C 215

INSULATED END-SLEEVE, REEL, 0.75mm2-8 WHITE

Sku

C 215

Availability:
No
  • Total: 1
Product Description
Cord end-sleeves on reel, C-serien
  • Total: 1
  • Total: 1

Related items

Cord end-sleeves on reel, C-serien

  • Total: 1
Insulated Yes
Reel/roll packaging Yes
Construction type Single-sleeves
Colour White
Surface protection Tinned
Material insulation Polypropylene (PP)
Material Copper
Colour code CEW/CTW (Old German colorline)
Halogen free Yes
ID 1.2 mm
T 0.15 mm
L 14 mm
N 8 mm
W 2.8 mm
MOQ 4000 .
Unit pcs
Sleeve Length 8 mm
AWG size 20
Total length 14 mm
Nominal cross section 0.75 mm²
Barcode 733117615805
Country of origin DE
Item status Non Stock Item, can be on stock but is not a regular stock item.
MOQ 4000 .
Stock code C 215
Taric code 85369010
Unit pcs
Approved according to CE Yes
Approved according to CSA Yes
With approval according to UL Yes
ETIM-Class EC000005 - Cable end sleeve
ETIM-Release 9.0
Trademark NEMIQ
Product Group Insulated end-sleeves on tape/reel
Alternative SKU C215
Conflict Minerals Yes, see report under tab "Documents"
Extended Minerals N/A, contains no extended minerals
PFAS No PFAS
POPs No POPs
REACH No SVHC (240 Subs. 23 Jan 2024)
RoHS RoHS 3 (2015/863)
SCIP Not Applicable
US TSCA No (5 PBT Subs, Feb 2021)
