Batteripolsäkringar - CF-serien
CF
Maximum voltage: 58 VCurrent rating: 50-300 A
Technical properties
- Explosion-proof:
- No
- Release characteristic:
- Medium time-lag
- Optical defect indication:
- Yes
- Type of current:
- DC
- Colour code:
- Other
- Nominal voltage DC:
- 58 V
- Max. continuous voltage DC:
- 58 V
- Max. current (Imax):
- 100 A, 125 A, 150 A, 175 A, 200 A, 250 A, 300 A, 50 A, 75 A
- Nominal current:
- 100 A, 125 A, 150 A, 175 A, 200 A, 250 A, 300 A, 50 A, 75 A
- Fuse type:
- Battery
- Packaging:
- Loose piece
Show more
Item List
- Total: 10
- Total: 10
Accessories
Related products
Spare Parts
Product video
Documents
Manuals, Datasheets, Sketches & Drawings
Conflict Minerals Reporting Template Version 6.31_Approved
Dimensions
- Total: 10
| Product Description | Width | MOQ | Unit | Mounting holes | Thickness | Length | Availability | ||
|---|---|---|---|---|---|---|---|---|---|
| BATTERY TERMINAL FUSE, 100A . | 20 mm | 10 . | pcs | Other | 11 mm | 25 mm |
Yes
|
|
|
| BATTERY TERMINAL FUSE, 125A . | 20 mm | 10 . | pcs | Other | 11 mm | 25 mm |
No
|
|
|
| BATTERY TERMINAL FUSE, 175A . | 20 mm | 10 . | pcs | Other | 11 mm | 25 mm |
No
|
|
|
| BATTERY TERMINAL FUSE, 200A . | 20 mm | 10 . | pcs | Other | 11 mm | 25 mm |
No
|
|
|
| BATTERY TERMINAL FUSE, 250A . | 20 mm | 10 . | pcs | Other | 11 mm | 25 mm |
Yes
|
|
|
| BATTERY TERMINAL FUSE, 300A . | 20 mm | 10 . | pcs | Other | 11 mm | 25 mm |
Yes
|
|
|
| BATTERY TERMINAL FUSE, 50A . | 20 mm | 10 . | pcs | Other | 11 mm | 25 mm |
No
|
|
|
| BATTERY TERMINAL FUSE, 75A . | 20 mm | 10 . | pcs | Other | 11 mm | 25 mm |
Yes
|
|
|
| ISOLATION NUT, M8 TO CUBE BATTERY TERMINAL FUSES | 10 . | pcs |
Yes
|
|
|
||||
| BATTERY TERMINAL FUSE, 150A . | 20 mm | 10 . | pcs | Other | 11 mm | 25 mm |
Yes
|
|
|
- Total: 10
Similar Options
Approvals
- Total: 10
| Product Description | Availability | ||
|---|---|---|---|
| BATTERY TERMINAL FUSE, 100A . |
Yes
|
|
|
| BATTERY TERMINAL FUSE, 125A . |
No
|
|
|
| BATTERY TERMINAL FUSE, 175A . |
No
|
|
|
| BATTERY TERMINAL FUSE, 200A . |
No
|
|
|
| BATTERY TERMINAL FUSE, 250A . |
Yes
|
|
|
| BATTERY TERMINAL FUSE, 300A . |
Yes
|
|
|
| BATTERY TERMINAL FUSE, 50A . |
No
|
|
|
| BATTERY TERMINAL FUSE, 75A . |
Yes
|
|
|
| ISOLATION NUT, M8 TO CUBE BATTERY TERMINAL FUSES |
Yes
|
|
|
| BATTERY TERMINAL FUSE, 150A . |
Yes
|
|
|
- Total: 10
Technical Properties
- Total: 10
| Product Description | Explosion-proof | Release characteristic | Optical defect indication | Type of current | Colour code | Nominal voltage DC | Max. continuous voltage DC | Max. current (Imax) | Nominal current | Fuse type | Packaging | Availability | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BATTERY TERMINAL FUSE, 100A . | No | Medium time-lag | Yes | DC | Other | 58 V | 58 V | 100 A | 100 A | Battery | Loose piece |
Yes
|
|
|
| BATTERY TERMINAL FUSE, 125A . | No | Medium time-lag | Yes | DC | Other | 58 V | 58 V | 125 A | 125 A | Battery | Loose piece |
No
|
|
|
| BATTERY TERMINAL FUSE, 175A . | No | Medium time-lag | Yes | DC | Other | 58 V | 58 V | 175 A | 175 A | Battery | Loose piece |
No
|
|
|
| BATTERY TERMINAL FUSE, 200A . | No | Medium time-lag | Yes | DC | Other | 58 V | 58 V | 200 A | 200 A | Battery | Loose piece |
No
|
|
|
| BATTERY TERMINAL FUSE, 250A . | No | Medium time-lag | Yes | DC | Other | 58 V | 58 V | 250 A | 250 A | Battery | Loose piece |
Yes
|
|
|
| BATTERY TERMINAL FUSE, 300A . | No | Medium time-lag | Yes | DC | Other | 58 V | 58 V | 300 A | 300 A | Battery | Loose piece |
Yes
|
|
|
| BATTERY TERMINAL FUSE, 50A . | No | Medium time-lag | Yes | DC | Other | 58 V | 58 V | 50 A | 50 A | Battery | Loose piece |
No
|
|
|
| BATTERY TERMINAL FUSE, 75A . | No | Medium time-lag | Yes | DC | Other | 58 V | 58 V | 75 A | 75 A | Battery | Loose piece |
Yes
|
|
|
| ISOLATION NUT, M8 TO CUBE BATTERY TERMINAL FUSES | 300 A | Battery | Loose piece |
Yes
|
|
|
||||||||
| BATTERY TERMINAL FUSE, 150A . | No | Medium time-lag | Yes | DC | Other | 58 V | 58 V | 150 A | 150 A | Battery | Loose piece |
Yes
|
|
|
- Total: 10
Other information
- Total: 10
| Product Description | ETIM-Class | ETIM-Release | Product Group | Search Description | Alternative SKU | Availability | ||
|---|---|---|---|---|---|---|---|---|
| BATTERY TERMINAL FUSE, 100A . | EC004122 - Strip fuse | DYNAMIC | Battery terminal fuses | NEWFUSE | CUBE100 |
Yes
|
|
|
| BATTERY TERMINAL FUSE, 125A . | EC004122 - Strip fuse | DYNAMIC | Battery terminal fuses | NEWFUSE | CUBE125 |
No
|
|
|
| BATTERY TERMINAL FUSE, 175A . | EC004122 - Strip fuse | DYNAMIC | Battery terminal fuses | NEWFUSE | CUBE175 |
No
|
|
|
| BATTERY TERMINAL FUSE, 200A . | EC004122 - Strip fuse | DYNAMIC | Battery terminal fuses | NEWFUSE | CUBE200 |
No
|
|
|
| BATTERY TERMINAL FUSE, 250A . | EC004122 - Strip fuse | DYNAMIC | Battery terminal fuses | NEWFUSE | CUBE250 |
Yes
|
|
|
| BATTERY TERMINAL FUSE, 300A . | EC004122 - Strip fuse | DYNAMIC | Battery terminal fuses | NEWFUSE | CUBE300 |
Yes
|
|
|
| BATTERY TERMINAL FUSE, 50A . | EC004122 - Strip fuse | DYNAMIC | Battery terminal fuses | NEWFUSE | CUBE50 |
No
|
|
|
| BATTERY TERMINAL FUSE, 75A . | EC004122 - Strip fuse | DYNAMIC | Battery terminal fuses | NEWFUSE | CUBE75 |
Yes
|
|
|
| ISOLATION NUT, M8 TO CUBE BATTERY TERMINAL FUSES | EC004122 - Strip fuse | DYNAMIC | Battery terminal fuses | NEWFUSE | CUBEM8 |
Yes
|
|
|
| BATTERY TERMINAL FUSE, 150A . | EC004122 - Strip fuse | DYNAMIC | Battery terminal fuses | NEWFUSE | CUBE150 |
Yes
|
|
|
- Total: 10
