ENVIROFLEX
RG CABLES AND HALOGEN FREE ALTERNATIVES - Halogen-free RG compatible cables
Technical properties
- Colour outer sheath:
- Blue, Black
- Nominal voltage:
- 2500 V, 1500 V
- Colour:
- Black, Blue
- Material insulation:
- Polyolefin (POE)
- Operating temperature:
- -40-105 °C
- Conductor surface:
- Bare, Tinned
- Halogen free:
- Yes
Show more
Item List
- Total: 7
- Total: 7
Accessories
Related products
Spare Parts
Product video
Documents
Manuals, Datasheets, Sketches & Drawings
Conflict Minerals Reporting Template Version 6.31_Approved
Dimensions
- Total: 7
| Product Description | MOQ | Unit | Nominal voltage | Availability | ||
|---|---|---|---|---|---|---|
| RADOX ENVIROFLEX_179, 75Ω, 3GHZ, 0.305mm2, BLUE COAX, 2500V, HF, FT, 105C, ø2.54 mm | 100 . | m |
No
|
|
|
|
| RADOX ENVIROFLEX_B58, 50Ω, 1GHZ, 0.9mm2, BLACK COAX, 2500V, HF,FT, 85C, ø4.95mm | 100 . | m |
No
|
|
|
|
| RADOX ENVIROFLEX_393,50Ω, 6GHZ, SVART/BLÅ RAND, COAX,≤5kV , HF, FT, 105C, ø10.05 mm | 100 . | m |
No
|
|
|
|
| RADOX ENVIROFLEX_142, 50Ω, 6GHZ, BLACK/BLUE RAND COAX, 2500V, HF, FT, 105C, ø5 mm | 100 . | m | 2500 V |
No
|
|
|
| RADOX ENVIROFLEX_400, 50Ω, 6GHZ, 1.0mm2, BL/BLUE COAX, 2500V, HF, FT, 105C, ø5 mm | 100 . | m | 2500 V |
Yes
|
|
|
| RADOX ENVIROFLEX_316_D, 50Ω, 6GHZ, 0.54mm2, BLACK COAX, 1500V, HF, 105C, ø3.16 mm | 100 . | m | 1500 V |
No
|
|
|
| RADOX ENVIROFLEX_B214, 50Ω, 6GHZ, 2.25mm2, BLACK COAX, 2500V, HF, FT, 85C, ø10.8mm | 100 . | m |
No
|
|
|
- Total: 7
Similar Options
Approvals
- Total: 7
- Total: 7
Technical Properties
- Total: 7
| Product Description | Colour outer sheath | Nominal voltage | Colour | Material insulation | Operating temperature | Conductor surface | Halogen free | Availability | ||
|---|---|---|---|---|---|---|---|---|---|---|
| RADOX ENVIROFLEX_179, 75Ω, 3GHZ, 0.305mm2, BLUE COAX, 2500V, HF, FT, 105C, ø2.54 mm | Blue | Blue | Yes |
No
|
|
|
||||
| RADOX ENVIROFLEX_B58, 50Ω, 1GHZ, 0.9mm2, BLACK COAX, 2500V, HF,FT, 85C, ø4.95mm | Black | Black | Yes |
No
|
|
|
||||
| RADOX ENVIROFLEX_393,50Ω, 6GHZ, SVART/BLÅ RAND, COAX,≤5kV , HF, FT, 105C, ø10.05 mm |
No
|
|
|
|||||||
| RADOX ENVIROFLEX_142, 50Ω, 6GHZ, BLACK/BLUE RAND COAX, 2500V, HF, FT, 105C, ø5 mm | Black | 2500 V | Black | Polyolefin (POE) | -40-105 °C | Tinned | Yes |
No
|
|
|
| RADOX ENVIROFLEX_400, 50Ω, 6GHZ, 1.0mm2, BL/BLUE COAX, 2500V, HF, FT, 105C, ø5 mm | Black | 2500 V | Black | Polyolefin (POE) | -40-105 °C | Tinned | Yes |
Yes
|
|
|
| RADOX ENVIROFLEX_316_D, 50Ω, 6GHZ, 0.54mm2, BLACK COAX, 1500V, HF, 105C, ø3.16 mm | Black | 1500 V | Black | Polyolefin (POE) | -40-105 °C | Bare | Yes |
No
|
|
|
| RADOX ENVIROFLEX_B214, 50Ω, 6GHZ, 2.25mm2, BLACK COAX, 2500V, HF, FT, 85C, ø10.8mm | Black | Black | Yes |
No
|
|
|
- Total: 7
Other information
- Total: 7
| Product Description | ETIM-Class | ETIM-Release | Trademark | Product Group | Search Description | Alternative SKU | Availability | ||
|---|---|---|---|---|---|---|---|---|---|
| RADOX ENVIROFLEX_179, 75Ω, 3GHZ, 0.305mm2, BLUE COAX, 2500V, HF, FT, 105C, ø2.54 mm | EC003251 - Power cable >= 1 kV, for permanent installation | 9.0 |
|
Cable - Coaxial | RADOX ENVIROFLEX_179, 75Ω, 3GHZ, 0.305MM2, BLÅ | 23019104 |
No
|
|
|
| RADOX ENVIROFLEX_B58, 50Ω, 1GHZ, 0.9mm2, BLACK COAX, 2500V, HF,FT, 85C, ø4.95mm | EC003251 - Power cable >= 1 kV, for permanent installation | 9.0 |
|
Cable - Coaxial | RADOX ENVIROFLEX_B58, 50Ω, 1GHZ, 0.9MM2, SVART | 85086965 |
No
|
|
|
| RADOX ENVIROFLEX_393,50Ω, 6GHZ, SVART/BLÅ RAND, COAX,≤5kV , HF, FT, 105C, ø10.05 mm | EC003251 - Power cable >= 1 kV, for permanent installation | 9.0 |
|
Cable - Coaxial | RADOX ENVIROFLEX_393,50Ω, 6GHZ, SVART/BLÅ RAND | 22512282 |
No
|
|
|
| RADOX ENVIROFLEX_142, 50Ω, 6GHZ, BLACK/BLUE RAND COAX, 2500V, HF, FT, 105C, ø5 mm | EC003251 - Power cable >= 1 kV, for permanent installation | 9.0 |
|
Cable - Coaxial | ENVIROFLEX_142 | 22512168 |
No
|
|
|
| RADOX ENVIROFLEX_400, 50Ω, 6GHZ, 1.0mm2, BL/BLUE COAX, 2500V, HF, FT, 105C, ø5 mm | EC003251 - Power cable >= 1 kV, for permanent installation | 9.0 |
|
Cable - Coaxial | ENVIROFLEX_400 | 22512280 |
Yes
|
|
|
| RADOX ENVIROFLEX_316_D, 50Ω, 6GHZ, 0.54mm2, BLACK COAX, 1500V, HF, 105C, ø3.16 mm | EC003251 - Power cable >= 1 kV, for permanent installation | 9.0 |
|
Cable - Coaxial | ENVIROFLEX_316_D | 22512281 |
No
|
|
|
| RADOX ENVIROFLEX_B214, 50Ω, 6GHZ, 2.25mm2, BLACK COAX, 2500V, HF, FT, 85C, ø10.8mm | EC003251 - Power cable >= 1 kV, for permanent installation | 9.0 |
|
Cable - Coaxial | ENVIROFLEX_B214 | 85087101 |
No
|
|
|
- Total: 7
