Lödskarvar
D-1744-serien
Soldersleeve wire splices from Tyco. Provides encapsulation, inspectability, strain relief and insulation. Immersion sealed.
Temperature range: -55º C - +150º C (-67º F - +302º F)
Technical properties
- Colour:
- Blue, Grey
- Operating temperature:
- -55-150 °C
- Connector type:
- Lödskarvhylsa med lim
- Packaging:
- Loose piece
Show more
Item List
Accessories
Related products
Spare Parts
Product video
Documents
Dimensions
- Total: 4
| Product Description | MOQ | Unit | Nominal cross section | Availability | ||
|---|---|---|---|---|---|---|
| SOLDERSLEEVE WIRE SPLICE BLUE, OD MAX=1.5mm, 0.2-0.75mm2 | 100 . | pcs | 0.2-0.75 mm² |
No
|
|
|
| SOLDERSLEEVE WIRE SPLICE GREY, OD MAX=2.8mm, 0.6-2.0mm2 | 100 . | pcs | 0.6-2 mm² |
No
|
|
|
| SOLDERSLEEVE WIRE SPLICE GREY, OD MAX=4.4mm, 1.8-2.5mm2 | 100 . | pcs | 1.8-2.5 mm² |
Yes
|
|
|
| SOLDERSLEEVE WIRE SPLICE GREY, OD MAX=5.8mm, 2.4-4.5mm2 | 100 . | pcs | 2.4-4.5 mm² |
No
|
|
|
- Total: 4
Similar Options
Approvals
- Total: 4
- Total: 4
Technical Properties
- Total: 4
| Product Description | Colour | Operating temperature | Connector type | Packaging | Availability | ||
|---|---|---|---|---|---|---|---|
| SOLDERSLEEVE WIRE SPLICE BLUE, OD MAX=1.5mm, 0.2-0.75mm2 | Blue | -55-150 °C | Lödskarvhylsa med lim | Loose piece |
No
|
|
|
| SOLDERSLEEVE WIRE SPLICE GREY, OD MAX=2.8mm, 0.6-2.0mm2 | Grey | -55-150 °C | Lödskarvhylsa med lim | Loose piece |
No
|
|
|
| SOLDERSLEEVE WIRE SPLICE GREY, OD MAX=4.4mm, 1.8-2.5mm2 | Grey | -55-150 °C | Lödskarvhylsa med lim | Loose piece |
Yes
|
|
|
| SOLDERSLEEVE WIRE SPLICE GREY, OD MAX=5.8mm, 2.4-4.5mm2 | Grey | -55-150 °C | Lödskarvhylsa med lim | Loose piece |
No
|
|
|
- Total: 4
Other information
- Total: 4
| Product Description | ETIM-Class | ETIM-Release | Trademark | Product Group | Search Description | Alternative SKU | Availability | ||
|---|---|---|---|---|---|---|---|---|---|
| SOLDERSLEEVE WIRE SPLICE BLUE, OD MAX=1.5mm, 0.2-0.75mm2 | EC000466 - Heat-shrink crimp connection | 7.0 |
|
Soldersleeve wire splices | 448859-000 | D1744-01 |
No
|
|
|
| SOLDERSLEEVE WIRE SPLICE GREY, OD MAX=2.8mm, 0.6-2.0mm2 | EC000466 - Heat-shrink crimp connection | 7.0 |
|
Soldersleeve wire splices | 371176-000 | D1744-02 |
No
|
|
|
| SOLDERSLEEVE WIRE SPLICE GREY, OD MAX=4.4mm, 1.8-2.5mm2 | EC000466 - Heat-shrink crimp connection | 7.0 |
|
Soldersleeve wire splices | 750648-000 | D1744-03 |
Yes
|
|
|
| SOLDERSLEEVE WIRE SPLICE GREY, OD MAX=5.8mm, 2.4-4.5mm2 | EC000466 - Heat-shrink crimp connection | 7.0 |
|
Soldersleeve wire splices | 225107-000 | D1744-04 |
No
|
|
|
- Total: 4
