Multiple rocker push-button complete with frame INTEGRO Flow
Återfjädrande strömställare och tryckknapp 1-pol
10 A, 250 VAC
Skruvanslutning av anslutningsledning.
Denna artikel är butiksförpackad med streckkod.
Technical properties
- Nominal voltage:
- 250 V
- Connection type:
- Screwed terminal
- Rated current:
- 10 A
- Mounting method:
- Built-in installation
- Anti-bacterial treatment:
- No
- Surface finishing:
- Matt, Glossy
- Compatible with Apple HomeKit:
- No
- Compatible with Google Assistant:
- No
- Compatible with Amazon Alexa:
- No
- IFTTT support available:
- No
- Assembly arrangement:
- Basic element with central cover plate, Basic element with complete housing
- Wiring system:
- Off switch 1-pole
- Method of operation:
- Rocker/button
- With mounting plate:
- No
- Illumination:
- No
- Feedback-signal contact:
- No
- Heating switch:
- No
- Washing machine switch:
- No
- Type of fastening:
- Screw mounting
- RAL-number (similar):
- 8017 ., 7021 ., 9010 ., 9023 ., 9006 .
- Min. depth of built-in installation box:
- 16 mm
- Colour:
- Brown, Anthracite, White, Chrome
- Material:
- Plastic
- Variant:
- 250V
- Built-in depth:
- 15.5 mm
Show more
Item List
- Total: 5
- Total: 5
Accessories
Related products
Spare Parts
Product video
Documents
Dimensions
- Total: 5
| Product Description | Built-in depth | Number of modules (module system) | Device width | Device height | Device depth | Number of rockers | Min. depth of built-in installation box | MOQ | Unit | Nominal voltage | Availability | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ROCKER PUSH-BUTTONS SWITCH COMPLETE WITH FRAME BROWN MATT, INTEGRO FLOW | 15.5 mm | 1 . | 55.5 mm | 55.5 mm | 25 mm | 1 . | 16 mm | 1 . | pck | 250 V |
No
|
|
|
| ROCKER PUSH-BUTTONS SWITCH COMPLETE WITH FRAME POLAR WHITE GLOSSY, INTEGRO FLOW | 15.5 mm | 1 . | 55.5 mm | 55.5 mm | 25 mm | 1 . | 16 mm | 1 . | pck | 250 V |
Yes
|
|
|
| ROCKER PUSH-BUTTONS SWITCH COMPLETE WITH FRAME ANTRACITE MATT, INTEGRO FLOW | 15.5 mm | 1 . | 55.5 mm | 55.5 mm | 25 mm | 1 . | 16 mm | 1 . | pck | 250 V |
No
|
|
|
| ROCKER PUSH-BUTTONS SWITCH COMPLETE WITH FRAME CHROME GLOSSY, INTEGRO FLOW | 15.5 mm | 1 . | 55.5 mm | 55.5 mm | 25 mm | 1 . | 16 mm | 1 . | pck | 250 V |
No
|
|
|
| ROCKER PUSH-BUTTONS SWITCH COMPLETE WITH FRAME CHROME MATT, INTEGRO FLOW | 15.5 mm | 1 . | 55.5 mm | 55.5 mm | 25 mm | 1 . | 16 mm | 1 . | pck | 250 V |
No
|
|
|
- Total: 5
Similar Options
Approvals
- Total: 5
- Total: 5
Technical Properties
- Total: 5
| Product Description | Nominal voltage | Connection type | Rated current | Mounting method | Anti-bacterial treatment | Surface finishing | Compatible with Apple HomeKit | Compatible with Google Assistant | Compatible with Amazon Alexa | IFTTT support available | Assembly arrangement | Wiring system | Method of operation | With mounting plate | Illumination | Feedback-signal contact | Heating switch | Washing machine switch | Type of fastening | RAL-number (similar) | Min. depth of built-in installation box | Colour | Material | Variant | Built-in depth | Availability | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ROCKER PUSH-BUTTONS SWITCH COMPLETE WITH FRAME BROWN MATT, INTEGRO FLOW | 250 V | Screwed terminal | 10 A | Built-in installation | No | Matt | No | No | No | No | Basic element with central cover plate | Off switch 1-pole | Rocker/button | No | No | No | Screw mounting | 8017 . | 16 mm | Brown | Plastic | 15.5 mm |
No
|
|
|
|||
| ROCKER PUSH-BUTTONS SWITCH COMPLETE WITH FRAME POLAR WHITE GLOSSY, INTEGRO FLOW | 250 V | Screwed terminal | 10 A | Built-in installation | No | Glossy | No | No | No | No | Basic element with complete housing | Off switch 1-pole | Rocker/button | No | No | No | No | No | Screw mounting | 9010 . | 16 mm | White | Plastic | 15.5 mm |
Yes
|
|
|
|
| ROCKER PUSH-BUTTONS SWITCH COMPLETE WITH FRAME ANTRACITE MATT, INTEGRO FLOW | 250 V | Screwed terminal | 10 A | Built-in installation | No | Matt | No | No | No | No | Basic element with central cover plate | Off switch 1-pole | Rocker/button | No | No | No | Screw mounting | 7021 . | 16 mm | Anthracite | Plastic | 250V | 15.5 mm |
No
|
|
|
||
| ROCKER PUSH-BUTTONS SWITCH COMPLETE WITH FRAME CHROME GLOSSY, INTEGRO FLOW | 250 V | Screwed terminal | 10 A | Built-in installation | No | Glossy | No | No | No | No | Basic element with complete housing | Off switch 1-pole | Rocker/button | No | No | No | Screw mounting | 9023 . | 16 mm | Chrome | Plastic | 250V | 15.5 mm |
No
|
|
|
||
| ROCKER PUSH-BUTTONS SWITCH COMPLETE WITH FRAME CHROME MATT, INTEGRO FLOW | 250 V | Screwed terminal | 10 A | Built-in installation | No | Matt | No | No | No | No | Basic element with complete housing | Off switch 1-pole | Rocker/button | No | No | No | Screw mounting | 9006 . | 16 mm | Chrome | Plastic | 250V | 15.5 mm |
No
|
|
|
- Total: 5
Other information
- Total: 5
| Product Description | ETIM-Class | ETIM-Release | Trademark | Product Group | Alternative SKU | Availability | ||
|---|---|---|---|---|---|---|---|---|
| ROCKER PUSH-BUTTONS SWITCH COMPLETE WITH FRAME BROWN MATT, INTEGRO FLOW | EC001590 - Installation switch | 9.0 |
|
Rocker push-buttons | 171436712501BR-BR-B |
No
|
|
|
| ROCKER PUSH-BUTTONS SWITCH COMPLETE WITH FRAME POLAR WHITE GLOSSY, INTEGRO FLOW | EC001590 - Installation switch | 9.0 |
|
Rocker push-buttons | 171436712509WH-WH-B |
Yes
|
|
|
| ROCKER PUSH-BUTTONS SWITCH COMPLETE WITH FRAME ANTRACITE MATT, INTEGRO FLOW | EC001590 - Installation switch | 9.0 | Rocker push-buttons | 171436712505AN-AN-B |
No
|
|
|
|
| ROCKER PUSH-BUTTONS SWITCH COMPLETE WITH FRAME CHROME GLOSSY, INTEGRO FLOW | EC001590 - Installation switch | 9.0 | Rocker push-buttons | 171436712518CG-CG-B |
No
|
|
|
|
| ROCKER PUSH-BUTTONS SWITCH COMPLETE WITH FRAME CHROME MATT, INTEGRO FLOW | EC001590 - Installation switch | 9.0 | Rocker push-buttons | 171436712528CM-CM-B |
No
|
|
|
- Total: 5
