RADOX 125 Multi conductor unscreened
Halogen-free cable suitable both for fixed installation or as a connection cable in dry, damp and wet areas both indoors and outdoors.
Due to the good mechanical properties and the high chemical resistance, RADOX 125 is especially suitable in industry in demanding environments, eg for machines and industrial equipment.
Technical properties
- Number of cores:
- 5 ., 12 ., 2 ., 3 ., 7 ., 27 ., 4 .
- Protective conductor:
- No
- Material outer sheath:
- None
- Colour outer sheath:
- Black
- Flame retardant:
- According to IEC/EN 60332-1-2
- Conductor material:
- Copper
- Screen:
- No
- Armouring/reinforcement:
- None
- Drain wire:
- No
- Nominal voltage:
- 1000 V
- Halogen free:
- Yes, Yes
- Conductor category:
- Class 5 = flexible
- Colour:
- Black
- Material insulation:
- Polyolefin (POE)
- Operating temperature:
- -40-125 °C
- Conductor surface:
- Tinned
Show more
Item List
- Total: 9
- Total: 9
Accessories
Related products
Spare Parts
Product video
Documents
Manuals, Datasheets, Sketches & Drawings
Conflict Minerals Reporting Template Version 6.31_Approved
Dimensions
- Total: 9
| Product Description | Nominal cross section conductor | Weight | MOQ | Cable width approx. | Cable height approx. | Unit | Nominal voltage | Availability | ||
|---|---|---|---|---|---|---|---|---|---|---|
| RADOX 125 S2, 2x0.75mm2, BLACK 1000V, HF, FT, 125C | 0.75 mm² | 63 kg/km | 3000 . | 6.6 mm | 6.6 mm | m |
No
|
|
|
|
| RADOX 125 S2, 5G0.75mm2, BLACK 1000V, HF, FT, 125C | 0.75 mm² | 100 . | m | 1000 V |
Yes
|
|
|
|||
| RADOX 125 S2, 12G0.75mm2, BLACK 1000V, HF, FT, 125C | 0.75 mm² | 214 kg/km | 50 . | 10 mm | 10 mm | m | 1000 V |
Yes
|
|
|
| RADOX 125 S2, 2x1.0mm2, BLACK 1000V, HF, FT, 125C | 1 mm² | 100 . | m | 1000 V |
Yes
|
|
|
|||
| RADOX 125 S2, 2x1.5mm2, BLACK 1000V, HF, FT, 125C | 1.5 mm² | 86 kg/km | 100 . | 8 mm | 8 mm | m | 1000 V |
Yes
|
|
|
| RADOX 125 S2, 3G1.5mm2, BLACK 1000V, HF, FT, 125C | 1.5 mm² | 110 kg/km | 100 . | 8 mm | 8 mm | m | 1000 V |
Yes
|
|
|
| RADOX 125 S2, 4G1.5mm2, BLACK 1000V, HF, FT, 125C | 1.5 mm² | 1500 . | m |
Yes
|
|
|
||||
| RADOX 125, 27G1.5mm2, BLACK 1000V, HF, FT, 125C | 1.5 mm² | 25 . | m | 1000 V |
Yes
|
|
|
|||
| RADOX 125 S2, 7G2.5mm2, BLACK 1000V, HF, FT, 125C | 2.5 mm² | 379 kg/km | 100 . | 15 mm | 15 mm | m | 1000 V |
Yes
|
|
|
- Total: 9
Similar Options
Approvals
- Total: 9
| Product Description | Approved according to IEC 60332-3, cat A,B,C, (F4) | Approved according to IEC 60754-2 | Reaction-to-fire according to EN 13501-6: Class | Reaction-to-fire according to EN 13501-6: Smoke production | Reaction-to-fire according to EN 13501-6: Flaming droplets/particles | Reaction-to-fire according to EN 13501-6: Acidity | Halogen free | Low smoke (according to EN 61034-2) | Low temperature resistant (according to EN 60811-504+505+506) | Oil resistant according to EN IEC 60811-404 | Flame retardant | Availability | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| RADOX 125 S2, 2x0.75mm2, BLACK 1000V, HF, FT, 125C | Eca | N/A | N/A | N/A | Yes | Yes | According to IEC/EN 60332-1-2 |
No
|
|
|
||||
| RADOX 125 S2, 5G0.75mm2, BLACK 1000V, HF, FT, 125C | Yes | Yes | Eca | N/A | N/A | N/A | Yes | Yes | According to IEC/EN 60332-1-2 |
Yes
|
|
|
||
| RADOX 125 S2, 12G0.75mm2, BLACK 1000V, HF, FT, 125C | Yes | Yes | Eca | N/A | N/A | N/A | Yes | Yes | According to IEC/EN 60332-1-2 |
Yes
|
|
|
||
| RADOX 125 S2, 2x1.0mm2, BLACK 1000V, HF, FT, 125C | Yes | Yes | Eca | N/A | N/A | N/A | Yes | Yes | According to IEC/EN 60332-1-2 |
Yes
|
|
|
||
| RADOX 125 S2, 2x1.5mm2, BLACK 1000V, HF, FT, 125C | Yes | Yes | Eca | N/A | N/A | N/A | Yes | Yes | According to IEC/EN 60332-1-2 |
Yes
|
|
|
||
| RADOX 125 S2, 3G1.5mm2, BLACK 1000V, HF, FT, 125C | Yes | Yes | Eca | N/A | N/A | N/A | Yes | Yes | According to IEC/EN 60332-1-2 |
Yes
|
|
|
||
| RADOX 125 S2, 4G1.5mm2, BLACK 1000V, HF, FT, 125C | Eca | N/A | N/A | N/A | Yes | Yes | According to IEC/EN 60332-1-2 |
Yes
|
|
|
||||
| RADOX 125, 27G1.5mm2, BLACK 1000V, HF, FT, 125C | Yes | Yes | Eca | N/A | N/A | N/A | Yes | Yes | No | No | According to IEC/EN 60332-1-2 |
Yes
|
|
|
| RADOX 125 S2, 7G2.5mm2, BLACK 1000V, HF, FT, 125C | Yes | Yes | Eca | N/A | N/A | N/A | Yes | Yes | According to IEC/EN 60332-1-2 |
Yes
|
|
|
- Total: 9
Technical Properties
- Total: 9
| Product Description | Number of cores | Protective conductor | Material outer sheath | Colour outer sheath | Flame retardant | Conductor material | Screen | Armouring/reinforcement | Drain wire | Nominal voltage | Halogen free | Conductor category | Colour | Material insulation | Operating temperature | Conductor surface | Halogen free | Availability | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| RADOX 125 S2, 2x0.75mm2, BLACK 1000V, HF, FT, 125C | 2 . | No | None | Black | According to IEC/EN 60332-1-2 | Copper | No | No | Yes | Class 5 = flexible | Black | Tinned | Yes |
No
|
|
|
||||
| RADOX 125 S2, 5G0.75mm2, BLACK 1000V, HF, FT, 125C | 5 . | No | None | Black | According to IEC/EN 60332-1-2 | Copper | No | No | 1000 V | Yes | Class 5 = flexible | Black | Polyolefin (POE) | -40-125 °C | Tinned | Yes |
Yes
|
|
|
|
| RADOX 125 S2, 12G0.75mm2, BLACK 1000V, HF, FT, 125C | 12 . | No | None | Black | According to IEC/EN 60332-1-2 | Copper | No | No | 1000 V | Yes | Class 5 = flexible | Black | Polyolefin (POE) | -40-125 °C | Tinned | Yes |
Yes
|
|
|
|
| RADOX 125 S2, 2x1.0mm2, BLACK 1000V, HF, FT, 125C | 2 . | No | None | Black | According to IEC/EN 60332-1-2 | Copper | No | No | 1000 V | Yes | Class 5 = flexible | Black | Polyolefin (POE) | -40-125 °C | Tinned | Yes |
Yes
|
|
|
|
| RADOX 125 S2, 2x1.5mm2, BLACK 1000V, HF, FT, 125C | 2 . | No | None | Black | According to IEC/EN 60332-1-2 | Copper | No | No | 1000 V | Yes | Class 5 = flexible | Black | Polyolefin (POE) | -40-125 °C | Tinned | Yes |
Yes
|
|
|
|
| RADOX 125 S2, 3G1.5mm2, BLACK 1000V, HF, FT, 125C | 3 . | No | None | Black | According to IEC/EN 60332-1-2 | Copper | No | No | 1000 V | Yes | Class 5 = flexible | Black | Polyolefin (POE) | -40-125 °C | Tinned | Yes |
Yes
|
|
|
|
| RADOX 125 S2, 4G1.5mm2, BLACK 1000V, HF, FT, 125C | 4 . | No | None | Black | According to IEC/EN 60332-1-2 | Copper | No | No | Yes | Class 5 = flexible | Black | Tinned | Yes |
Yes
|
|
|
||||
| RADOX 125, 27G1.5mm2, BLACK 1000V, HF, FT, 125C | 27 . | No | None | Black | According to IEC/EN 60332-1-2 | Copper | No | None | No | 1000 V | Yes | Class 5 = flexible | Black | Polyolefin (POE) | -40-125 °C | Tinned | Yes |
Yes
|
|
|
| RADOX 125 S2, 7G2.5mm2, BLACK 1000V, HF, FT, 125C | 7 . | No | None | Black | According to IEC/EN 60332-1-2 | Copper | No | No | 1000 V | Yes | Class 5 = flexible | Black | Polyolefin (POE) | -40-125 °C | Tinned | Yes |
Yes
|
|
|
- Total: 9
Other information
- Total: 9
| Product Description | ETIM-Class | ETIM-Release | Trademark | Product Group | Search Description | Alternative SKU | Availability | ||
|---|---|---|---|---|---|---|---|---|---|
| RADOX 125 S2, 2x0.75mm2, BLACK 1000V, HF, FT, 125C | EC003251 - Power cable >= 1 kV, for permanent installation | 9.0 |
|
Cable - RXL 125 Multi conductor | RXL 125 | 12430125 |
No
|
|
|
| RADOX 125 S2, 5G0.75mm2, BLACK 1000V, HF, FT, 125C | EC003251 - Power cable >= 1 kV, for permanent installation | 9.0 |
|
Cable - RXL 125 Multi conductor | RXL 125 | 12420501-100 |
Yes
|
|
|
| RADOX 125 S2, 12G0.75mm2, BLACK 1000V, HF, FT, 125C | EC003251 - Power cable >= 1 kV, for permanent installation | 9.0 |
|
Cable - RXL 125 Multi conductor | RXL 125 | 12420602-50 |
Yes
|
|
|
| RADOX 125 S2, 2x1.0mm2, BLACK 1000V, HF, FT, 125C | EC003251 - Power cable >= 1 kV, for permanent installation | 9.0 |
|
Cable - RXL 125 Multi conductor | RXL 125 | 12430115-100 |
Yes
|
|
|
| RADOX 125 S2, 2x1.5mm2, BLACK 1000V, HF, FT, 125C | EC003251 - Power cable >= 1 kV, for permanent installation | 9.0 |
|
Cable - RXL 125 Multi conductor | RXL 125 | 12430113-100 |
Yes
|
|
|
| RADOX 125 S2, 3G1.5mm2, BLACK 1000V, HF, FT, 125C | EC003251 - Power cable >= 1 kV, for permanent installation | 9.0 |
|
Cable - RXL 125 Multi conductor | RXL 125 | 12430116-100 |
Yes
|
|
|
| RADOX 125 S2, 4G1.5mm2, BLACK 1000V, HF, FT, 125C | EC003251 - Power cable >= 1 kV, for permanent installation | 9.0 |
|
Cable - RXL 125 Multi conductor | RXL 125 | 12582631 |
Yes
|
|
|
| RADOX 125, 27G1.5mm2, BLACK 1000V, HF, FT, 125C | EC003251 - Power cable >= 1 kV, for permanent installation | 9.0 |
|
Cable - RXL 125 Multi conductor | RADOX 125, 27G1.5MM2, SVART | 12516646-25 |
Yes
|
|
|
| RADOX 125 S2, 7G2.5mm2, BLACK 1000V, HF, FT, 125C | EC003251 - Power cable >= 1 kV, for permanent installation | 9.0 |
|
Cable - RXL 125 Multi conductor | RXL 125 | 12507226-100 |
Yes
|
|
|
- Total: 9
