LSP Downlights Kvadratiska 6-Pack
These downlights can be tilted, only use high quality components and has a premium feeling. Works for both indoor and outdoor use.Available in sizes 60x60mm or 80x80mm.60x60mm frames have springs and can be mounted in ceiling.Hole size: 52-54mm.80x80mm frames have metal wings and can be mounted in ceiling as well as in 70mm junction boxes.Hole size: 52-62mm.6-pack. Can be supplemented with drivers, cables and connectors.Technical data:Power: 3.3WLumen: See below.Dimmable: YesLight beam spread: 60°Color temp: See below.IP rating: IP54Temp. Range: -20°C to +50°CLife-span: 70% after 50.000hVoltage: 1-10VAmperage: 350mAAmount of LED’s: 6pcsType of LED: COB, CREE CXA1304-2 STEPCRI: RA90Optics: Reflector with a prism in front of the LED.Glass: ClearEnergy rating: A++Cable: 100mm AWG22 with connector.Size: Depth=50mm, Height=60mmDownlight depth in box: Max 25mmAvailable in white, black or aluminum color.
Technical properties
- Dimmable:
- Yes
- Dimming 0-10 V:
- No
- Dimming 1-10 V:
- No
- Dimming DALI:
- No
- Dimming DSI:
- No
- Dimming DMX:
- No
- Dimming potentiometer (integrated):
- No
- Dimming GPRS:
- No
- Dimming LineSwitch:
- No
- Dimming manufacturer's proprietary system:
- No
- Dimming mains voltage modulation:
- No
- Dimming phase cut-off (trailing edge):
- Yes
- Dimming phase cut-on (leading edge):
- Yes
- Dimming programmable:
- No
- Dimming RF:
- No
- Dimming Sine Wave Reduction:
- No
- Dimming Touch and Dim:
- No
- Dimming Zigbee:
- No
- Dimming with push-button:
- No
- Protection class according to IEC 61140:
- III
- Housing material:
- Aluminium
- Suitable for surface mounting:
- No
- Suitable for built-in mounting:
- Yes
- Suitable for wall mounting:
- No
- Suitable for suspended mounting:
- No
- Suitable for ceiling mounting:
- Yes
- Suitable for traverse mounting:
- No
- Suitable for pedestal/floor mounting:
- No
- Suitable for light-track mounting:
- No
- Suitable for clamp-mounting:
- No
- Suitable for low voltage cable system:
- No
- Adjustability:
- Rotatable
- With movement sensor:
- No
- With light sensor:
- No
- Lamp type:
- LED not exchangeable
- With light source:
- Yes
- Suitable for number of light sources:
- 1 .
- Lamp holder:
- None
- Housing colour:
- Aluminium, Black, White
- Material cover:
- None
- Surface brushed:
- Yes, No
- Voltage type:
- AC
- Nominal voltage:
- 220-240 V
- Type of control gear:
- LED operating device current-controlled
- With control gear:
- Yes
- Dimming depending on control gear:
- Yes
- Reflector:
- High-gloss
- Light distributor:
- Reflector
- Light distribution:
- Symmetric
- Beam angle:
- 41-80° - Wide beam
- Light outlet:
- Direct
- Energy efficiency class of the built-in lamp:
- A++, A+, A (LED)
- Degree of protection (NEMA):
- Other
- Suitable for lamp power:
- 0 N/A
- Max. system power:
- 3.3 W
- Colour of light:
- White
- Colour temperature:
- 2700 K
- Colour rendering index CRI:
- 90-100
- Luminous flux:
- 310 lm
- Lamp efficacy:
- 94 lm/W
- Luminous intensity:
- 368 cd
- Number of poles:
- 2 .
- Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24:
- No
- Suitable for workplace according to EN 12464-1:
- No
- Covering of the luminaire with thermally insulating material possible:
- Yes
- Connection type:
- Crimping
- Frame shape:
- Square
- Degree of protection (IP):
- IP54
- Surface protection:
- Other, Powder coating
- Rated luminous flux according to IEC 62722-2-1:
- 310 lm
Show more
Item List
- Total: 12
- Total: 12
Accessories
Related products
Spare Parts
Product video
Documents
Dimensions
- Total: 12
| Product Description | Width | Built-in width | Built-in length | Built-in diameter | Conductor cross section | MOQ | Connectable conductor cross section | Height/depth | Unit | Length | Outer diameter | Availability | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 6-PACK LED DOWNLIGHTS 60mm, SQUARE, 3.3W, 310Lm ALU, 2700K, 60gr, IP54, SPRINGS | 60 mm | 0 N/A | 0 N/A | 52-54 mm | 0.34 mm² | 1 . | 0.34 mm² | 3 mm | pck | 60 mm | 0 mm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 80mm, SQUARE, 3.3W, 310Lm ALU, 2700K, 60gr, IP54, WINGS | 80 mm | 0 N/A | 0 N/A | 52-62 mm | 0.34 mm² | 1 . | 0.34 mm² | 3 mm | pck | 80 mm | 0 mm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 60mm, SQUARE, 3.3W, 310Lm BLACK, 2700K, 60gr, IP54, SPRINGS | 60 mm | 0 N/A | 0 N/A | 52-54 mm | 0.34 mm² | 1 . | 0.34 mm² | 3 mm | pck | 60 mm | 0 mm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 80mm, SQUARE, 3.3W, 310Lm BLACK, 2700K, 60gr, IP54, WINGS | 80 mm | 0 N/A | 0 N/A | 52-62 mm | 0.34 mm² | 1 . | 0.34 mm² | 3 mm | pck | 80 mm | 0 mm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 60mm, SQUARE, 3.3W, 310Lm WHITE, 2700K, 60gr, IP54, SPRINGS | 60 mm | 0 N/A | 0 N/A | 52-54 mm | 0.34 mm² | 1 . | 0.34 mm² | 3 mm | pck | 60 mm | 0 mm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 80mm, SQUARE, 3.3W, 310Lm WHITE, 2700K, 60gr, IP54, WINGS | 80 mm | 0 N/A | 0 N/A | 52-62 mm | 0.34 mm² | 1 . | 0.34 mm² | 3 mm | pck | 80 mm | 0 mm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 60mm, SQUARE, 3.3W, 310Lm ALU, 3000K, 60gr, IP54, SPRINGS | 60 mm | 0 N/A | 0 N/A | 52-54 mm | 0.34 mm² | 1 . | 0.34 mm² | 3 mm | pck | 60 mm | 0 mm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 80mm, SQUARE, 3.3W, 310Lm ALU, 3000K, 60gr, IP54, WINGS | 80 mm | 0 N/A | 0 N/A | 52-62 mm | 0.34 mm² | 1 . | 0.34 mm² | 3 mm | pck | 80 mm | 0 mm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 60mm, SQUARE, 3.3W, 310Lm BLACK, 3000K, 60gr, IP54, SPRINGS | 60 mm | 0 N/A | 0 N/A | 52-54 mm | 0.34 mm² | 1 . | 0.34 mm² | 3 mm | pck | 60 mm | 0 mm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 80mm, SQUARE, 3.3W, 310Lm BLACK, 3000K, 60gr, IP54, WINGS | 80 mm | 0 N/A | 0 N/A | 52-62 mm | 0.34 mm² | 1 . | 0.34 mm² | 3 mm | pck | 80 mm | 0 mm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 60mm, SQUARE, 3.3W, 310Lm WHITE, 3000K, 60gr, IP54, SPRINGS | 60 mm | 0 N/A | 0 N/A | 52-54 mm | 0.34 mm² | 1 . | 0.34 mm² | 3 mm | pck | 60 mm | 0 mm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 80mm, SQUARE, 3.3W, 310Lm WHITE, 3000K, 60gr, IP54, WINGS | 80 mm | 0 N/A | 0 N/A | 52-62 mm | 0.34 mm² | 1 . | 0.34 mm² | 3 mm | pck | 80 mm | 0 mm |
No
|
|
|
- Total: 12
Similar Options
Approvals
- Total: 12
- Total: 12
Technical Properties
- Total: 12
| Product Description | Dimmable | Dimming 0-10 V | Dimming 1-10 V | Dimming DALI | Dimming DSI | Dimming DMX | Dimming potentiometer (integrated) | Dimming GPRS | Dimming LineSwitch | Dimming manufacturer's proprietary system | Dimming mains voltage modulation | Dimming phase cut-off (trailing edge) | Dimming phase cut-on (leading edge) | Dimming programmable | Dimming RF | Dimming Sine Wave Reduction | Dimming Touch and Dim | Dimming Zigbee | Dimming with push-button | Protection class according to IEC 61140 | Housing material | Suitable for surface mounting | Suitable for built-in mounting | Suitable for wall mounting | Suitable for suspended mounting | Suitable for ceiling mounting | Suitable for traverse mounting | Suitable for pedestal/floor mounting | Suitable for light-track mounting | Suitable for clamp-mounting | Suitable for low voltage cable system | Adjustability | With movement sensor | With light sensor | Lamp type | With light source | Suitable for number of light sources | Lamp holder | Housing colour | Material cover | Surface brushed | Voltage type | Nominal voltage | Type of control gear | With control gear | Dimming depending on control gear | Reflector | Light distributor | Light distribution | Beam angle | Light outlet | Energy efficiency class of the built-in lamp | Degree of protection (NEMA) | Suitable for lamp power | Max. system power | Colour of light | Colour temperature | Colour rendering index CRI | Luminous flux | Lamp efficacy | Luminous intensity | Number of poles | Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24 | Suitable for workplace according to EN 12464-1 | Covering of the luminaire with thermally insulating material possible | Connection type | Frame shape | Degree of protection (IP) | Surface protection | Rated luminous flux according to IEC 62722-2-1 | Availability | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 6-PACK LED DOWNLIGHTS 60mm, SQUARE, 3.3W, 310Lm ALU, 2700K, 60gr, IP54, SPRINGS | Yes | No | No | No | No | No | No | No | No | No | No | Yes | Yes | No | No | No | No | No | No | III | Aluminium | No | Yes | No | No | Yes | No | No | No | No | No | Rotatable | No | No | LED not exchangeable | Yes | 1 . | None | Aluminium | None | Yes | AC | 220-240 V | LED operating device current-controlled | Yes | Yes | High-gloss | Reflector | Symmetric | 41-80° - Wide beam | Direct | A++, A+, A (LED) | Other | 0 N/A | 3.3 W | White | 2700 K | 90-100 | 310 lm | 94 lm/W | 368 cd | 2 . | No | No | Yes | Crimping | Square | IP54 | Other | 310 lm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 80mm, SQUARE, 3.3W, 310Lm ALU, 2700K, 60gr, IP54, WINGS | Yes | No | No | No | No | No | No | No | No | No | No | Yes | Yes | No | No | No | No | No | No | III | Aluminium | No | Yes | No | No | Yes | No | No | No | No | No | Rotatable | No | No | LED not exchangeable | Yes | 1 . | None | Aluminium | None | Yes | AC | 220-240 V | LED operating device current-controlled | Yes | Yes | High-gloss | Reflector | Symmetric | 41-80° - Wide beam | Direct | A++, A+, A (LED) | Other | 0 N/A | 3.3 W | White | 2700 K | 90-100 | 310 lm | 94 lm/W | 368 cd | 2 . | No | No | Yes | Crimping | Square | IP54 | Other | 310 lm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 60mm, SQUARE, 3.3W, 310Lm BLACK, 2700K, 60gr, IP54, SPRINGS | Yes | No | No | No | No | No | No | No | No | No | No | Yes | Yes | No | No | No | No | No | No | III | Aluminium | No | Yes | No | No | Yes | No | No | No | No | No | Rotatable | No | No | LED not exchangeable | Yes | 1 . | None | Black | None | No | AC | 220-240 V | LED operating device current-controlled | Yes | Yes | High-gloss | Reflector | Symmetric | 41-80° - Wide beam | Direct | A++, A+, A (LED) | Other | 0 N/A | 3.3 W | White | 2700 K | 90-100 | 310 lm | 94 lm/W | 368 cd | 2 . | No | No | Yes | Crimping | Square | IP54 | Powder coating | 310 lm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 80mm, SQUARE, 3.3W, 310Lm BLACK, 2700K, 60gr, IP54, WINGS | Yes | No | No | No | No | No | No | No | No | No | No | Yes | Yes | No | No | No | No | No | No | III | Aluminium | No | Yes | No | No | Yes | No | No | No | No | No | Rotatable | No | No | LED not exchangeable | Yes | 1 . | None | Black | None | No | AC | 220-240 V | LED operating device current-controlled | Yes | Yes | High-gloss | Reflector | Symmetric | 41-80° - Wide beam | Direct | A++, A+, A (LED) | Other | 0 N/A | 3.3 W | White | 2700 K | 90-100 | 310 lm | 94 lm/W | 368 cd | 2 . | No | No | Yes | Crimping | Square | IP54 | Powder coating | 310 lm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 60mm, SQUARE, 3.3W, 310Lm WHITE, 2700K, 60gr, IP54, SPRINGS | Yes | No | No | No | No | No | No | No | No | No | No | Yes | Yes | No | No | No | No | No | No | III | Aluminium | No | Yes | No | No | Yes | No | No | No | No | No | Rotatable | No | No | LED not exchangeable | Yes | 1 . | None | White | None | No | AC | 220-240 V | LED operating device current-controlled | Yes | Yes | High-gloss | Reflector | Symmetric | 41-80° - Wide beam | Direct | A++, A+, A (LED) | Other | 0 N/A | 3.3 W | White | 2700 K | 90-100 | 310 lm | 94 lm/W | 368 cd | 2 . | No | No | Yes | Crimping | Square | IP54 | Powder coating | 310 lm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 80mm, SQUARE, 3.3W, 310Lm WHITE, 2700K, 60gr, IP54, WINGS | Yes | No | No | No | No | No | No | No | No | No | No | Yes | Yes | No | No | No | No | No | No | III | Aluminium | No | Yes | No | No | Yes | No | No | No | No | No | Rotatable | No | No | LED not exchangeable | Yes | 1 . | None | White | None | No | AC | 220-240 V | LED operating device current-controlled | Yes | Yes | High-gloss | Reflector | Symmetric | 41-80° - Wide beam | Direct | A++, A+, A (LED) | Other | 0 N/A | 3.3 W | White | 2700 K | 90-100 | 310 lm | 94 lm/W | 368 cd | 2 . | No | No | Yes | Crimping | Square | IP54 | Powder coating | 310 lm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 60mm, SQUARE, 3.3W, 310Lm ALU, 3000K, 60gr, IP54, SPRINGS | Yes | No | No | No | No | No | No | No | No | No | No | Yes | Yes | No | No | No | No | No | No | III | Aluminium | No | Yes | No | No | Yes | No | No | No | No | No | Rotatable | No | No | LED not exchangeable | Yes | 1 . | None | Aluminium | None | Yes | AC | 220-240 V | LED operating device current-controlled | Yes | Yes | High-gloss | Reflector | Symmetric | 41-80° - Wide beam | Direct | A++, A+, A (LED) | Other | 0 N/A | 3.3 W | White | 3000 K | 90-100 | 310 lm | 94 lm/W | 368 cd | 2 . | No | No | Yes | Crimping | Square | IP54 | Other | 310 lm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 80mm, SQUARE, 3.3W, 310Lm ALU, 3000K, 60gr, IP54, WINGS | Yes | No | No | No | No | No | No | No | No | No | No | Yes | Yes | No | No | No | No | No | No | III | Aluminium | No | Yes | No | No | Yes | No | No | No | No | No | Rotatable | No | No | LED not exchangeable | Yes | 1 . | None | Aluminium | None | Yes | AC | 220-240 V | LED operating device current-controlled | Yes | Yes | High-gloss | Reflector | Symmetric | 41-80° - Wide beam | Direct | A++, A+, A (LED) | Other | 0 N/A | 3.3 W | White | 3000 K | 90-100 | 310 lm | 94 lm/W | 368 cd | 2 . | No | No | Yes | Crimping | Square | IP54 | Other | 310 lm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 60mm, SQUARE, 3.3W, 310Lm BLACK, 3000K, 60gr, IP54, SPRINGS | Yes | No | No | No | No | No | No | No | No | No | No | Yes | Yes | No | No | No | No | No | No | III | Aluminium | No | Yes | No | No | Yes | No | No | No | No | No | Rotatable | No | No | LED not exchangeable | Yes | 1 . | None | Black | None | No | AC | 220-240 V | LED operating device current-controlled | Yes | Yes | High-gloss | Reflector | Symmetric | 41-80° - Wide beam | Direct | A++, A+, A (LED) | Other | 0 N/A | 3.3 W | White | 3000 K | 90-100 | 310 lm | 94 lm/W | 368 cd | 2 . | No | No | Yes | Crimping | Square | IP54 | Powder coating | 310 lm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 80mm, SQUARE, 3.3W, 310Lm BLACK, 3000K, 60gr, IP54, WINGS | Yes | No | No | No | No | No | No | No | No | No | No | Yes | Yes | No | No | No | No | No | No | III | Aluminium | No | Yes | No | No | Yes | No | No | No | No | No | Rotatable | No | No | LED not exchangeable | Yes | 1 . | None | Black | None | No | AC | 220-240 V | LED operating device current-controlled | Yes | Yes | High-gloss | Reflector | Symmetric | 41-80° - Wide beam | Direct | A++, A+, A (LED) | Other | 0 N/A | 3.3 W | White | 3000 K | 90-100 | 310 lm | 94 lm/W | 368 cd | 2 . | No | No | Yes | Crimping | Square | IP54 | Powder coating | 310 lm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 60mm, SQUARE, 3.3W, 310Lm WHITE, 3000K, 60gr, IP54, SPRINGS | Yes | No | No | No | No | No | No | No | No | No | No | Yes | Yes | No | No | No | No | No | No | III | Aluminium | No | Yes | No | No | Yes | No | No | No | No | No | Rotatable | No | No | LED not exchangeable | Yes | 1 . | None | White | None | No | AC | 220-240 V | LED operating device current-controlled | Yes | Yes | High-gloss | Reflector | Symmetric | 41-80° - Wide beam | Direct | A++, A+, A (LED) | Other | 0 N/A | 3.3 W | White | 3000 K | 90-100 | 310 lm | 94 lm/W | 368 cd | 2 . | No | No | Yes | Crimping | Square | IP54 | Powder coating | 310 lm |
No
|
|
|
| 6-PACK LED DOWNLIGHTS 80mm, SQUARE, 3.3W, 310Lm WHITE, 3000K, 60gr, IP54, WINGS | Yes | No | No | No | No | No | No | No | No | No | No | Yes | Yes | No | No | No | No | No | No | III | Aluminium | No | Yes | No | No | Yes | No | No | No | No | No | Rotatable | No | No | LED not exchangeable | Yes | 1 . | None | White | None | No | AC | 220-240 V | LED operating device current-controlled | Yes | Yes | High-gloss | Reflector | Symmetric | 41-80° - Wide beam | Direct | A++, A+, A (LED) | Other | 0 N/A | 3.3 W | White | 3000 K | 90-100 | 310 lm | 94 lm/W | 368 cd | 2 . | No | No | Yes | Crimping | Square | IP54 | Powder coating | 310 lm |
No
|
|
|
- Total: 12
Other information
- Total: 12
- Total: 12
