NHSA, 3:1, with adhesive, 1.2m lenght
NHSA är en flexibel tunnväggig krympslang av polyolefin med invändig beläggning av lim.
Användningsområden: Idealisk för inkapsling, skydd och fukttätning av elektriska komponenter, förgreningar och förstärkning av kabelmantlar.
Material: Polyolefin med smältlim
Färg: Svart
Arbetstemperatur: -45° C till +125° C
Lägsta krymptemperatur: +70° C, Lägsta temperatur för maximal krympning: +125° C
Väggtjocklek: Tunnväggig med smältlim
Krympgrad: 3:1
Technical properties
- Model:
- Thin-walled
- Operating temperature:
- -45-125 °C
- Transparent:
- No
- Type:
- Heat-shrink
- Shrink rate:
- 3:1
- With inner glue:
- Yes
- Printable:
- No
- Colour:
- Black
- Material:
- Polyolefin (PO-X)
- Halogen free:
- No
- Packaging:
- Cut to length
Show more
Item List
- Total: 7
- Total: 7
Accessories
Related products
Spare Parts
Product video
Documents
Dimensions
- Total: 7
| Product Description | Wall thickness after shrinking | MOQ | Unit | Length | Inner diameter before heat-shrink | Inner diameter after heat-shrink | Availability | ||
|---|---|---|---|---|---|---|---|---|---|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=19mm BLACK, LENGHT, L=1.2m, THIN-W | 2 mm | 25 . | pcs | 1.2 m | 19 mm | 6 mm |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=24.0mm BLACK, LENGHT, L=1.2m, THIN-W | 2.1 mm | 25 . | pcs | 1.2 m | 24 mm | 8 mm |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=3mm BLACK, LENGHT, L=1.2m, THIN-W | 0.95 mm | 25 . | pcs | 1.2 m | 3 mm | 1 mm |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=40mm BLACK, LENGHT, L=1.2m, THIN-W | 2.4 mm | 25 . | pcs | 1.2 m | 40 mm | 13 mm |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=9mm BLACK, LENGHT, L=1.2m, THIN-W | 1.65 mm | 25 . | pcs | 1.2 m | 9 mm | 3 mm |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=12mm BLACK, LENGHT, L=1.2m, THIN-W | 1.8 mm | 25 . | pcs | 1.2 m | 12 mm | 4 mm |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=6mm BLACK, LENGHT, L=1.2m, THIN-W | 1.35 mm | 25 . | pcs | 1.2 m | 6 mm | 2 mm |
Yes
|
|
|
- Total: 7
Similar Options
Approvals
- Total: 7
| Product Description | Approved according to UR | UL approval | Availability | ||
|---|---|---|---|---|---|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=19mm BLACK, LENGHT, L=1.2m, THIN-W |
|
No |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=24.0mm BLACK, LENGHT, L=1.2m, THIN-W |
|
No |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=3mm BLACK, LENGHT, L=1.2m, THIN-W |
|
No |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=40mm BLACK, LENGHT, L=1.2m, THIN-W |
|
No |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=9mm BLACK, LENGHT, L=1.2m, THIN-W |
|
No |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=12mm BLACK, LENGHT, L=1.2m, THIN-W |
|
No |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=6mm BLACK, LENGHT, L=1.2m, THIN-W |
|
No |
Yes
|
|
|
- Total: 7
Technical Properties
- Total: 7
| Product Description | Model | Operating temperature | Transparent | Type | Shrink rate | With inner glue | Printable | Colour | Material | Halogen free | Packaging | Availability | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=19mm BLACK, LENGHT, L=1.2m, THIN-W | Thin-walled | -45-125 °C | No | Heat-shrink | 3:1 | Yes | No | Black | Polyolefin (PO-X) | No | Cut to length |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=24.0mm BLACK, LENGHT, L=1.2m, THIN-W | Thin-walled | -45-125 °C | No | Heat-shrink | 3:1 | Yes | No | Black | Polyolefin (PO-X) | No | Cut to length |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=3mm BLACK, LENGHT, L=1.2m, THIN-W | Thin-walled | -45-125 °C | No | Heat-shrink | 3:1 | Yes | No | Black | Polyolefin (PO-X) | No | Cut to length |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=40mm BLACK, LENGHT, L=1.2m, THIN-W | Thin-walled | -45-125 °C | No | Heat-shrink | 3:1 | Yes | No | Black | Polyolefin (PO-X) | No | Cut to length |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=9mm BLACK, LENGHT, L=1.2m, THIN-W | Thin-walled | -45-125 °C | No | Heat-shrink | 3:1 | Yes | No | Black | Polyolefin (PO-X) | No | Cut to length |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=12mm BLACK, LENGHT, L=1.2m, THIN-W | Thin-walled | -45-125 °C | No | Heat-shrink | 3:1 | Yes | No | Black | Polyolefin (PO-X) | No | Cut to length |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=6mm BLACK, LENGHT, L=1.2m, THIN-W | Thin-walled | -45-125 °C | No | Heat-shrink | 3:1 | Yes | No | Black | Polyolefin (PO-X) | No | Cut to length |
Yes
|
|
|
- Total: 7
Other information
- Total: 7
| Product Description | ETIM-Class | ETIM-Release | Trademark | Product Group | Search Description | Alternative SKU | Availability | ||
|---|---|---|---|---|---|---|---|---|---|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=19mm BLACK, LENGHT, L=1.2m, THIN-W | EC000217 - Shrink tubing | 9.0 |
|
Length | CGAT 19L, ATUM 19L ENR2023V | NHSA19/6-L |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=24.0mm BLACK, LENGHT, L=1.2m, THIN-W | EC000217 - Shrink tubing | 9.0 |
|
Length | CGAT 24L, ATUM 24L ENR2023V | NHSA24/8-L |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=3mm BLACK, LENGHT, L=1.2m, THIN-W | EC000217 - Shrink tubing | 9.0 |
|
Length | CGAT 3L, ATUM 3L ENR2023V | NHSA3/1-L |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=40mm BLACK, LENGHT, L=1.2m, THIN-W | EC000217 - Shrink tubing | 9.0 |
|
Length | ATUM 40L, CGAT 39L ENR2023V | NHSA40/13-L |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=9mm BLACK, LENGHT, L=1.2m, THIN-W | EC000217 - Shrink tubing | 9.0 |
|
Length | CGAT 9L, ATUM 9L ENR2023V | NHSA9/3-L |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=12mm BLACK, LENGHT, L=1.2m, THIN-W | EC000217 - Shrink tubing | 9.0 |
|
Length | CGAT 12L, ATUM 12L ENR2023V | NHSA12/4-L |
Yes
|
|
|
| SHRINK TUBE WITH ADHESIVE, 3:1, ID=6mm BLACK, LENGHT, L=1.2m, THIN-W | EC000217 - Shrink tubing | 9.0 |
|
Length | CGAT 6L, ATUM 6L ENR2023V | NHSA6/2-L |
Yes
|
|
|
- Total: 7
