic | Type of current | Colour code | Nominal voltage DC | Max. current (Imax) | Nominal current | Fuse type | Packaging | Availability | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| BLADE FUSE, MINI, 2A GREY | Medium time-lag | DC | Grey | 32 V | 2 A | 2 A | Mini | Loose piece |
Yes
|
|
|
| BLADE FUSE, MINI, 3A PURPLE | Medium time-lag | DC | Purple | 32 V | 3 A | 3 A | Mini | Loose piece |
Yes
|
|
|
| BLADE FUSE, MINI, 4A PINK | Medium time-lag | DC | Pink | 32 V | 4 A | 4 A | Mini | Loose piece |
Yes
|
|
|
| BLADE FUSE, MINI, 5A ORANGE | Medium time-lag | DC | Other | 32 V | 5 A | 5 A | Mini | Loose piece |
Yes
|
|
|
| BLADE FUSE, MINI, 7.5A BROWN | Medium time-lag | DC | Brown | 32 V | 7.5 A | 7.5 A | Mini | Loose piece |
Yes
|
|
|
| BLADE FUSE, MINI, 10A RED | Medium time-lag | DC | Red | 32 V | 10 A | 10 A | Mini | Loose piece |
Yes
|
|
|
| BLADE FUSE, MINI, 15A BLUE | Medium time-lag | DC | Blue | 32 V | 15 A | 15 A | Mini | Loose piece |
Yes
|
|
|
| BLADE FUSE, MINI, 20A YELLOW | Medium time-lag | DC | Yellow | 32 V | 20 A | 20 A | Mini | Loose piece |
Yes
|
|
|
| BLADE FUSE, MINI, 25A WHITE | Medium time-lag | DC | Other | 32 V | 25 A | 25 A | Mini | Loose piece |
Yes
|
|
|
| BLADE FUSE, MINI, 30A GREEN | Medium time-lag | DC | Green | 32 V | 30 A | 30 A | Mini | Loose piece |
Yes
|
|
|
- Total: 10
Other information
- Total: 10
| Product Description | ETIM-Class | ETIM-Release | Product Group | Alternative SKU | Availability | ||
|---|---|---|---|---|---|---|---|
| BLADE FUSE, MINI, 2A GREY | EC002298 - Blade fuse | 9.0 | Blade fuses | BLMINI2 |
Yes
|
|
|
| BLADE FUSE, MINI, 3A PURPLE | EC002298 - Blade fuse | 9.0 | Blade fuses | BLMINI3 |
Yes
|
|
|
| BLADE FUSE, MINI, 4A PINK | EC002298 - Blade fuse | 9.0 | Blade fuses | BLMINI4 |
Yes
|
|
|
| BLADE FUSE, MINI, 5A ORANGE | EC002298 - Blade fuse | 9.0 | Blade fuses | BLMINI5 |
Yes
|
|
|
| BLADE FUSE, MINI, 7.5A BROWN | EC002298 - Blade fuse | 9.0 | Blade fuses | BLMINI7.5 |
Yes
|
|
|
| BLADE FUSE, MINI, 10A RED | EC002298 - Blade fuse | 9.0 | Blade fuses | BLMINI10 |
Yes
|
|
|
| BLADE FUSE, MINI, 15A BLUE | EC002298 - Blade fuse | 9.0 | Blade fuses | BLMINI15 |
Yes
|
|
|
| BLADE FUSE, MINI, 20A YELLOW | EC002298 - Blade fuse | 9.0 | Blade fuses | BLMINI20 |
Yes
|
|
|
| BLADE FUSE, MINI, 25A WHITE | EC002298 - Blade fuse | 9.0 | Blade fuses | BLMINI25 |
Yes
|
|
|
| BLADE FUSE, MINI, 30A GREEN | EC002298 - Blade fuse | 9.0 | Blade fuses | BLMINI30 |
Yes
|
|
|
- Total: 10
