WT 10-04
Pressverktyg med locator för rullpressning av triadkontakter. Har löstagbar CSV 10-back.
Det finns 6 uttag i verktygets pressback från 0.25-1.5 mm².
Pressverktyget är en ratchettång med inbyggd returspärr som garanterar att kontaktpressningen fullföljs.
Längd: 195 mm
- Number of crimps:
- 1
- With locking device (for mechanical tools):
- Yes
- Inserts exchangeable:
- No
- Number of included inserts:
- 1 .
- With automatic return:
- Yes
- Cycle time:
- 2 s
- Suitable for:
- Cable lugs and connectors
- Construction/operation:
- Mechanical
- For component:
- Plastdon
- Compression shape:
- Other
Crimp tool – ERG 740
Pressverktyg för Shield-Kon jordningshylsor (RSK).
En ratchettång med inbyggd returspärr som garanterar att kontaktpressningen fullföljs (Shure-Stake).
- Number of crimps:
- 1
- With locking device (for mechanical tools):
- Yes
- Inserts exchangeable:
- Yes, No
- Number of included inserts:
- 0-1 .
- With automatic return:
- Yes
- Cycle time:
- 2 s
- Suitable for:
- Screen connector
- Construction/operation:
- Mechanical
- For component:
- Skärmjordning
- Compression shape:
- Round compression, Other
Crimp tool – ERG 2004
ERG 2004 är ett pressverktyg för oisolerade flaggkabelskor STA-KON typ AB, C.
En ratchettång med inbyggd returspärr som garanterar att kontaktpressningen fullföljs.
- Number of crimps:
- 1
- With locking device (for mechanical tools):
- Yes
- Inserts exchangeable:
- No
- Number of included inserts:
- 1 .
- With automatic return:
- Yes
- Cycle time:
- 2 s
- Suitable for:
- Cable lugs and connectors
- Construction/operation:
- Mechanical
- For component:
- Non-insulated terminals, roller compaction
- Compression shape:
- Roll compression (shrinking)
Crimp tool - ERG4000KE
A versatile tool, one frame with a selection of interchangeable dies covers a wide range of shield diameters in the Hexagonal range. Shure-Stake™ mechanism: once pressing has commenced, the tool can be re-opened only after successful completion of the crimping cycle.
Length: 265 mm
Weight: 550 g
The frame can be combined with several crimoing dies according to chart under Dokuments. Dies to be ordered separately.
- Number of crimps:
- 1
- With locking device (for mechanical tools):
- Yes
- Inserts exchangeable:
- Yes
- With automatic return:
- Yes
- Suitable for:
- Cable lugs and connectors
- Construction/operation:
- Mechanical
- Compression shape:
- Hexagon
TBEF
TBEF är den vanligaste typen av metallskyddsslang.
Lämplig för många olika typer av installationer i
miljöer utan extrema ytterligheter. Resistant mot syra och olja, självslocknande mantel av PVC.
Konstruktion: Galvaniserad stålspiral med bomullspackning. Yttermantel av PVC.
Temperatur, Stationär: -25º C till +105º C
Flexande: -5º C till +105º C
Skyddsklass: IP 67 (med korrekt anslutna T&B kopplingar)
Provspänning: 2000 V
Isoleringsresistans: 100 MOhm
Färg: Grå, svart
- Compressive strength:
- 1250 N
- Bending strength:
- Flexible
- Tensile strength:
- 1000-2500 N
- Sheathing material 1st coating:
- Polyvinyl chloride (PVC)
- Sheathing material 2nd coating (exterior):
- Not sheathed
- Sealing:
- Special fibre sealing
- Suitable for EX-applications:
- No
- Degree of protection (IP):
- IP67
- Colour:
- Black, Grey
- Surface protection:
- Galvanised
- Material:
- Steel
- Approved according to BWB:
- No
- Approved according to VDE-EMV/emc:
- No
- Approved according to FI:
- No
- VDE tested:
- Yes
- Approved according to CSA:
- No
- With approval according to UL:
- No
TC 826
TC 826-serien
4-vägs skruvsockel med mycket låg profil för en eller två buntband.
Bandbredd: Upp till 4.8 mm
Material: Polyamid 6.6
Temperaturområde: -40º C till +85º C
Brännbarhetsklass: UL 94 V-2
Färg: Naturell
Övrigt: Halogenfri, silikonfri
Fabrikat: Thomas & Betts
- Availability:
-
No
- Suitable for Class 2 conductor:
- Yes
- Suitable for Class 5 conductor:
- Yes
- Reel/roll packaging:
- No
- Flange shape:
- Ring shape
- According to DIN:
- No
- Insulation:
- Partially isolated
- Colour insulation:
- Blue
- Sleeve form:
- Short
- Suitable for solid cores:
- No
- Suitable for stranded conductors:
- Yes
- Suitable for fine strand conductors:
- Yes
- Suitable for high temperatures (to 650 °C):
- No
- Suitable for insulated varnish:
- No
- Suitable for round conductors:
- Yes
- Suitable for flat conductors:
- No
- Surface protection:
- Tinned
- Material:
- Copper
- Voltage max:
- 600V
- Halogen free:
- No
- Suitable for Class 2 conductor:
- Yes
- Suitable for Class 5 conductor:
- Yes
- Reel/roll packaging:
- No
- Max. current (Imax):
- 27-88 A
- Flange shape:
- Ring shape
- According to DIN:
- No
- Insulation:
- Partially isolated
- Colour insulation:
- Blue, Red
- Sleeve form:
- Short
- Suitable for solid cores:
- No
- Suitable for stranded conductors:
- Yes
- Suitable for fine strand conductors:
- Yes
- Suitable for high temperatures (to 650 °C):
- No
- Suitable for insulated varnish:
- No
- Suitable for round conductors:
- Yes
- Suitable for flat conductors:
- No
- Surface protection:
- Tinned
- Material insulation:
- Polyamide (PA)
- Fire classification:
- According to UL94V2
- Material:
- Copper
- Voltage max:
- 600V
- Halogen free:
- Yes, No
- Suitable for Class 2 conductor:
- Yes
- Suitable for Class 5 conductor:
- Yes
- Reel/roll packaging:
- No
- Max. current (Imax):
- 27 A
- Flange shape:
- Fork shape
- According to DIN:
- No
- Insulation:
- Partially isolated
- Colour insulation:
- Blue
- Sleeve form:
- Short
- Suitable for solid cores:
- No
- Suitable for stranded conductors:
- Yes
- Suitable for fine strand conductors:
- Yes
- Suitable for high temperatures (to 650 °C):
- No
- Suitable for insulated varnish:
- No
- Suitable for round conductors:
- Yes
- Suitable for flat conductors:
- No
- Surface protection:
- Tinned
- Material insulation:
- Polyamide (PA)
- Fire classification:
- According to UL94V2
- Material:
- Copper
- Voltage max:
- 600V
- Halogen free:
- Yes
- Suitable for Class 2 conductor:
- Yes
- Suitable for Class 5 conductor:
- Yes
- Reel/roll packaging:
- No
- Model:
- Bushing
- Max. current (Imax):
- 15 A
- Insulation:
- Partially isolated
- Colour insulation:
- Blue
- With cam clamp:
- No
- With tap spreader:
- No
- Material insulation:
- Polyamide (PA)
- Fire classification:
- According to UL94V2
- Material:
- Brass
- Voltage max:
- 300V
- Halogen free:
- Yes
- Model:
- Standard version
- Number of branches:
- 0 N/A
- Insulation:
- None
- Colour insulation:
- N/A
- Sleeve form:
- Short
- Suitable for solid cores:
- No
- Suitable for stranded conductors:
- No
- Suitable for fine strand conductors:
- No
- Suitable for high temperatures (to 650 °C):
- No
- Suitable for insulated varnish:
- Yes
- Suitable for round conductors:
- No
- Suitable for flat conductors:
- Yes
- For pull protected connections:
- No
- Voltage level:
- Up to 35 kV
- Type of connection:
- Other
- Surface protection:
- Tinned
- Material:
- Copper
Toppskarvar, skruvtyp
Gängade toppskarvar
Kablarnas skalade ändar skruvas in och ihop för kontaktering.
Spänning: 600 V
Temperatur: 105º C
- Number of cores:
- 2-5 .
- Colour:
- Yellow
- Connector type:
- Toppskarv, skruvbar
- Suitable for Class 2 conductor:
- Yes
- Suitable for Class 5 conductor:
- Yes
- Model:
- Bushing
- Max. current (Imax):
- 15 A
- Insulation:
- Fully isolated
- Colour insulation:
- Blue
- With cam clamp:
- No
- With tap spreader:
- No
- Material insulation:
- Polyamide (PA)
- Fire classification:
- According to UL94V2
- Material:
- Brass
- Voltage max:
- 300V
- Halogen free:
- Yes
Safe-Ty, low profile cable ties, plastic
Safe-Ty is a plastic tie, ideal for use where precision bundling is required and clearance is a necessity.
A unique saddle back design curves to form a snug fit around the bundle, and allows for easy pull-through in bulkheads and any other tight spaces.
Colour: Natural, UV-resistant black
Other properties: UV-resistant, silicone free
- Detectable:
- No
- Min. tensile strength:
- 80 N
- Model:
- Internal toothing
- Material quality:
- Polyamide (PA)
- Band closure:
- Plastic lip/-cam
- UV-stable acc. ASTM D6779:
- Yes, No
- Transparent:
- No
- Fluorescent:
- No
- Solvable fastener:
- No
- Text strip:
- None
- Type of fastening:
- None
- Colour:
- Black, Natural colour
- Surface protection:
- Untreated
- Material:
- Plastic
- Halogen free:
- Yes
- Max. tensile force:
- 80 N
Ty-Rap, cable ties, metal barb - TYC-series
Extra flexible.
Material cable tie: Polyamide 12
Material looking tongue: Stainless steel 316
Other features: UV-resistant
- Detectable:
- No
- Min. tensile strength:
- 150-380 N
- Model:
- Without toothing
- Material quality:
- Polyamide (PA)
- Band closure:
- Steel nose
- UV-stable acc. ASTM D6779:
- Yes
- Transparent:
- No
- Fluorescent:
- No
- Solvable fastener:
- No
- Text strip:
- None
- Type of fastening:
- None
- Colour:
- Black
- Surface protection:
- Untreated
- Material:
- Plastic
- Halogen free:
- Yes
- Max. tensile force:
- 150-380 N
Ty-Rap, cable ties, metal barb - TYP-series
Better chemical properties than polyamide.
Material locking tongue: Stainless steel 316
Flammability class: UL 94 HB
Other features: UV-resistant
- Detectable:
- No
- Min. tensile strength:
- 80-540 N
- Model:
- Without toothing
- Material quality:
- Polypropylene (PP)
- Band closure:
- Steel nose
- UV-stable acc. ASTM D6779:
- Yes
- Transparent:
- No
- Fluorescent:
- No
- Solvable fastener:
- No
- Text strip:
- None
- Type of fastening:
- None
- Colour:
- Black
- Surface protection:
- Untreated
- Material:
- Plastic
- Halogen free:
- Yes
- Max. tensile force:
- 80-540 N
- Inflammability class of insulation material according to with UL94:
- Other
Ty-Rap, cable ties, metal barb - TYZ-series
Good chemical features for extreme temperatures. The best plastic material cable ties are made in.
Material cable tie: Fluoropolymer ETFE
Material locking tongue: Stainless steel 316
Other features: UV-resistant
Color: Aquamarine
- Detectable:
- No
- Min. tensile strength:
- 80-540 N
- Model:
- Without toothing
- Material quality:
- ETFE
- Band closure:
- Steel nose
- UV-stable acc. ASTM D6779:
- Yes
- Transparent:
- No
- Fluorescent:
- No
- Solvable fastener:
- No
- Text strip:
- None
- Type of fastening:
- None
- Colour:
- Green
- Surface protection:
- Untreated
- Material:
- Plastic
- Halogen free:
- Yes
- Max. tensile force:
- 80-540 N
Ty-Rap, cable ties, metal barb - TY MFR-series
Flame retardant according to UL 94 V-0.
Material cable tie: Polyamid 6.6
Material locking tongue: Stainless steel 316
Flammability class: UL 94 V-0
- Detectable:
- No
- Min. tensile strength:
- 80-540 N
- Model:
- Without toothing
- Material quality:
- Polyamide (PA)
- Band closure:
- Steel nose
- UV-stable acc. ASTM D6779:
- No
- Transparent:
- No
- Fluorescent:
- No
- Solvable fastener:
- No
- Text strip:
- None
- Type of fastening:
- None
- Colour:
- White
- Surface protection:
- Untreated
- Material:
- Plastic
- Halogen free:
- Yes
- Max. tensile force:
- 80-540 N
- Approved according to Lloyd's Register TA:
- Yes
- MIL approval:
- Yes
Plastic cable ties with tranverse identification tag
Material cable tie: Polyamid 6.6
Material locking tongue: Stainless steel 316
Other features: Silikonfri
Approvals: TY 51 M is approved according to MIL (MS-3368-5)
The identification tag is placed inside the locking device.
- Detectable:
- No
- Min. tensile strength:
- 80 N
- Model:
- Without toothing
- Material quality:
- Polyamide (PA)
- Band closure:
- Steel nose
- UV-stable acc. ASTM D6779:
- No
- Transparent:
- No
- Fluorescent:
- No
- Solvable fastener:
- No
- Text strip:
- Adjacent to bundle
- Type of fastening:
- None
- Colour:
- Natural colour, Orange, Yellow
- Surface protection:
- Untreated
- Material:
- Plastic
- Halogen free:
- Yes
- Max. tensile force:
- 80 N
Plastic cable ties with longitudinal identification tag
Material locking tongue: Stainless steel 316
Temperature range: -40°C - +85°C
Other features: Silicone free
Approvals: MIL: MS-3368-1, -2, -3, -4
TY 46 is available with 1, 2, 3 or 4 cable ties on the same identification tag.
L-4-18ID-9-M is a Ty-Fast plastic cable tie without steel barb. It is not UL approved.
- Detectable:
- No
- Min. tensile strength:
- 220 N
- Model:
- Without toothing
- Material quality:
- Polyamide (PA)
- Band closure:
- Steel nose
- UV-stable acc. ASTM D6779:
- Yes, No
- Transparent:
- No
- Fluorescent:
- No
- Solvable fastener:
- No
- Text strip:
- Adjacent to bundle
- Type of fastening:
- None
- Colour:
- Black, Natural colour
- Surface protection:
- Untreated
- Material:
- Plastic
- Halogen free:
- Yes
- Max. tensile force:
- 220 N
Ty-Rap, plastic cable ties with mounting hole
Characteristics
Can be directly mounted on to a support with screws, bolts or rivets. Mounting and bundling in one maintenance-friendly assembly.
Typical application: cable harness manufacture and pre- and end- mounting of bundles andparts. Maintenance friendly mounting of cables, tubes and parts in all types and sizes of machines and installations - indoor and outdoor.
- Detectable:
- No
- Min. tensile strength:
- 80-540 N
- Model:
- Without toothing
- Material quality:
- Polyamide (PA)
- Band closure:
- Plastic lip/-cam, Steel nose
- UV-stable acc. ASTM D6779:
- Yes, No
- Transparent:
- No
- Fluorescent:
- No
- Solvable fastener:
- No
- Text strip:
- None
- Type of fastening:
- Screw hole
- Colour:
- Black, Natural colour
- Surface protection:
- Untreated
- Material:
- Plastic
- Halogen free:
- Yes
- Max. tensile force:
- 80-540 N
- Approved according to Lloyd's Register TA:
- Yes
- VG approval:
- Yes
Ty-Rap, plastic cable ties for panel mounting
Cable ties for panel mountingCable ties for panel mounting up to 4.0 mm, anchor type.
The Ty-Rap non-magnetic stainless steel locking device ensures a strong, reliable and long lasting fastening under adverse conditions. The locking tongue of stainless steel in the nylon head gives the cable ties a superior locking in all temperatures and environments.The smooth, notchless body reduces stress concentration points and ensures a precise fastening.
All Ty-Rap cable ties with locking device meets and exceeds the performance requirements according to MIL-S--23190 (USA).
Smooth and rounded edges on head and strap provides a comfortable handling and prevents sharp edges from damaging the cables.
Material locking tongue: Stainless steel 316
Color: Natural, UV-resistant black
Other features: Silicone free
Only TY 38 M and TY 538 M are UL approved.
- Detectable:
- No
- Min. tensile strength:
- 130-220 N
- Model:
- Without toothing
- Material quality:
- Polyamide (PA)
- Band closure:
- Steel nose
- UV-stable acc. ASTM D6779:
- Yes, No
- Transparent:
- No
- Fluorescent:
- No
- Solvable fastener:
- No
- Text strip:
- None
- Type of fastening:
- Plug-in anchor/plug-in cam
- Colour:
- Black, Natural colour
- Surface protection:
- Untreated
- Material:
- Plastic
- Halogen free:
- Yes
- Max. tensile force:
- 130-220 N
Ty-Rap, releasable cable ties, plastic - TYR-series
Releasable cable ties for temporary but strong bundling. The cable ties can be reused several times.
Fast and very simple application.
Other features: Silicone free
- Detectable:
- No
- Min. tensile strength:
- 220 N
- Model:
- Internal toothing
- Material quality:
- Polyamide (PA)
- Band closure:
- Plastic lip/-cam
- UV-stable acc. ASTM D6779:
- No
- Transparent:
- No
- Fluorescent:
- No
- Solvable fastener:
- Yes
- Text strip:
- None
- Type of fastening:
- None
- Colour:
- Natural colour
- Surface protection:
- Untreated
- Material:
- Plastic
- Halogen free:
- Yes
- Max. tensile force:
- 220 N
Ty-Rap, releasable cable ties, plastic - TY 409-series
Releasable cable tie with incorporated fastener. Rugged one-piece construction, ideal for heavy-duty applications.
Can be reused several times.
Color: UV-resistant black
Other features: UV-resisitant, halogene free, silicone free
- Detectable:
- No
- Min. tensile strength:
- 890 N
- Model:
- Internal toothing
- Material quality:
- Polyamide (PA)
- Band closure:
- Plastic lip/-cam
- UV-stable acc. ASTM D6779:
- Yes
- Transparent:
- No
- Fluorescent:
- No
- Solvable fastener:
- Yes
- Text strip:
- None
- Type of fastening:
- None
- Colour:
- Black
- Surface protection:
- Untreated
- Material:
- Plastic
- Halogen free:
- Yes
- Max. tensile force:
- 890 N
- Approved according to Lloyd's Register TA:
- Yes
