Nylflex, PA6, Automotive
Halogenfri, svårantändlig, värmestabil och UV-beständig. En ADR-godkänd standardslang med god flexibilitet som ger ett mycket gott skydd för elektriska ledningar mot fukt, smuts och mekanisk åverkan. Materialet är dessutom motståndkraftigt mot oljor, fett, lösningsmedel och drivmedel av olika slag. För fordonsindustrin, maskin och apparatbyggen samt för verkstäder.
Material: PA 6
Temperaturområde: -40° C till +120° C
Färg: Svart RAL 8022
Övriga egenskaper: UV-beständig, flamavvisande
Tryckhållfasthet: 350 N / 50 mm, slag 6J
Technical properties
- Compressive strength:
- 350 N
- Fire resistance according to UL94:
- HB
- Oil resistant:
- Yes
- Lengthwise slotted:
- No
- Closable (two-part):
- No
- With draw wire:
- No
- High conducting inner coating:
- No
- Degree of protection (IP):
- IP66
- Colour:
- Black
- Operating temperature:
- -40-120 °C
- Material:
- Polyamide 6
- Halogen free:
- Yes
- Suitable in fire resistance areas:
- Yes
Show more
Item List
- Total: 16
- Total: 16
Accessories
Related products
Spare Parts
Product video
Documents
Dimensions
- Total: 16
- Total: 16
Similar Options
Approvals
- Total: 16
| Product Description | Approved according to ADR CGVS | Approved according to DIN EN 61386-23 | Approved according to UR | Approves according to Vd TÜV/GGVS | Approved according to LUL/British Standard | Approved according to Lloyd's Register TA | Approved according to UTAC | Approved according to DIN 5510 | Approved according to NF F 16-101 | VDE tested | Degree of protection (IP) | Approved according to CSA | With approval according to UL | Availability | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CORRUGATED CONDUIT, PA6, BLACK NW13, ID=13.0mm, OD=16.0mm (10m) | No |
|
Yes | No | No | No | No | No | IP66 | No |
Yes
|
|
|
|||
| CORRUGATED CONDUIT, PA6, BLACK NW10, ID=9.8mm, OD=12.9mm (10m) | No |
|
Yes | No | No | No | No | No | IP66 | No |
Yes
|
|
|
|||
| CORRUGATED CONDUIT, PA6, BLACK NW17, ID=16.6mm, OD=21.0mm (10m) | No |
|
Yes | No | No | No | No | No | IP66 | No |
Yes
|
|
|
|||
| CORRUGATED CONDUIT, PA6, BLACK NW22, ID=21.4mm, OD=25.4mm (10m) | No |
|
Yes | No | No | No | No | No | IP66 | No |
Yes
|
|
|
|||
| CORRUGATED CONDUIT, PA6, BLACK NW7.5, ID=6.8mm, OD=9.9mm |
|
No |
|
Yes | No | No | No | No | No | Yes | IP66 | No |
|
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW8.5, ID=8.4mm, OD=11.4mm |
|
No |
|
Yes | No | No | No | No | No | Yes | IP66 | No |
|
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW10, ID=9.8mm, OD=12.9mm |
|
No |
|
Yes | No | No | No | No | No | Yes | IP66 | No |
|
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW12, ID=12.2mm, OD=15.7mm |
|
No |
|
Yes | No | No | No | No | No | Yes | IP66 | No |
|
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW13, ID=13.0mm, OD=16.0mm |
|
No |
|
Yes | No | No | No | No | No | Yes | IP66 | No |
|
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW14, ID=14.3mm, OD=18.2mm |
|
No |
|
Yes | No | No | No | No | No | Yes | IP66 | No |
|
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW17, ID=16.6mm, OD=21.0mm |
|
No |
|
Yes | No | No | No | No | No | Yes | IP66 | No |
|
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW22, ID=21.4mm, OD=25.4mm |
|
No |
|
Yes | No | No | No | No | No | Yes | IP66 | No |
|
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW23, ID=23.0mm, OD=28.4mm |
|
No |
|
Yes | No | No | No | No | No | Yes | IP66 | No |
|
No
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW29, ID=28.9mm, OD=34.3mm |
|
No |
|
Yes | No | No | No | No | No | Yes | IP66 | No |
|
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW36, ID=35.3mm, OD=42.5mm |
|
No |
|
Yes | No | No | No | No | No | Yes | IP66 | No |
|
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW48, ID=47.5mm, OD=54.5mm |
|
No |
|
Yes | No | No | No | No | No | Yes | IP66 | No |
|
Yes
|
|
|
- Total: 16
Technical Properties
- Total: 16
| Product Description | Compressive strength | Fire resistance according to UL94 | Oil resistant | Lengthwise slotted | Closable (two-part) | With draw wire | High conducting inner coating | Degree of protection (IP) | Colour | Operating temperature | Material | Halogen free | Suitable in fire resistance areas | Availability | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CORRUGATED CONDUIT, PA6, BLACK NW13, ID=13.0mm, OD=16.0mm (10m) | 350 N | HB | Yes | No | No | No | No | IP66 | Black | -40-120 °C | Polyamide 6 | Yes | Yes |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW10, ID=9.8mm, OD=12.9mm (10m) | 350 N | HB | Yes | No | No | No | No | IP66 | Black | -40-120 °C | Polyamide 6 | Yes | Yes |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW17, ID=16.6mm, OD=21.0mm (10m) | 350 N | HB | Yes | No | No | No | No | IP66 | Black | -40-120 °C | Polyamide 6 | Yes | Yes |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW22, ID=21.4mm, OD=25.4mm (10m) | 350 N | HB | Yes | No | No | No | No | IP66 | Black | -40-120 °C | Polyamide 6 | Yes | Yes |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW7.5, ID=6.8mm, OD=9.9mm | 350 N | HB | Yes | No | No | No | No | IP66 | Black | -40-120 °C | Polyamide 6 | Yes | Yes |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW8.5, ID=8.4mm, OD=11.4mm | 350 N | HB | Yes | No | No | No | No | IP66 | Black | -40-120 °C | Polyamide 6 | Yes | Yes |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW10, ID=9.8mm, OD=12.9mm | 350 N | HB | Yes | No | No | No | No | IP66 | Black | -40-120 °C | Polyamide 6 | Yes | Yes |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW12, ID=12.2mm, OD=15.7mm | 350 N | HB | Yes | No | No | No | No | IP66 | Black | -40-120 °C | Polyamide 6 | Yes | Yes |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW13, ID=13.0mm, OD=16.0mm | 350 N | HB | Yes | No | No | No | No | IP66 | Black | -40-120 °C | Polyamide 6 | Yes | Yes |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW14, ID=14.3mm, OD=18.2mm | 350 N | HB | Yes | No | No | No | No | IP66 | Black | -40-120 °C | Polyamide 6 | Yes | Yes |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW17, ID=16.6mm, OD=21.0mm | 350 N | HB | Yes | No | No | No | No | IP66 | Black | -40-120 °C | Polyamide 6 | Yes | Yes |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW22, ID=21.4mm, OD=25.4mm | 350 N | HB | Yes | No | No | No | No | IP66 | Black | -40-120 °C | Polyamide 6 | Yes | Yes |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW23, ID=23.0mm, OD=28.4mm | 350 N | HB | Yes | No | No | No | No | IP66 | Black | -40-120 °C | Polyamide 6 | Yes | Yes |
No
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW29, ID=28.9mm, OD=34.3mm | 350 N | HB | Yes | No | No | No | No | IP66 | Black | -40-120 °C | Polyamide 6 | Yes | Yes |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW36, ID=35.3mm, OD=42.5mm | 350 N | HB | Yes | No | No | No | No | IP66 | Black | -40-120 °C | Polyamide 6 | Yes | Yes |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW48, ID=47.5mm, OD=54.5mm | 350 N | HB | Yes | No | No | No | No | IP66 | Black | -40-120 °C | Polyamide 6 | Yes | Yes |
Yes
|
|
|
- Total: 16
Other information
- Total: 16
| Product Description | ETIM-Class | ETIM-Release | Trademark | Product Group | Alternative SKU | Availability | ||
|---|---|---|---|---|---|---|---|---|
| CORRUGATED CONDUIT, PA6, BLACK NW13, ID=13.0mm, OD=16.0mm (10m) | EC001175 - Corrugated plastic hose | 9.0 |
|
Conduit | NYLFLEX13-10 |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW10, ID=9.8mm, OD=12.9mm (10m) | EC001175 - Corrugated plastic hose | 9.0 |
|
Conduit | NYLFLEX10-10 |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW17, ID=16.6mm, OD=21.0mm (10m) | EC001175 - Corrugated plastic hose | 9.0 |
|
Conduit | NYLFLEX17-10 |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW22, ID=21.4mm, OD=25.4mm (10m) | EC001175 - Corrugated plastic hose | 9.0 |
|
Conduit | NYLFLEX22-10 |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW7.5, ID=6.8mm, OD=9.9mm | EC001175 - Corrugated plastic hose | 9.0 |
|
Conduit | NYLFLEX7.5 |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW8.5, ID=8.4mm, OD=11.4mm | EC001175 - Corrugated plastic hose | 9.0 |
|
Conduit | NYLFLEX8.5 |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW10, ID=9.8mm, OD=12.9mm | EC001175 - Corrugated plastic hose | 9.0 |
|
Conduit | NYLFLEX10 |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW12, ID=12.2mm, OD=15.7mm | EC001175 - Corrugated plastic hose | 9.0 |
|
Conduit | NYLFLEX12 |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW13, ID=13.0mm, OD=16.0mm | EC001175 - Corrugated plastic hose | 9.0 |
|
Conduit | NYLFLEX13 |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW14, ID=14.3mm, OD=18.2mm | EC001175 - Corrugated plastic hose | 9.0 |
|
Conduit | NYLFLEX14 |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW17, ID=16.6mm, OD=21.0mm | EC001175 - Corrugated plastic hose | 9.0 |
|
Conduit | NYLFLEX17 |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW22, ID=21.4mm, OD=25.4mm | EC001175 - Corrugated plastic hose | 9.0 |
|
Conduit | NYLFLEX22 |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW23, ID=23.0mm, OD=28.4mm | EC001175 - Corrugated plastic hose | 9.0 |
|
Conduit | NYLFLEX23 |
No
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW29, ID=28.9mm, OD=34.3mm | EC001175 - Corrugated plastic hose | 9.0 |
|
Conduit | NYLFLEX29 |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW36, ID=35.3mm, OD=42.5mm | EC001175 - Corrugated plastic hose | 9.0 |
|
Conduit | NYLFLEX36 |
Yes
|
|
|
| CORRUGATED CONDUIT, PA6, BLACK NW48, ID=47.5mm, OD=54.5mm | EC001175 - Corrugated plastic hose | 9.0 |
|
Conduit | NYLFLEX48 |
Yes
|
|
|
- Total: 16
