NHS-12.7-0-5M
SHRINK TUBE WITHOUT ADHESIVE, 2:1, ID=12.7mm BLACK, L=5m, THIN-W
NHS-12.7-0-5M
- Availability:
-
Yes
- Total: 1
Related items
NHS 2:1, without adhesive, blister pack
Standard heat shrink tubing with shrink ratio 2:1
Applications:
Electrical insulation, strain relief, bundling, mechanical protection, colour coding of wires, cables, tubes and electronic components.
Blister pack.
Material: Polyolefin
Colour: Black
Temperature range: Max. +125° C (+257° F)
Lowest shrink temperature: +90° C (+194° F)
Wall thickness: Thin wall
Shrink ratio: 2:1
Self-extinguishing: VW-1
- Total: 1
Product Properties
| Model | Thin-walled |
|---|---|
| Operating temperature | -55-125 °C |
| Transparent | No |
| Type | Heat-shrink |
| Shrink rate | 2:1 |
| With inner glue | No |
| Printable | No |
| Colour | Black |
| Material | Polyolefin (PO-X) |
| Halogen free | No |
| Packaging | Assortment |
Dimensions
| Wall thickness after shrinking | 0.65 mm |
|---|---|
| MOQ | 1 . |
| Unit | pck |
| Length | 5 m |
| Nominal diameter inch | 1/2 inch |
| Inner diameter before heat-shrink | 12.5 mm |
| Inner diameter after heat-shrink | 6.25 mm |
Logistics
| Barcode | 733117613293 |
|---|---|
| Country of origin | CN |
| Item status | Stock item, normally in stock with reservation for in between sales. |
| MOQ | 1 . |
| Packaging | Assortment |
| Stock code | NHS-12.7-0-5M |
| Taric code | 39173200 |
| Unit | pck |
Approvals
| Approved according to CSA STYLE 20222-E | Yes |
|---|---|
| Approved according to UR | Yes |
| UL approval | No |
| Approved according to CSA | Yes |
Other info
| ETIM-Class | EC000217 - Shrink tubing |
|---|---|
| ETIM-Release | 9.0 |
| Trademark | NEMIQ |
| Product Group | Retailer Concepts & Assortments |
| Alternative SKU | NHS-12.7-0-5M |
Compliance
| Conflict Minerals | N/A, Contains no conflict minerals |
|---|---|
| Iron and Steel Sanction | Compliance |
| REACH | No SVHC (Latest. 27 June 2024) |
| RoHS | RoHS 3 (2015/863) |
| SCIP | Not Applicable |
| US TSCA | Compliance |
