Midi fuses with indicator diode
Midi fuse, BL-series
The built-in miniature lamp (Bulb or LED) lights-up after the fusing element has interrupted (show-blow).Saves a lot of time troubleshooting.
Maximum voltage: 32 V DCCurrent rating: 3-30 ASize excl. lamp (W x D x H): 18.8 x 5.3 x 18.7 mmLamp height: 3.5 mm
This part is also available in retail packaging (pin-pac) with barcode,then with the suffix -PP added to the end of the part number.
Technical properties
- Release characteristic:
- Medium time-lag
- Type of current:
- DC
- Colour code:
- Red, Blue, Yellow, Other, Purple, Green, Pink, Brown
- Nominal voltage DC:
- 32 V
- Max. current (Imax):
- 10 A, 15 A, 20 A, 25 A, 3 A, 30 A, 4 A, 5 A, 7.5 A
- Nominal current:
- 10 A, 15 A, 20 A, 25 A, 3 A, 30 A, 4 A, 5 A, 7.5 A
- Fuse type:
- Midi
- Packaging:
- Loose piece
Show more
Item List
- Total: 9
- Total: 9
Accessories
Related products
Spare Parts
Product video
Documents
Manuals, Datasheets, Sketches & Drawings
Conflict Minerals Reporting Template Version 6.31_Approved
Dimensions
- Total: 9
| Product Description | Width | MOQ | Unit | Length | Availability | ||
|---|---|---|---|---|---|---|---|
| BLADE FUSE, MIDI, 10A RED, DIOD | 18.8 mm | 25 . | pcs | 18.8 mm |
Yes
|
|
|
| BLADE FUSE, MIDI, 15A BLUE, DIOD | 18.8 mm | 25 . | pcs | 18.8 mm |
Yes
|
|
|
| BLADE FUSE, MIDI, 20A YELLOW, DIOD | 18.8 mm | 25 . | pcs | 18.8 mm |
Yes
|
|
|
| BLADE FUSE, MIDI, 25A WHITE | 18.8 mm | 25 . | pcs | 18.8 mm |
Yes
|
|
|
| BLADE FUSE, MIDI, 3A PURPLE, DIOD | 18.8 mm | 25 . | pcs | 18.8 mm |
Yes
|
|
|
| BLADE FUSE, MIDI, 30A GREEN | 18.8 mm | 25 . | pcs | 18.8 mm |
Yes
|
|
|
| BLADE FUSE, MIDI, 4A PINK | 18.8 mm | 25 . | pcs | 18.8 mm |
Yes
|
|
|
| BLADE FUSE, MIDI, 5A ORANGE, DIOD | 18.8 mm | 25 . | pcs | 18.8 mm |
Yes
|
|
|
| BLADE FUSE, MIDI, 7.5A BROWN, DIOD | 18.8 mm | 25 . | pcs | 18.8 mm |
Yes
|
|
|
- Total: 9
Similar Options
Approvals
- Total: 9
| Product Description | Availability | ||
|---|---|---|---|
| BLADE FUSE, MIDI, 10A RED, DIOD |
Yes
|
|
|
| BLADE FUSE, MIDI, 15A BLUE, DIOD |
Yes
|
|
|
| BLADE FUSE, MIDI, 20A YELLOW, DIOD |
Yes
|
|
|
| BLADE FUSE, MIDI, 25A WHITE |
Yes
|
|
|
| BLADE FUSE, MIDI, 3A PURPLE, DIOD |
Yes
|
|
|
| BLADE FUSE, MIDI, 30A GREEN |
Yes
|
|
|
| BLADE FUSE, MIDI, 4A PINK |
Yes
|
|
|
| BLADE FUSE, MIDI, 5A ORANGE, DIOD |
Yes
|
|
|
| BLADE FUSE, MIDI, 7.5A BROWN, DIOD |
Yes
|
|
|
- Total: 9
Technical Properties
- Total: 9
| Product Description | Release characteristic | Type of current | Colour code | Nominal voltage DC | Max. current (Imax) | Nominal current | Fuse type | Packaging | Availability | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| BLADE FUSE, MIDI, 10A RED, DIOD | Medium time-lag | DC | Red | 32 V | 10 A | 10 A | Midi | Loose piece |
Yes
|
|
|
| BLADE FUSE, MIDI, 15A BLUE, DIOD | Medium time-lag | DC | Blue | 32 V | 15 A | 15 A | Midi | Loose piece |
Yes
|
|
|
| BLADE FUSE, MIDI, 20A YELLOW, DIOD | Medium time-lag | DC | Yellow | 32 V | 20 A | 20 A | Midi | Loose piece |
Yes
|
|
|
| BLADE FUSE, MIDI, 25A WHITE | Medium time-lag | DC | Other | 32 V | 25 A | 25 A | Midi | Loose piece |
Yes
|
|
|
| BLADE FUSE, MIDI, 3A PURPLE, DIOD | Medium time-lag | DC | Purple | 32 V | 3 A | 3 A | Midi | Loose piece |
Yes
|
|
|
| BLADE FUSE, MIDI, 30A GREEN | Medium time-lag | DC | Green | 32 V | 30 A | 30 A | Midi | Loose piece |
Yes
|
|
|
| BLADE FUSE, MIDI, 4A PINK | Medium time-lag | DC | Pink | 32 V | 4 A | 4 A | Midi | Loose piece |
Yes
|
|
|
| BLADE FUSE, MIDI, 5A ORANGE, DIOD | Medium time-lag | DC | Other | 32 V | 5 A | 5 A | Midi | Loose piece |
Yes
|
|
|
| BLADE FUSE, MIDI, 7.5A BROWN, DIOD | Medium time-lag | DC | Brown | 32 V | 7.5 A | 7.5 A | Midi | Loose piece |
Yes
|
|
|
- Total: 9
Other information
- Total: 9
| Product Description | ETIM-Class | ETIM-Release | Product Group | Alternative SKU | Availability | ||
|---|---|---|---|---|---|---|---|
| BLADE FUSE, MIDI, 10A RED, DIOD | EC002298 - Blade fuse | 7.0 | Blade fuses | BLMIDI10 |
Yes
|
|
|
| BLADE FUSE, MIDI, 15A BLUE, DIOD | EC002298 - Blade fuse | 7.0 | Blade fuses | BLMIDI15 |
Yes
|
|
|
| BLADE FUSE, MIDI, 20A YELLOW, DIOD | EC002298 - Blade fuse | 7.0 | Blade fuses | BLMIDI20 |
Yes
|
|
|
| BLADE FUSE, MIDI, 25A WHITE | EC002298 - Blade fuse | 7.0 | Blade fuses | BLMIDI25 |
Yes
|
|
|
| BLADE FUSE, MIDI, 3A PURPLE, DIOD | EC002298 - Blade fuse | 7.0 | Blade fuses | BLMIDI3 |
Yes
|
|
|
| BLADE FUSE, MIDI, 30A GREEN | EC002298 - Blade fuse | 7.0 | Blade fuses | BLMIDI30 |
Yes
|
|
|
| BLADE FUSE, MIDI, 4A PINK | EC002298 - Blade fuse | 7.0 | Blade fuses | BLMIDI4 |
Yes
|
|
|
| BLADE FUSE, MIDI, 5A ORANGE, DIOD | EC002298 - Blade fuse | 7.0 | Blade fuses | BLMIDI5 |
Yes
|
|
|
| BLADE FUSE, MIDI, 7.5A BROWN, DIOD | EC002298 - Blade fuse | 7.0 | Blade fuses | BLMIDI7.5 |
Yes
|
|
|
- Total: 9
