- Fire resistance according to UL94:
- HB
- Oil resistant:
- Yes
- Lengthwise slotted:
- Yes
- Closable (two-part):
- No
- With draw wire:
- No
- High conducting inner coating:
- No
- Colour:
- Black
- Operating temperature:
- -40-120 °C
- Material:
- Polyamide 6
- UV resistant:
- Yes
- Halogen free:
- Yes
- Approved according to DIN EN 61386-23:
- No
- Approved according to UR:
- No
- Approves according to Vd TÜV/GGVS:
- No
- Approved according to LUL/British Standard:
- No
- Approved according to Lloyd's Register TA:
- No
- Approved according to UTAC:
- No
- Approved according to DIN 5510:
- No
- Approved according to NF F 16-101:
- No
- Approved according to CSA:
- No
- Fire resistance according to UL94:
- HB
- Oil resistant:
- Yes
- Lengthwise slotted:
- No
- Closable (two-part):
- No
- With draw wire:
- No
- High conducting inner coating:
- No
- Colour:
- Red
- Operating temperature:
- -40-120 °C
- Material:
- Polyamide 6
- UV resistant:
- Yes
- Halogen free:
- Yes
- Approved according to DIN EN 61386-23:
- No
- Approved according to UR:
- No
- Approves according to Vd TÜV/GGVS:
- Yes
- Approved according to LUL/British Standard:
- No
- Approved according to Lloyd's Register TA:
- No
- Approved according to UTAC:
- No
- Approved according to DIN 5510:
- No
- Approved according to NF F 16-101:
- No
- Approved according to CSA:
- No
NC Standard Weight, Polyamide 6 General Purpose Conduit
NC-CONDUIT-ORANGE
Flexible standard weight nylon (PA6) conduit is a general-purpose conduit suitable for automotive harness applications.
It can withstand extremes of temperatures and resists automotive oils and solvents. It is extremely tough and has a high impact strength and fatigue life.
Solid NC conduits provide protection against mechanical shock and ingress of water whilst maintaining their form through tight bend radius.
ADR approved for hazardous vehicles.
NC standard weight is extensively used in harnesses on HGV, off road vehicles and marine applications where a superior protection against impact and mechanical shock is preferred. The conduit is used for both chassis and engine applications and can be used in a wide range of temperatures. Polyamide 6 is highly resistant to all hydrocarbon based oils and fluids and many types of solvents.
NC is designed for connection to all Harnessflex sealed and hinged system fittings.
The standard colour is black, orange color for ev and hybrid vehicles also available.
- Fire resistance according to UL94:
- HB
- Oil resistant:
- Yes
- Lengthwise slotted:
- No
- Closable (two-part):
- No
- With draw wire:
- No
- High conducting inner coating:
- No
- Colour:
- Orange
- Operating temperature:
- -40-120 °C
- Material:
- Polyamide 6
- UV resistant:
- Yes
- Halogen free:
- Yes
- Approved according to DIN EN 61386-23:
- No
- Approved according to UR:
- No
- Approves according to Vd TÜV/GGVS:
- Yes
- Approved according to LUL/British Standard:
- No
- Approved according to Lloyd's Register TA:
- No
- Approved according to UTAC:
- No
- Approved according to DIN 5510:
- No
- Approved according to NF F 16-101:
- No
- Approved according to CSA:
- No
