Change-over rocker switch - INTEGRO Berker
Change-over rocker switch1-Pole
16 A, 250 VAC
Size: 55.5 mm x 55.5 mm
Screw terminals
Technical properties
- Nominal voltage:
- 250 V
- Connection type:
- Screwed terminal
- Rated current:
- 10 A
- Mounting method:
- Built-in installation
- Anti-bacterial treatment:
- No
- Surface finishing:
- Glossy, Matt
- Compatible with Apple HomeKit:
- No
- Compatible with Google Assistant:
- No
- Compatible with Amazon Alexa:
- No
- IFTTT support available:
- No
- Assembly arrangement:
- Basic element with central cover plate
- Wiring system:
- Two-way switch
- Method of operation:
- Rocker/button
- Push button switch:
- No
- With mounting plate:
- No
- Label space/information surface:
- Yes, No
- Illumination:
- No
- Function lighting:
- Other
- Type of lighting:
- LED exchangeable
- Feedback-signal contact:
- No
- Heating switch:
- No
- Washing machine switch:
- No
- Type of fastening:
- Screw mounting
- RAL-number (similar):
- 9010 ., 8017 ., 7021 ., 9005 ., 9023 ., 9006 .
- Min. depth of built-in installation box:
- 16 mm
- Colour:
- White, Brown, Anthracite, Black, Chrome
- Surface protection:
- Untreated
- Material:
- Plastic
- Type of product:
- Strömbrytare
- Variant:
- 250V
- Built-in depth:
- 15.5 mm
Show more
Item List
- Total: 8
- Total: 8
Accessories
Related products
Spare Parts
Product video
Documents
Dimensions
- Total: 8
| Product Description | Built-in depth | Number of modules (module system) | Device width | Device height | Device depth | Number of rockers | Switching current for fluorescent lamps | Min. depth of built-in installation box | MOQ | Unit | Nominal voltage | Availability | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ROCKER SWITCH CHANGE-OVER, 250V BROWN MATT, INTEGRO | 15.5 mm | 1 . | 55.5 mm | 55.5 mm | 25 mm | 1 . | 10 AX | 16 mm | 10 . | pcs | 250 V |
No
|
|
|
| ROCKER SWITCH CHANGE-OVER, 250V POLAR WHITE GLOSSY, INTEGRO | 15.5 mm | 1 . | 55.5 mm | 55.5 mm | 25 mm | 1 . | 10 AX | 16 mm | 10 . | pcs | 250 V |
Yes
|
|
|
| ROCKER SWITCH CHANGE-OVER, 250V ANTHRACITE MATT, INTEGRO | 15.5 mm | 1 . | 55.5 mm | 55.5 mm | 25 mm | 1 . | 10 AX | 16 mm | 10 . | pcs | 250 V |
Yes
|
|
|
| ROCKER SWITCH CHANGE-OVER, 250V BLACK GLOSSY FLOW/PURE | 15.5 mm | 1 . | 55.5 mm | 55.5 mm | 25 mm | 1 . | 10 AX | 16 mm | 10 . | pcs | 250 V |
No
|
|
|
| ROCKER SWITCH CHANGE-OVER, 250V CHROME GLOSSY, INTEGRO | 15.5 mm | 1 . | 55.5 mm | 55.5 mm | 25 mm | 1 . | 10 AX | 16 mm | 10 . | pcs | 250 V |
Yes
|
|
|
| ROCKER SWITCH CHANGE-OVER, 250V CHROME MATT, INTEGRO | 15.5 mm | 1 . | 55.5 mm | 55.5 mm | 25 mm | 1 . | 10 AX | 16 mm | 10 . | pcs | 250 V |
No
|
|
|
| ROCKER SWITCH CHANGE-OVER, 250V CHROMELACK MATT, INTEGRO | 15.5 mm | 1 . | 55.5 mm | 55.5 mm | 25 mm | 1 . | 10 AX | 16 mm | 10 . | pcs | 250 V |
No
|
|
|
| ROCKER SWITCH CHANGE-OVER, 250V POLAR WHITE GLOSSY, CLASSIC | 15.5 mm | 1 . | 55.5 mm | 55.5 mm | 25 mm | 1 . | 10 AX | 16 mm | 10 . | pcs | 250 V |
No
|
|
|
- Total: 8
Similar Options
Approvals
- Total: 8
- Total: 8
Technical Properties
- Total: 8
| Product Description | Nominal voltage | Connection type | Rated current | Mounting method | Anti-bacterial treatment | Surface finishing | Compatible with Apple HomeKit | Compatible with Google Assistant | Compatible with Amazon Alexa | IFTTT support available | Assembly arrangement | Wiring system | Method of operation | Push button switch | With mounting plate | Label space/information surface | Illumination | Function lighting | Type of lighting | Feedback-signal contact | Heating switch | Washing machine switch | Type of fastening | RAL-number (similar) | Min. depth of built-in installation box | Colour | Surface protection | Material | Type of product | Variant | Built-in depth | Availability | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ROCKER SWITCH CHANGE-OVER, 250V BROWN MATT, INTEGRO | 250 V | Screwed terminal | 10 A | Built-in installation | No | Matt | No | No | No | No | Basic element with central cover plate | Two-way switch | Rocker/button | No | No | Yes | No | Other | LED exchangeable | No | No | No | Screw mounting | 8017 . | 16 mm | Brown | Untreated | Plastic | Strömbrytare | 250V | 15.5 mm |
No
|
|
|
| ROCKER SWITCH CHANGE-OVER, 250V POLAR WHITE GLOSSY, INTEGRO | 250 V | Screwed terminal | 10 A | Built-in installation | No | Glossy | No | No | No | No | Basic element with central cover plate | Two-way switch | Rocker/button | No | No | Yes | No | Other | LED exchangeable | No | No | No | Screw mounting | 9010 . | 16 mm | White | Untreated | Plastic | Strömbrytare | 250V | 15.5 mm |
Yes
|
|
|
| ROCKER SWITCH CHANGE-OVER, 250V ANTHRACITE MATT, INTEGRO | 250 V | Screwed terminal | 10 A | Built-in installation | No | Matt | No | No | No | No | Basic element with central cover plate | Two-way switch | Rocker/button | No | No | No | No | No | Screw mounting | 7021 . | 16 mm | Anthracite | Plastic | Strömbrytare | 250V | 15.5 mm |
Yes
|
|
|
|||||
| ROCKER SWITCH CHANGE-OVER, 250V BLACK GLOSSY FLOW/PURE | 250 V | Screwed terminal | 10 A | Built-in installation | No | Glossy | No | No | No | No | Basic element with central cover plate | Two-way switch | Rocker/button | Yes | No | No | No | Screw mounting | 9005 . | 16 mm | Black | Plastic | Strömbrytare | 250V | 15.5 mm |
No
|
|
|
||||||
| ROCKER SWITCH CHANGE-OVER, 250V CHROME GLOSSY, INTEGRO | 250 V | Screwed terminal | 10 A | Built-in installation | No | Glossy | No | No | No | No | Basic element with central cover plate | Two-way switch | Rocker/button | No | No | No | Screw mounting | 9023 . | 16 mm | Chrome | Plastic | Strömbrytare | 250V | 15.5 mm |
Yes
|
|
|
|||||||
| ROCKER SWITCH CHANGE-OVER, 250V CHROME MATT, INTEGRO | 250 V | Screwed terminal | 10 A | Built-in installation | No | Matt | No | No | No | No | Basic element with central cover plate | Two-way switch | Rocker/button | No | No | No | Screw mounting | 9006 . | 16 mm | Chrome | Plastic | Strömbrytare | 250V | 15.5 mm |
No
|
|
|
|||||||
| ROCKER SWITCH CHANGE-OVER, 250V CHROMELACK MATT, INTEGRO | 250 V | Screwed terminal | 10 A | Built-in installation | No | Matt | No | No | No | No | Basic element with central cover plate | Two-way switch | Rocker/button | Yes | No | No | No | Screw mounting | 9006 . | 16 mm | Chrome | Plastic | Strömbrytare | 250V | 15.5 mm |
No
|
|
|
||||||
| ROCKER SWITCH CHANGE-OVER, 250V POLAR WHITE GLOSSY, CLASSIC | 250 V | Screwed terminal | 10 A | Built-in installation | No | Glossy | No | No | No | No | Basic element with central cover plate | Two-way switch | Rocker/button | No | No | No | No | No | Screw mounting | 9010 . | 16 mm | White | Plastic | Strömbrytare | 250V | 15.5 mm |
No
|
|
|
- Total: 8
Other information
- Total: 8
| Product Description | ETIM-Class | ETIM-Release | Trademark | Product Group | Search Description | Alternative SKU | Availability | ||
|---|---|---|---|---|---|---|---|---|---|
| ROCKER SWITCH CHANGE-OVER, 250V BROWN MATT, INTEGRO | EC001590 - Installation switch | 9.0 |
|
Installation switches | 936562501 | 171436562501 |
No
|
|
|
| ROCKER SWITCH CHANGE-OVER, 250V POLAR WHITE GLOSSY, INTEGRO | EC001590 - Installation switch | 9.0 |
|
Installation switches | 936562509 | 171436562509 |
Yes
|
|
|
| ROCKER SWITCH CHANGE-OVER, 250V ANTHRACITE MATT, INTEGRO | EC001590 - Installation switch | 9.0 |
|
Installation switches | 936562505 | 171436562505 |
Yes
|
|
|
| ROCKER SWITCH CHANGE-OVER, 250V BLACK GLOSSY FLOW/PURE | EC001590 - Installation switch | 9.0 |
|
Installation switches | 936562510 | 171436562510 |
No
|
|
|
| ROCKER SWITCH CHANGE-OVER, 250V CHROME GLOSSY, INTEGRO | EC001590 - Installation switch | 9.0 |
|
Installation switches | 936562518 | 171436562518 |
Yes
|
|
|
| ROCKER SWITCH CHANGE-OVER, 250V CHROME MATT, INTEGRO | EC001590 - Installation switch | 9.0 |
|
Installation switches | 936562528 | 171436562528 |
No
|
|
|
| ROCKER SWITCH CHANGE-OVER, 250V CHROMELACK MATT, INTEGRO | EC001590 - Installation switch | 9.0 |
|
Installation switches | 936562568 | 171436562568 |
No
|
|
|
| ROCKER SWITCH CHANGE-OVER, 250V POLAR WHITE GLOSSY, CLASSIC | EC001590 - Installation switch | 9.0 |
|
Installation switches | 9365609 | 1714365609 |
No
|
|
|
- Total: 8
